1972 Lamborghini Jarama USA Pedals (20.42)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 20.42 - Pedals

1972 Lamborghini Jarama USA Pedals (20.42)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003104592	Pump Pipe/Load Pipe	1 req	Avail to order Our Price: $69.41
2	008830204	Clamp	2 req	Avail to order Our Price: $10.06
3	003108012	This item is no longer available	1 req
4	002105757	Cylinder Oil Delivery Pipe	1 req	Avail to order Our Price: $1,102.85
5	008401007	Washer 21.5x10.4x2 Uni 6592/5s	2 req	Avail to order Our Price: $2.00
6	008201008	Nut	2 req	Current Stock: 2 Our Price: $2.00
7	004204692	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
8	004204472	Clutch /Brake Cylinder Fork	2 req	Avail to order Our Price: $33.55
9	008401806	Pedal Washer Vulkollan 4556084	5 req	Avail to order Our Price: $41.63
10	004204480	Clutch Pedal Return Spring	1 req	Avail to order Our Price: $80.51
11	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
12	N90612002	PAN HEAD BOLT	4 req	Current Stock: 37 Our Price: $2.00
13	004204476	Pedal Upper Cover	1 req	Avail to order Our Price: $76.19
14	004204475	Cover Seal	1 req	Avail to order Our Price: $7.31
15	004204676	Pedal Mount Pin	1 req	Avail to order Our Price: $60.02
16	008100828	Screw M8x45 Uni 5739/5s/Z	3 req	Avail to order Our Price: $2.00
17	008200806	M8 Uni 5588/8g/Z Nut	3 req	Current Stock: 25 Our Price: $2.00
18	008100829	Special Screw M8x15	1 req	Avail to order Our Price: $8.80
19	008700804	Screw 8x1.5x25 5931 8g Zg	6 req	Avail to order Our Price: $2.00
20	WHT001514	SPRING WASHER	6 req	Current Stock: 9 Our Price: $26.80
21	008101018	Screw M10x1.5x60 Uni5737/	2 req	Avail to order Our Price: $2.00
22	004205397	Brake Cylinder	1 req	Avail to order Our Price: $611.28
23	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
24	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
25	004204964	Brake Cylinder Cap	1 req	Avail to order Our Price: $72.76
26	008200902	M9x6 Special Nut	1 req	Avail to order Our Price: $11.93
27	004203415	Pin	2 req	Avail to order Our Price: $15.06
28	008820201	Split Pin 1.8x15 Uni 1336a	2 req	Current Stock: 19 Our Price: $7.60
29	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
30	004204479	Brake Pedal Return Spring	1 req	Avail to order Our Price: $80.51
31	008801802	Bushing 18x20x15 mm	4 req	Avail to order Our Price: $53.45
32	004204467	This item is no longer available	1 req
33	004201212	Brake Pedal Cover	2 req	Avail to order Our Price: $61.09
34	004204464	Clutch Pedal	1 req	Avail to order Our Price: $404.04
35	004204461	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
37	008581601	O-Ring E 18 Uni 7435-75	2 req	Avail to order Our Price: $2.91
38	004204473	Accelerator Pedal Bracket Pin	1 req	Avail to order Our Price: $24.31
38	004204511	Pedal Board Seal	1 req	Avail to order Our Price: $20.81
39	008801803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
40	008820201	Split Pin 1.8x15 Uni 1336a	2 req	Current Stock: 19 Our Price: $7.60
41	008800601	Bushing 6x10x10 mm	1 req	Avail to order Our Price: $23.93
42	004201154	Accelerator Pedal Fork Pin	1 req	Avail to order Our Price: $14.92
43	004204481	Accelerator Pedal Return Sprin	1 req	Avail to order Our Price: $80.51
44	004204448	Pedal Bracket	1 req	Avail to order Our Price: $210.22
45	004203128	Accelerator Pedal Cover Countach	1 req	Avail to order Our Price: $93.34
46	004205014	Accelerator Pedal	1 req	Avail to order Our Price: $445.79
47	004201153	Accelerator Pedal Wire Fork	1 req	Avail to order Our Price: $68.36
48	008100503	Screw M5x8 Uni 5739/8g	2 req	Avail to order Our Price: $2.00
49	N01118312	HEX.HEAD CLAMPING NUT	4 req	Avail to order Our Price: $2.17
50	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
51	008200806	M8 Uni 5588/8g/Z Nut	1 req	Current Stock: 25 Our Price: $2.00
52	004201651	Accelerator Wire Adjustment Sc	1 req	Avail to order Our Price: $961.64
53	004204691	Carburettor Wire	1 req	Avail to order Our Price: $329.22
54	003303845	NLA (No Longer Available)	1 req	*See Description
55	001300372	Accelerator Wire Pin	1 req	Avail to order Our Price: $24.31
56	001300188	Accelerator Wire Lock Fork	1 req	Current Stock: 1 Our Price: $236.31
57	003301857	Sheath Terminal	2 req	Avail to order Our Price: $5.08
58	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
59	008100619	Screw M6x35 Uni 5739/5s	1 req	Avail to order Our Price: $2.91
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
