1972 Lamborghini Jarama USA Power Steering (Optional) (44.40)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 44.40 - Power Steering (Optional)

1972 Lamborghini Jarama USA Power Steering (Optional) (44.40)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	004009726	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
0	004009725	Reservoir/Oil Pump Pipe	1 req	Avail to order Our Price: $66.73
0	004009734	RH Power Steering Pipe	1 req	Avail to order Our Price: $367.51
0	004008968	Power Steering	1 req	Avail to order Our Price: $4,465.27
1	001509899	Alternator & Compressor Drive	1 req	Avail to order Our Price: $1,019.79
2	004009742	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
3	004009745	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
4	001508485	Pump/Engine Oil Pipe	1 req	Avail to order Our Price: $472.65
5	008100625	Screw M6x16 Uni 5739/8g/Z	2 req	Avail to order Our Price: $140.00
6	004009759	This item is no longer available	1 req
7	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.17
8	004009738	This item is no longer available	1 req
9	008830207	Clamp	2 req	Avail to order Our Price: $11.93
10	008611002	NLA	2 req	*See Description
11	008700413	Lock Screw 4.2x12.7din798	2 req	Avail to order Our Price: $6.79
12	001501567	This item is no longer available	2 req
13	004009733	Power Steering Box/Reservoir P	1 req	Avail to order Our Price: $27.06
14	004009730	Power Steering ElbowPipe Nut	1 req	Avail to order Our Price: $121.81
15	004009729	This item is no longer available	1 req
16	004009741	Power Steering Column Assembly	1 req	Avail to order Our Price: $414.48
17	008700624	Screw 5931 6x1x20 8gZg	1 req	Current Stock: 10 Our Price: $2.00
18	008700623	Screw M6x55 Uni 59318g/Zd	1 req	Current Stock: 8 Our Price: $2.00
19	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
20	004009735	Pump/Power Steering Pipe	1 req	Avail to order Our Price: $314.59
21	004009732	Reservoir/Oil Pump Pipe	1 req	Avail to order Our Price: $66.73
22	008101034	Screw M10x130 Uni 5737 10k	1 req	Avail to order Our Price: $74.61
23	008401408	Annealed Copper Washer 21x14x1	2 req	Current Stock: 41 Our Price: $2.00
24	008401610	Annealed Copper Washer 16x22x0	1 req	Current Stock: 25 Our Price: $11.23
25	004009731	Power Steering Box Inlet Union	1 req	Avail to order Our Price: $81.26
26	004009728	Power Steering Outlet Union	1 req	Avail to order Our Price: $69.41
27	004009727	Power Steering Pump Outlet Uni	1 req	Avail to order Our Price: $121.81
28	008401408	Annealed Copper Washer 21x14x1	1 req	Current Stock: 41 Our Price: $2.00
29	008201212	Nut	4 req	Current Stock: 1 Our Price: $2.01
30	008401217	Washer12 Allen Screw5s	4 req	Current Stock: 3 Our Price: $6.79
31	008301219	Special Stud M12x20	4 req	Avail to order Our Price: $8.80
32	008700413	Lock Screw 4.2x12.7din798	2 req	Avail to order Our Price: $6.79
33	004009767	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
34	004009744	Power Steering Belt	2 req	Avail to order Our Price: $115.85
35	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.39
36	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
37	400422269	HOLLOW SCREW	1 req	Avail to order Our Price: $58.59
38	008100830	Screw M8x20 Uni 5739/8g/Z	6 req	Current Stock: 19 Our Price: $2.00
39	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $2.00
40	008401804	Annealed Copper Washer 18.2x30	2 req	Avail to order Our Price: $4.70
41	004009752	Power Steering Fuel Pump Adjus	1 req	Avail to order Our Price: $81.26
42	008300822	Stud M8x18 Uni 5911 8g Z	1 req	Avail to order Our Price: $26.35
43	004022676	ZF VANE POWER STEERING SYSTEM	1 req	Avail to order Our Price: $533.75
44	004009754	This item is no longer available	1 req
45	004009753	Power Steering Pump Attachment	1 req	Avail to order Our Price: $175.39
46	008830208	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
47	004009737	Power Steering	1 req	Avail to order Our Price: $4,383.27
48	004009743	Power Steering Pump Pulley	1 req	Avail to order Our Price: $1,146.51
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
