Maintenance Parts:

Belts

PN Item Diagram
001604645 Belt
Belt
view diagram Current Stock: 3
Our Price: $20.93
Belt
004009744 Power Steering Belt
Power Steering Belt
view diagram Avail to order
Our Price: $97.90
004504532 Belt
Belt
view diagram Current Stock: 1
Our Price: $47.09
Belt
004608478 Belt
Belt
view diagram Avail to order
Our Price: $96.04

Brakes

PN Item Diagram
003106765 Brake Pads Front - Jarama - Miura
Front Brake Pads
view diagram Avail to order
Our Price: $260.65
Brake Pads Front - Jarama - Miura
003207720 E-Brake Pad - Espada - Jarama
Handbrake Pad
view diagram Current Stock: 4
Our Price: $67.05
E-Brake Pad - Espada - Jarama
003206764 Brake Pad Rear - Espada - Miura - Jarama - Sold Each
Rear Brake Pad
view diagram Avail to order
Our Price: $60.06

Drivetrain

PN Item Diagram
001501188 Oil Filter - Miura Countach Espada Jarama
Oil Filter Cartridge
view diagram Current Stock: 4
Our Price: $36.74
Oil Filter - Miura Countach Espada Jarama
002104719 Drive Plate
Drive Plate
view diagram Avail to order
Our Price: $738.46
002104088 Clutch Rod
Clutch Rod
view diagram Avail to order
Our Price: $24.01
001504611 Oil Filter
Oil Filter
Avail to order
Our Price: $429.84

Fuel-Air

PN Item Diagram
001320172 Air Filter - Carbureted
Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option
view diagram Avail to order
Our Price: $384.37
Air Filter - Carbureted

Fuses-Bulbs-Relays

PN Item Diagram
006617095 Bulb for license plate lamp
Bulb LAMP SV8,5-8 5W
view diagram Current Stock: 45
Our Price: $8.49
Bulb for license plate lamp
006617091 Bulb 21w tail light
21w Bulb
view diagram Current Stock: 6
Our Price: $10.46
Bulb 21w  tail light
006617094 Check Parts Manual for location
Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)
view diagram Current Stock: 77
Our Price: $7.65
Check Parts Manual for location
N0177522 bulb
Headlight LAMP 12V/3W
view diagram Current Stock: 10
Our Price: $2.00
bulb
001605819 Relay
Relay
view diagram Current Stock: 1
Our Price: $37.62
Relay
006617089 10 W Bulb
10 W Bulb
view diagram Avail to order
Our Price: $13.47
006617103 3w Bulb
3w Bulb
view diagram Avail to order
Our Price: $5.40

Gaskets

PN Item Diagram
001526482 Engine Gasket Set - Espada - Jarama
Engine Gasket Kit Espada - Jarama
Avail to order
Our Price: $877.35
Engine Gasket Set - Espada - Jarama
001526462 Grommet and Oil Seals Set - Espada - Jarama
Grommet and Oil Seals Set Espada - Jarama
Avail to order
Our Price: $75.46

Misc

PN Item Diagram
006715235 Windsc.Wip.Blade
Windsc.Wip.Blade
view diagram Avail to order
Our Price: $58.09
008200605R OE spec alternative for 008200605
M6 Ncm 70 Urama Simmon Nut
Avail to order
Our Price: $3.00
OE spec alternative for 008200605
900000381 NLA (No Longer Available)
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Avail to order
Our Price: $158.74
NLA (No Longer Available)
900000382 NLA
use PN 400093050D for USA replacement
Avail to order
Our Price: $158.74
NLA

Sensors

PN Item Diagram
001801333 NLA (No longer Available to order)
Oil & Coolant Temperature Thermometer
view diagram Avail to order
Our Price: $114.27
NLA (No longer Available to order)
Open All

Select Group and TAV

TAV: 13.10350.23 - Differential

1972 Lamborghini Jarama USA Differential (13.10350.23)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 002304837 Flange
2 req Avail to order
Our Price: $577.16
2 008546801 Bearing
2 req Avail to order
Our Price: $213.99
3 002304785 Planetary Shim Adjustment
2 req Avail to order
Our Price: $88.95
4 002304808 Differential Crown Wheel
2 req Avail to order
Our Price: $244.29
5 002305301 This item is no longer available 1 req
6 002305300 This item is no longer available 1 req
7 002304826 Differential Inner Box
1 req Avail to order
Our Price: $923.08
8 008411002 SEE PN WHT000768
12 req Avail to order
Our Price: $2.00
SEE PN WHT000768
9 008101017 Special Screw 10x1x22
12 req Avail to order
Our Price: $15.01
10 008253506 M35x1.5x52 Ring Nut
2 req Avail to order
Our Price: $28.11
M35x1.5x52 Ring Nut
11 008413502 Washer Skf Mb7
2 req Avail to order
Our Price: $5.50
12 008503502 Bearing
2 req Current Stock: 1
Our Price: $43.59
Bearing
13 008614501 LH Ring 45x60x7 mm
1 req Avail to order
Our Price: $57.81
LH  Ring 45x60x7 mm
14 008606901 Ring 70 mm Or
2 req Current Stock: 18
Our Price: $2.00
15 002304836 Flange
2 req Avail to order
Our Price: $142.66
16 002306465 CV Drive Shaft Flange
2 req Avail to order
Our Price: $339.39
17 008931601 Plug D.Cher 1006
2 req Avail to order
Our Price: $2.38
18 008614502 RH Ring 45x60x7 mm
1 req Avail to order
Our Price: $57.81
RH Ring 45x60x7 mm
19 008700610 Screw 6x22 Uni 5933/8g/Zd
16 req Avail to order
Our Price: $2.00
Screw 6x22 Uni 5933/8g/Zd
20 008410604 Washer 6x11 Rds6
16 req Avail to order
Our Price: $2.38
21 002313876 Satellite Adjusting Ring
2 req Avail to order
Our Price: $49.49
22 002302132 POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT
2 req *See Description
23 002302026 Differential Satellite Gear
2 req Avail to order
Our Price: $1,681.03
24 002302136 Differential Pinion Shim
1 req Avail to order
Our Price: $30.72
25 WHT003590 Elastic Pin 4x40
1 req Avail to order
Our Price: $10.34
Elastic Pin  4x40
26 002304835 Differential Adjustment Shim 6
1 req Avail to order
Our Price: $26.82
27 008544101 Bearing
1 req Avail to order
Our Price: $224.30
28 002304842 Spacer
1 req Avail to order
Our Price: $632.75
29 002304870 Differential Adjustment Shim 3
1 req Avail to order
Our Price: $26.82
30 008543401 Bearing
1 req Avail to order
Our Price: $169.52
31 01S409739A BEARING SUPPORTING
1 req Avail to order
Our Price: $158.65
BEARING SUPPORTING
32 01S409561 Bearing
1 req Avail to order
Our Price: $45.82
Bearing
33 002304830 Spacer
1 req Avail to order
Our Price: $13.80
34 008616001 NLA (No Longer Available)
1 req *See Description NLA (No Longer Available)
35 002305075 POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT
1 req *See Description
36 002307159 Differential Inlet Flange
1 req Avail to order
Our Price: $567.83
37 002302136 Differential Pinion Shim
1 req Avail to order
Our Price: $30.72
38 008613301 Felt Ring 33x48x10 mm
1 req Avail to order
Our Price: $14.45
39 002302137 Joint Centring Snap Ring
8 req Avail to order
Our Price: $213.99
40 008252502 M25x1.5 Special RingNut
1 req Avail to order
Our Price: $34.17

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
