1972 Jarama - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
004608478	BELT BELT	Avail to order Our Price: $108.74
004504532	BELT BELT FOR AIR CONDITIONER WE HAVE SOURCE IT IS NLA FROM LAMBORGHINI	Current Stock: 5 Our Price: $53.31
001604645	ALTERNATOR BELT BELT	Current Stock: 5 Our Price: $23.63
004009744	POWER STEERING BELT POWER STEERING BELT	Avail to order Our Price: $110.92

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $521.78
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD	Avail to order Our Price: $90.02
003207720	E-BRAKE PAD ESPADA JARAMA E-BRAKE PAD ESPADA JARAMA	Avail to order Our Price: $86.86

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.85
001702817	THERMOSTAT VALVE THERMOSTAT VALVE NLA (NO LONGER AVAILABLE) FROM FACTORY PLEASE CHECK FOR CURRENT PRICE AND AVAILABILITY. PRICING IS NOT UPDATED FOR NLA PARTS		Avail to order Our Price: $622.54

Drivetrain

PN	Item
002104088	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $27.25
002104719	DRIVE PLATE DRIVE PLATE	Avail to order Our Price: $836.48
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 3 Our Price: $55.02

Fuel-Air

PN	Item	Diagram
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION		Avail to order Our Price: $574.63
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 2 Our Price: $25.14

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $10.64
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.37
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.99
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.47
001605819	RELAY RELAY	Current Stock: 1 Our Price: $42.75
006617089	10 W BULB 10 W BULB	Avail to order Our Price: $15.25
006617103	3W BULB 3W BULB	Avail to order Our Price: $6.87

Gaskets

PN	Item	Diagram
001526462	GROMMET AND OIL SEALS SET - ESPADA - JARAMA GROMMET AND OIL SEALS SET ESPADA - JARAMA		Avail to order Our Price: $113.58
001526482	ENGINE GASKET SET - ESPADA - JARAMA ENGINE GASKET KIT ESPADA - JARAMA		Avail to order Our Price: $1,320.91

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,004.07

Misc

PN	Item
006715235	WINDSC.WIP.BLADE WINDSC.WIP.BLADE	Avail to order Our Price: $65.80
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.57

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $172.55
001719309	COOLANT THERMOSTAT COOLANT THERMOSTAT FITS THE FOLLOWING: COUNTACH 5000 S, LP400 ESPADA JALPA 3.5 URRACO P30		Avail to order Our Price: $395.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 88 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 7.17 - Water Pump

1972 Lamborghini Jarama USA Water Pump (7.17)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008602303	RING 24 MM OR	2 req	Current Stock: 18 Our Price: $0.70
2	001701783	WASHER	1 req	Avail to order Our Price: $10.64
3	001704506	COOLANT INLET PIPE	1 req	Avail to order Our Price: $1,486.06
4	008835004	CLAMP	4 req	Avail to order Our Price: $12.42
5	001701983	COOLANT PUMP SLEEVE	1 req	Avail to order Our Price: $78.58
6	001700395	COOLANT PUMP DRIVE SHAFT	1 req	Avail to order Our Price: $459.07
7	008860401	TAB 4X4X12	1 req	Avail to order Our Price: $35.99
8	001700391	COOLANT PUMP SEAL	1 req	Avail to order Our Price: $13.08
9	001704498	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008574301	O-RING	1 req	Current Stock: 20 Our Price: $3.06
11	008501705	BEARING	1 req	Current Stock: 16 Our Price: $48.80
12	008581501	O-RING E 17 UNI 7435-75	1 req	Current Stock: 14 Our Price: $0.40
13	07M109381	O-RING SEAL RING	1 req	Current Stock: 25 Our Price: $1.91
14	001712752	COOLANT SEAL SHOULDER WASHER	1 req	Avail to order Our Price: $42.09
15	008611703	SEAL	1 req	Avail to order Our Price: $457.39
16	001700396	This item is no longer available	1 req
17	001712751	COOLANT PUMP IMPELLER	1 req	Avail to order Our Price: $4,375.66
18	WHT000768	SPRING WASHER	1 req	Current Stock: 15 Our Price: $2.18
19	008201005	M10 UNI 5721-65 SPECIAL NU	1 req	Avail to order Our Price: $15.57
20	001704578	CASING/COVER SEAL	1 req	Current Stock: 1 Our Price: $23.27
21	001704495	This item is no longer available	1 req
22	WHT001197A	WASHER	6 req	Current Stock: 22 Our Price: $0.40
23	008100617	SCREW M6X18 UNI 57395S	6 req	Avail to order Our Price: $6.53
24	001704586	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
25	008300614	STUD M6X18 UNI 5911 8G/ZD	5 req	Avail to order Our Price: $9.96
26	N01152427	WASHER	5 req	Current Stock: 11 Our Price: $0.40
27	008200605	SIMMON NUT FOR URAMA	5 req	Current Stock: 39 Our Price: $3.45
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
