1972 Jarama - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
004608478	BELT BELT	Avail to order Our Price: $100.78
004504532	BELT BELT	Current Stock: 1 Our Price: $49.39
001604645	BELT BELT	Current Stock: 1 Our Price: $21.96
004009744	POWER STEERING BELT POWER STEERING BELT	Avail to order Our Price: $102.76

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $494.83
003207720	E-BRAKE PAD ESPADA JARAMA E-BRAKE PAD ESPADA JARAMA	Avail to order Our Price: $82.36
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD	Avail to order Our Price: $85.26

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $25.41
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $589.94

Drivetrain

PN	Item
002104719	DRIVE PLATE DRIVE PLATE	Avail to order Our Price: $774.98
002104088	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $25.19
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $52.14

Fuel-Air

PN	Item	Diagram
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION		Avail to order Our Price: $544.80
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $23.86

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $9.86
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.04
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.80
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.43
001605819	RELAY RELAY	Current Stock: 1 Our Price: $39.61
006617089	10 W BULB 10 W BULB	Avail to order Our Price: $14.15
006617103	3W BULB 3W BULB	Avail to order Our Price: $6.35

Gaskets

PN	Item	Diagram
001526482	ENGINE GASKET SET - ESPADA - JARAMA ENGINE GASKET KIT ESPADA - JARAMA		Avail to order Our Price: $1,250.80
001526462	GROMMET AND OIL SEALS SET - ESPADA - JARAMA GROMMET AND OIL SEALS SET ESPADA - JARAMA		Avail to order Our Price: $107.67

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $931.04

Misc

PN	Item
006715235	WINDSC.WIP.BLADE WINDSC.WIP.BLADE	Avail to order Our Price: $60.97
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $162.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT		Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 2.10300.11 - Cylinder Heads

1972 Lamborghini Jarama USA Cylinder Heads (2.10300.11)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001104881	LH HEAD REAR LH COVER	4 req	Current Stock: 1 Our Price: $236.73
2	001104915	CAM REAR COVER SEAL	4 req	Current Stock: 1 Our Price: $6.93
3	001104529	This item is no longer available	1 req
4	001100903	This item is no longer available	1 req
5	008200605	SIMMON NUT FOR URAMA	32 req	Current Stock: 50 Our Price: $3.31
6	N01152427	WASHER	32 req	Current Stock: 16 Our Price: $0.40
7	008300819	SPECIAL STUD M 8	28 req	Avail to order Our Price: $51.84
8	008300821	SPECIAL STUD M 8	4 req	Avail to order Our Price: $117.70
9	008300822	STUD M8X18 UNI 5911 8G Z	16 req	Avail to order Our Price: $23.67
10	001107364	This item is no longer available	2 req
11	008850501	REFERENCE PIN 5H7X7.5 C40	8 req	Avail to order Our Price: $35.62
12	001107363	CAM SUPPOR	8 req	Avail to order Our Price: $339.88
13	001107362	This item is no longer available	2 req
14	008200806	M8 UNI 5588/8G/Z NUT	40 req	Current Stock: 25 Our Price: $0.45
15	WHT001514	SPRING WASHER	40 req	Current Stock: 9 Our Price: $30.65
16	008200605	SIMMON NUT FOR URAMA	2 req	Current Stock: 50 Our Price: $3.31
17	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $0.40
18	001102055	HEAD COVER HOLDER PLATE	2 req	Avail to order Our Price: $323.98
19	008300612	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
20	008300818	STUD M8X30 UNI 5911 8G ZD	4 req	Avail to order Our Price: $5.49
21	001600906	DISTRIBUTOR BRACKET SEAL	1 req	Current Stock: 1 Our Price: $12.50
22	001108384	ESP/JAR OIL BREATHERCASING	1 req	Avail to order Our Price: $1,910.05
23	008200806	M8 UNI 5588/8G/Z NUT	16 req	Current Stock: 25 Our Price: $0.45
24	WHT001514	SPRING WASHER	16 req	Current Stock: 9 Our Price: $30.65
25	008300820	STUD M8X25 UNI 5911 8G ZD	4 req	Avail to order Our Price: $2.66
26	001107365	This item is no longer available	2 req
27	001104887	CAM COVER SEAL	4 req	Avail to order Our Price: $29.74
28	001104888	CAM COVER SEAL	4 req	Avail to order Our Price: $29.74
29	001107361	This item is no longer available	2 req
30	008851002	REFERENCE PIN 10H7X8.25 C40	32 req	Avail to order Our Price: $6.09
31	001102070	This item is no longer available	1 req
32	001104528	TESTA MOTORE SX	1 req	Avail to order Our Price: $33,389.49
33	008300613	STUD M6X14 UNI 5911 8G/Z	6 req	Avail to order Our Price: $5.10
34	N01152427	WASHER	6 req	Current Stock: 16 Our Price: $0.40
35	N01118312	HEX.HEAD CLAMPING NUT	6 req	Avail to order Our Price: $2.43
36	004607775	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
37	008200807	M8 OT.58 UNI 2012SELF-LOCKI	18 req	Avail to order Our Price: $23.67
38	008300820	STUD M8X25 UNI 5911 8G ZD	18 req	Avail to order Our Price: $2.66
39	N0152785	WASHER	18 req	Current Stock: 71 Our Price: $0.50
40	001101401	OIL FILLER PLUG GASKET	2 req	Avail to order Our Price: $4.35
41	001103876	This item is no longer available	1 req
42	001103872	OIL FILLER PLUG	1 req	Avail to order Our Price: $37.03
43	008830205	CLAMP	2 req	Avail to order Our Price: $7.01
44	001101634	OIL BREATHER GASKET	1 req	Current Stock: 1 Our Price: $12.83
45	004606294	RH HEAD CLOSING COVER	1 req	Avail to order Our Price: $179.20
46	008700613	SCREW M6X14 UNI 5933/8G/ZB	2 req	Avail to order Our Price: $0.22
47	008605501	OR RING	1 req	Avail to order Our Price: $0.74
48	008301006	STUD M10X35 UNI 59118GZ	6 req	Avail to order Our Price: $11.17
49	008401006	WASHER 22X10.5X2.5 UNI 1734/5S	6 req	Current Stock: 1 Our Price: $0.71
50	008201008	NUT	6 req	Current Stock: 2 Our Price: $1.06
51	004604530	This item is no longer available	1 req
52	001100904	This item is no longer available	1 req
53	001100901	TESTA MOTORE DX	1 req	Avail to order Our Price: $33,389.49
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
