TAV: 7.10200.17 - Water Pump

1972 Lamborghini Jarama USA Water Pump (7.10200.17)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008835004	Clamp	2 req	Avail to order Our Price: $10.86
2	001701783	Washer 32x38 0.5-1-1.5	1 req	Avail to order Our Price: $11.09
3	001704506	Coolant Inlet Pipe	1 req	Avail to order Our Price: $1,297.54
4	008835004	Clamp	2 req	Avail to order Our Price: $10.86
5	001701983	Coolant Pump Sleeve	1 req	Avail to order Our Price: $68.63
6	001700395	NLA (No Longer Available)	1 req	*See Description
7	008860401	Tab 4x4x12	1 req	Avail to order Our Price: $31.41
8	001700391	Coolant Pump Seal	1 req	Avail to order Our Price: $13.71
9	001704498	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	008574301	O-Ring I 40 Uni 3654	1 req	Current Stock: 22 Our Price: $2.71
11	008501705	Bearing	1 req	Current Stock: 16 Our Price: $50.95
12	008581501	O-Ring E 17 Uni 7435-75	1 req	Current Stock: 16 Our Price: $2.00
13	07M109381	Snap Ring I 35 Uni 3654	1 req	Current Stock: 35 Our Price: $2.00
14	001712752	Coolant Seal Shoulder Washer	1 req	Avail to order Our Price: $36.84
15	008611703	Seal	1 req	Avail to order Our Price: $398.33
16	001700396	This item is no longer available	1 req
17	001712751	COOLANT PUMP IMPELLER	1 req	Avail to order Our Price: $1,190.52
18	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.14
19	008201005	M10 Uni 5721-65 Special Nu	1 req	Avail to order Our Price: $13.57
20	001704578	Casing/Cover Seal	1 req	Current Stock: 1 Our Price: $20.26
21	001704495	This item is no longer available	1 req
22	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
23	008100617	Screw M6x18 Uni 57395s	6 req	Avail to order Our Price: $6.81
24	001704586	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
25	008300614	Stud M6x18 Uni 5911 8g/Zd	5 req	Avail to order Our Price: $8.72
26	N01152427	WASHER	5 req	Current Stock: 16 Our Price: $2.00
27	008200605	Simmon Nut for urama	5 req	Current Stock: 50 Our Price: $3.10
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
