1972 Lamborghini Jarama USA Brakes System (Pipelines) (17.10350.31.32)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $105.79
004504532	Belt Belt	Current Stock: 1 Our Price: $51.90
001604645	Belt Belt	Current Stock: 3 Our Price: $23.02
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $107.79

Brakes

PN	Item
003106765	Brake Pads Front - Jarama - Miura Front Brake Pads	Avail to order Our Price: $322.90
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $73.99
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $74.43

Drivetrain

PN	Item
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Avail to order Our Price: $45.47
002104719	Drive Plate Drive Plate	Avail to order Our Price: $813.44
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $26.45
001504611	Oil Filter Oil Filter	Avail to order Our Price: $474.63

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $474.94

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.36
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $12.67
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
001605819	Relay Relay	Current Stock: 1 Our Price: $41.54
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $14.87
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $6.69

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,090.33
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $93.84

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $63.98
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 17.10350.31.32 - Brakes System (Pipelines)

1972 Lamborghini Jarama USA Brakes System (Pipelines) (17.10350.31.32)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	N01118312	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 4 Our Price: $2.01
2	N01152427	WASHER	4 req	Avail to order Our Price: $2.00
3	003204603	Rear Three-Way Pipe/Rh Hose	1 req	Avail to order Our Price: $64.62
4	003101450	Three-Way Union	3 req	Avail to order Our Price: $98.22
5	003204602	Rear Three-Way Pipe/Lh Hose	1 req	Avail to order Our Price: $64.62
6	003201483	Rear Brake Hose	2 req	Current Stock: 1 Our Price: $143.78
7	008411004	Corrugated Washer	8 req	Avail to order Our Price: $2.65
8	003107923	Brake/Clutch Reservoir Clamp	1 req	Avail to order Our Price: $15.44
9	003103947	Brake Oil Reservoir	3 req	Avail to order Our Price: $56.69
10	N0211963	HEX.HEAD CLAMPING	3 req	Avail to order Our Price: $2.00
11	003107922	Brake/Clutch Reservoir Clamp	1 req	Avail to order Our Price: $19.88
12	008830204	Clamp	4 req	Avail to order Our Price: $9.37
13	003107709	NLA (No Longer Available)	1 req	*See Description
14	003108306	This item is no longer available	1 req
15	003108003	Lh Three-Way Hose	1 req	Avail to order Our Price: $65.19
16	008200903	3/8X24 Unf Special Nut	8 req	Avail to order Our Price: $6.37
17	003101453	Front Brake Hose	2 req	Current Stock: 1 Our Price: $106.58
18	003208304	This item is no longer available	1 req
19	008610802	Grommet 8x18x2 mm	5 req	Avail to order Our Price: $8.84
20	003105399	Clutch Cylinder LoadPipe	2 req	Avail to order Our Price: $11.79
21	003208011	This item is no longer available	8 req
22	003104639	This item is no longer available	37 req
23	008830401	Brake & Clutch Pump Pipe Clamp	2 req	Avail to order Our Price: $2.65
24	003107781	This item is no longer available	1 req
25	003107780	Connection To SafetyDevice	1 req	Avail to order Our Price: $30.53
26	003108307	Safety Device Pipe/Brake Boost	1 req	Avail to order Our Price: $18.73
27	003208305	Safety Device Pipe/Rear Brake	1 req	Avail to order Our Price: $65.19
28	003207999	This item is no longer available	1 req
29	003108002	This item is no longer available	1 req
30	003201449	Brake Light Check	1 req	Avail to order Our Price: $147.25
31	N91116801	WASHER	1 req	Current Stock: 1 Our Price: $8.40
32	008830205	Clamp	4 req	Avail to order Our Price: $7.37
33	003201511	Bolt	1 req	Avail to order Our Price: $49.97
34	003101513	Copper Washer 16.2x24x1	5 req	Avail to order Our Price: $2.00
35	003204607	Brake Booster Union Pipe	2 req	Avail to order Our Price: $110.94
36	003101486	Bolt	1 req	Avail to order Our Price: $34.89
37	003104604	Three-Way Pipe/BrakeBooster	1 req	Avail to order Our Price: $64.62
38	003108001	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
39	003208449	This item is no longer available	1 req
40	003101518	Check Valve	1 req	Avail to order Our Price: $189.43
41	008411005	Washer D.10.5 Uni 1751/F	6 req	Avail to order Our Price: $2.00
42	008100912	Screw 3/8x7/8 Unf 2a3f	6 req	Avail to order Our Price: $2.65
43	003201353	This item is no longer available	2 req
44	003208006	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
