1972 Jarama - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
004608478	BELT BELT	Avail to order Our Price: $100.78
004504532	BELT BELT	Current Stock: 1 Our Price: $49.39
001604645	BELT BELT	Current Stock: 1 Our Price: $21.96
004009744	POWER STEERING BELT POWER STEERING BELT	Avail to order Our Price: $102.76

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $494.83
003207720	E-BRAKE PAD ESPADA JARAMA E-BRAKE PAD ESPADA JARAMA	Avail to order Our Price: $82.36
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD	Avail to order Our Price: $85.26

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $25.41
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $589.94

Drivetrain

PN	Item
002104719	DRIVE PLATE DRIVE PLATE	Avail to order Our Price: $774.98
002104088	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $25.19
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $52.14

Fuel-Air

PN	Item	Diagram
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION		Avail to order Our Price: $544.80
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $23.86

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $9.86
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.04
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.80
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.43
001605819	RELAY RELAY	Current Stock: 1 Our Price: $39.61
006617089	10 W BULB 10 W BULB	Avail to order Our Price: $14.15
006617103	3W BULB 3W BULB	Avail to order Our Price: $6.35

Gaskets

PN	Item	Diagram
001526482	ENGINE GASKET SET - ESPADA - JARAMA ENGINE GASKET KIT ESPADA - JARAMA		Avail to order Our Price: $1,250.80
001526462	GROMMET AND OIL SEALS SET - ESPADA - JARAMA GROMMET AND OIL SEALS SET ESPADA - JARAMA		Avail to order Our Price: $107.67

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $931.04

Misc

PN	Item
006715235	WINDSC.WIP.BLADE WINDSC.WIP.BLADE	Avail to order Our Price: $60.97
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $162.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT		Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 27.52 - Rear Suspension

1972 Lamborghini Jarama USA Rear Suspension (27.52)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	005204397	LH UPPER ARM	1 req	Avail to order Our Price: $211.60
0	005200719	REAR LH WHEEL HUB	1 req	Avail to order Our Price: $3,658.90
0	008201806	18X1.5 RIGHT NUT	1 req	Avail to order Our Price: $38.09
0	005204453	LH LOWER ARM	1 req	Avail to order Our Price: $587.19
1	008201603	NUT	4 req	Avail to order Our Price: $4.28
2	008401611	WASHER 17X29X3 5S UNI 16592	4 req	Avail to order Our Price: $14.55
3	008401612	WASHER 16.5X35X4	8 req	Avail to order Our Price: $10.58
4	008921601	SILBLOC RIV X220 52470	4 req	Avail to order Our Price: $75.52
5	005204566	NLA (NO LONGER AVAILABLE)	2 req	*See Description
6	005105678	This item is no longer available	2 req
7	008101609	NLA (NO LONGER AVAILABLE)	4 req	*See Description
8	005205680	REAR SHOCK ABSORBER BULKHEAD	2 req	Avail to order Our Price: $126.04
9	005205633	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
10	005204396	RH UPPER ARM	1 req	Avail to order Our Price: $211.60
11	008401705	WASHER	1 req	Current Stock: 2 Our Price: $1.19
12	008921702	SILBLOC RIV.89801584	8 req	Avail to order Our Price: $29.82
13	008401706	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
14	008101610	SCREW	4 req	Current Stock: 1 Our Price: $61.57
15	008101614	SCREW 16X1.5X82 CH2410K	4 req	Avail to order Our Price: $36.17
16	008400803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
17	008200804	NUT	8 req	Current Stock: 7 Our Price: $1.37
18	005200718	REAR RH HUB	1 req	Avail to order Our Price: $3,658.90
19	005200721	REAR WHEEL HUB SHIM	2 req	Avail to order Our Price: $342.53
20	008615201	OIL SEAL	2 req	Current Stock: 1 Our Price: $33.68
21	008577601	O-RING I 27 UNI 3654	4 req	Current Stock: 16 Our Price: $3.44
22	008523505	BEARING	2 req	Avail to order Our Price: $284.50
23	005206462	SPACER	2 req	Avail to order Our Price: $250.61
24	008700505	SCREW ESLOK 5X10 8G 2384	2 req	Avail to order Our Price: $6.09
25	005206463	REAR SUSPENSION HUB	2 req	Avail to order Our Price: $591.16
26	005205492	REAR BALL JOINT BUSHING	2 req	Avail to order Our Price: $142.33
27	008880601	HYDRAULIC 273 A GREASE DISPENS	2 req	Current Stock: 8 Our Price: $1.77
28	WHT003082	CYLINDER PINS 1707 H11 3X5	4 req	Current Stock: 41 Our Price: $0.90
29	008004284	COVER. 2AANON 25	2 req	Avail to order Our Price: $334.60
30	086525596	SEAL RING	2 req	Avail to order Our Price: $51.68
31	005201006	REAR HUB THREADED RING	2 req	Avail to order Our Price: $251.45
32	005206464	CV JOINT DRIVE AXLE FLANGE	2 req	Avail to order Our Price: $2,828.80
33	008201805	18X1.5 LEFT NUT	1 req	Avail to order Our Price: $38.09
34	008820401	SPLIT PIN A 4X40 UNI 1336	2 req	Avail to order Our Price: $2.58
35	005100527	UPPER JOINT ATTACHMENT SHEET	2 req	Avail to order Our Price: $1,805.28
36	005100961	UPPER BALL JOINT	2 req	Avail to order Our Price: $261.12
37	008401707	WASHER 17.5X44X1.5	4 req	Avail to order Our Price: $15.87
38	008403501	ERTALON WASHER 30X45	4 req	Avail to order Our Price: $33.45
39	008403502	WASHER 32X44X1.5	4 req	Avail to order Our Price: $33.45
40	008401708	WASHER 17.5X26X3 AQ42	8 req	Current Stock: 1 Our Price: $2.58
41	008201603	NUT	8 req	Avail to order Our Price: $4.28
42	008921801	ROLL BAR MOUNT 18	2 req	Current Stock: 2 Our Price: $45.87
43	008921802	U BOLT	2 req	Avail to order Our Price: $43.93
44	005204568	This item is no longer available	1 req
45	008201006	M10SELF LOCKING NUT	2 req	Avail to order Our Price: $7.81
46	005204572	BAR MOUNT BRACKET	2 req	Avail to order Our Price: $165.21
47	008411005	WASHER D.10.5 UNI 1751/F	2 req	Avail to order Our Price: $0.09
48	008101014	SCREW M10X20 UNI 5739/8G	2 req	Avail to order Our Price: $14.59
49	005204575	BAR MOUNT PLATE	2 req	Avail to order Our Price: $117.67
50	005101047	TORSION BAR U-BOLT	2 req	Avail to order Our Price: $112.41
51	008201007	M10X1SELF-LOCKINGNUT	4 req	Avail to order Our Price: $7.81
52	008201603	NUT	2 req	Avail to order Our Price: $4.28
53	008401613	WASHER 16.5X30X3	2 req	Avail to order Our Price: $2.58
54	008802002	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
55	008402004	BRONZE WASHER 22 X 20 X 2	4 req	Avail to order Our Price: $134.90
56	008402201	SHIM ADJUSTMENT WASHER WC 20 D	4 req	Avail to order Our Price: $12.83
57	008603902	OR RING	4 req	Current Stock: 18 Our Price: $0.66
58	008613802	HUB HOLDER SEALING RING	4 req	Avail to order Our Price: $25.55
59	005204452	RH LOWER ARM	1 req	Avail to order Our Price: $587.19
60	005201902	LOWER REAR ARM SHIM ADJUSTMENT	4 req	Avail to order Our Price: $424.52
61	008412401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
62	008202401	24X1 8G NUT	4 req	Current Stock: 1 Our Price: $3.04
63	008101612	This item is no longer available	2 req
64	008401303	WASHER	2 req	Avail to order Our Price: $17.85
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
