1972 Lamborghini Jarama USA Steering Control (22.43)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 22.43 - Steering Control

1972 Lamborghini Jarama USA Steering Control (22.43)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004301790	NLA (No Longer Available)	1 req	*See Description
2	008251801	M18x1.5x28 Self-Locking Ring N	1 req	Avail to order Our Price: $42.05
3	008401807	Washer 18.5x30x2.5	1 req	Avail to order Our Price: $23.93
4	004306392	This item is no longer available	1 req
5	004301383	NLA (No Longer Available)	1 req	*See Description
6	004313277	LIGHT / HORN SWITCH	1 req	Avail to order Our Price: $1,801.41
7	008860701	Tab 5x7.5 Unim 99	1 req	Avail to order Our Price: $8.80
8	004302666	This item is no longer available	1 req
9	004301397	Indicator Return Lever Pin	1 req	Avail to order Our Price: $27.73
10	004301424	Joint	1 req	Avail to order Our Price: $5,246.66
11	008100621	Screw M6x20 Uni 5739/5s/Z	3 req	Avail to order Our Price: $2.00
12	WHT001197A	WASHER	3 req	Current Stock: 2 Our Price: $2.00
13	008700406	Screw 3/16x15	2 req	Avail to order Our Price: $2.00
14	004301408	This item is no longer available	1 req
15	004301183	Steering Bracket	1 req	Avail to order Our Price: $670.33
16	008101021	Screw M10x1.5x125 Uni 5737	2 req	Avail to order Our Price: $21.40
17	008401006	Washer 22x10.5x2.5 Uni 1734/5s	4 req	Current Stock: 1 Our Price: $2.00
18	008201008	Nut	2 req	Current Stock: 2 Our Price: $2.00
19	008252503	M25x1.5x38 Self-Locking Ring N	1 req	Avail to order Our Price: $3.64
20	008402504	Washer 25.5x33x2.5	1 req	Current Stock: 4 Our Price: $23.93
21	008575001	O-Ring I 47 Uni 3654	2 req	Current Stock: 10 Our Price: $2.00
22	008502503	Bearing	2 req	Avail to order Our Price: $158.78
23	004301390	Spacer	1 req	Avail to order Our Price: $88.26
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
