1972 Lamborghini Jarama USA Electrical System (6.10328.16)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 6.10328.16 - Electrical System

1972 Lamborghini Jarama USA Electrical System (6.10328.16)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001608038	Fusebox Guide Bulkhead	1 req	Avail to order Our Price: $154.58
2	008611401	Grommet 14x20x1.5 mm	3 req	Avail to order Our Price: $6.79
3	001603918	Relay	2 req	Avail to order Our Price: $380.50
4	001605819	Relay	2 req	Current Stock: 1 Our Price: $44.66
5	006775095	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
6	N10430103	HEXALOBULAR SOCKET	2 req	Current Stock: 21 Our Price: $2.00
7	008100824	Screw M8x75 Uni 5737-65a/F	2 req	Current Stock: 9 Our Price: $2.00
8	006107528	Valve Box Bracket	1 req	Avail to order Our Price: $181.15
9	001608165	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	006617030	Horn Relay	1 req	Avail to order Our Price: $35.31
11	008200811	M8 Uni 5589/8g/ZdNut	2 req	Avail to order Our Price: $6.79
12	004505565	This item is no longer available	2 req
13	008700506	Screw Knip 4.8x16din7971 Black	4 req	Current Stock: 4 Our Price: $2.00
14	008301004	Stud M10x45 Uni 59118gz	1 req	Avail to order Our Price: $35.19
15	001604482	Alternator Upper Bracket	1 req	Avail to order Our Price: $71.87
16	008100832	Screw M8x1x35uni 5738/8g/Z	2 req	Avail to order Our Price: $2.91
17	008201008	Nut	1 req	Current Stock: 2 Our Price: $2.00
18	001605520	Alternator	2 req	Avail to order Our Price: $1,505.82
19	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
20	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
21	008200810	M8x1 Uni5588 65/8gzd Nut	2 req	Avail to order Our Price: $2.00
22	001605758	Fusebox Fastening Knob	2 req	Avail to order Our Price: $11.26
23	001606629	Shielded Regulator	2 req	Avail to order Our Price: $88.71
24	001604956	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
25	001601336	This item is no longer available	1 req
26	001604647	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
27	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.39
28	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $26.80
29	008611401	Grommet 14x20x1.5 mm	2 req	Avail to order Our Price: $6.79
30	008100620	Screw M6x12 Uni 5739/5s/Z	4 req	Avail to order Our Price: $6.79
31	001602565	Governor Sheath	4 req	Avail to order Our Price: $169.44
32	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
33	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.17
34	001607910	Alternator Upper Bracket	1 req	Avail to order Our Price: $52.78
35	008101023	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
36	001604488	Alternator Lower Bracket	1 req	Avail to order Our Price: $78.87
37	N0152785	WASHER	8 req	Current Stock: 71 Our Price: $2.00
38	008200806	M8 Uni 5588/8g/Z Nut	8 req	Current Stock: 25 Our Price: $2.00
39	001607342	Long Battery/StarterMotor Wire	1 req	Avail to order Our Price: $213.95
40	001606173	Starter Motor Wire Pipette	2 req	Current Stock: 9 Our Price: $2.00
41	001604648	This item is no longer available	2 req
42	008300822	Stud M8x18 Uni 5911 8g Z	8 req	Avail to order Our Price: $26.35
43	001604645	Belt	2 req	Current Stock: 3 Our Price: $24.72
44	008201008	Nut	2 req	Current Stock: 2 Our Price: $2.00
45	001604745	Alternator Fan	2 req	Avail to order Our Price: $15.38
46	001604743	This item is no longer available	2 req
47	001608406	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
48	008401006	Washer 22x10.5x2.5 Uni 1734/5s	2 req	Current Stock: 1 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
