1972 Jarama - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
001604645	BELT BELT	Current Stock: 3 Our Price: $24.80
004009744	POWER STEERING BELT POWER STEERING BELT	Avail to order Our Price: $115.81
004504532	BELT BELT	Current Stock: 1 Our Price: $55.72
004608478	BELT BELT	Avail to order Our Price: $113.58

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $456.30
003207720	E-BRAKE PAD ESPADA JARAMA E-BRAKE PAD ESPADA JARAMA	Avail to order Our Price: $76.00
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD	Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002104719	DRIVE PLATE DRIVE PLATE	Avail to order Our Price: $873.70
002104088	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $28.39
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item	Diagram
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION		Avail to order Our Price: $502.34
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $11.06
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	RELAY RELAY	Current Stock: 1 Our Price: $44.63
006617089	10 W BULB 10 W BULB	Avail to order Our Price: $15.95
006617103	3W BULB 3W BULB	Avail to order Our Price: $7.18

Gaskets

PN	Item	Diagram
001526482	ENGINE GASKET SET - ESPADA - JARAMA ENGINE GASKET KIT ESPADA - JARAMA		Avail to order Our Price: $1,153.39
001526462	GROMMET AND OIL SEALS SET - ESPADA - JARAMA GROMMET AND OIL SEALS SET ESPADA - JARAMA		Avail to order Our Price: $99.27

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.61

Misc

PN	Item
006715235	WINDSC.WIP.BLADE WINDSC.WIP.BLADE	Avail to order Our Price: $68.75
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT		Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 41.63 - Front And Rear Bumpers

1972 Lamborghini Jarama USA Front And Rear Bumpers (41.63)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006863001	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	006863008	This item is no longer available	1 req
3	006107563	This item is no longer available	1 req
4	006863003	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
5	006863009	This item is no longer available	1 req
6	006863001	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
7	006863010	This item is no longer available	1 req
8	006863013	This item is no longer available	1 req
9	008100505	SCREW M5X20 UNI 5739/5S	38 req	Avail to order Our Price: $0.50
10	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	38 req	Current Stock: 8 Our Price: $0.90
11	N10689901	HEX.NUT	38 req	Current Stock: 5 Our Price: $0.10
12	008100617	SCREW M6X18 UNI 57395S	4 req	Avail to order Our Price: $6.81
13	008410603	WASHER D.6.4 UNI 1751/ZD	4 req	Avail to order Our Price: $0.10
14	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $0.30
15	006108210	This item is no longer available	2 req
16	008100830	SCREW M8X20 UNI 5739/8G/Z	6 req	Current Stock: 19 Our Price: $0.50
17	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $0.50
18	N90179103	WASHER	6 req	Current Stock: 5 Our Price: $1.80
19	006107564	This item is no longer available	1 req
20	006863015	This item is no longer available	1 req
21	006863004	This item is no longer available	1 req
22	006863018	This item is no longer available	1 req
23	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $1.80
24	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.50
25	008100830	SCREW M8X20 UNI 5739/8G/Z	2 req	Current Stock: 19 Our Price: $0.50
26	008200806	M8 UNI 5588/8G/Z NUT	4 req	Current Stock: 25 Our Price: $0.40
27	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $1.80
28	006107899	REAR BUMPER RH BRACKET	1 req	Avail to order Our Price: $51.44
29	006107898	REAR BUMPER LH BRACKET	1 req	Avail to order Our Price: $51.44
30	006613015	FRONT PLATE CARR.	1 req	Avail to order Our Price: $84.40
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
