Maintenance Parts:

Belts

PN Item Diagram
001604645 Belt
Belt
view diagram Current Stock: 3
Our Price: $16.41
Belt
004608478 Belt
Belt
view diagram Avail to order
Our Price: $91.56
004009744 Power Steering Belt
Power Steering Belt
view diagram Avail to order
Our Price: $96.97
004504532 Belt
Belt
view diagram Current Stock: 1
Our Price: $44.94
Belt

Brakes

PN Item Diagram
003206764 Brake Pad Rear - Espada - Miura - Jarama - Sold Each
Rear Brake Pad
view diagram Avail to order
Our Price: $57.42
003207720 E-Brake Pad - Espada - Jarama
Handbrake Pad
view diagram Current Stock: 4
Our Price: $64.03
E-Brake Pad - Espada - Jarama
003106765 Brake Pads Front - Jarama - Miura
Front Brake Pads
view diagram Avail to order
Our Price: $249.32
Brake Pads Front - Jarama - Miura

Drivetrain

PN Item Diagram
001504611 Oil Filter
Oil Filter
Avail to order
Our Price: $411.19
001501188 Oil Filter - Miura Countach Espada Jarama
Oil Filter Cartridge
view diagram Current Stock: 1
Our Price: $35.08
Oil Filter - Miura Countach Espada Jarama
002104088 Clutch Rod
Clutch Rod
view diagram Avail to order
Our Price: $22.98
002104719 Drive Plate
Drive Plate
view diagram Avail to order
Our Price: $703.96

Fuel-Air

PN Item Diagram
001320172 Air Filter - Carbureted
Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option
view diagram Avail to order
Our Price: $367.37
Air Filter - Carbureted

Fuses-Bulbs-Relays

PN Item Diagram
001605819 Relay
Relay
view diagram Current Stock: 1
Our Price: $37.34
Relay
006617089 10 W Bulb
10 W Bulb
view diagram Avail to order
Our Price: $12.91
006617091 Bulb 21w tail light
21w Bulb
view diagram Current Stock: 7
Our Price: $10.37
Bulb 21w  tail light
006617094 Check Parts Manual for location
Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)
view diagram Current Stock: 77
Our Price: $7.60
Check Parts Manual for location
006617095 Bulb for license plate lamp
Bulb LAMP SV8,5-8 5W
view diagram Current Stock: 45
Our Price: $8.45
Bulb for license plate lamp
006617103 3w Bulb
3w Bulb
view diagram Avail to order
Our Price: $5.35
N0177522 bulb headlight
Headlight LAMP 12V/3W
view diagram Current Stock: 11
Our Price: $2.00
bulb headlight

Gaskets

PN Item Diagram
001526462 Grommet and Oil Seals Set - Espada - Jarama
Grommet and Oil Seals Set Espada - Jarama
Avail to order
Our Price: $74.89
001526482 Engine Gasket Set - Espada - Jarama
Engine Gasket Kit Espada - Jarama
Avail to order
Our Price: $870.74
Engine Gasket Set - Espada - Jarama

Misc

PN Item Diagram
006715235 Windsc.Wip.Blade
Windsc.Wip.Blade
view diagram Avail to order
Our Price: $55.48
008200605R OE spec alternative for 008200605
M6 Ncm 70 Urama Simmon Nut
Avail to order
Our Price: $3.00
OE spec alternative for 008200605
900000381 BATTERY CHARGER ROW BC - EURO
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Current Stock: 3
Our Price: $154.40
BATTERY CHARGER ROW BC - EURO
900000382 NLA
use PN 400093050D for USA replacement
Avail to order
Our Price: $154.40
NLA

Sensors

PN Item Diagram
001801333 NLA (No longer Available to order)
Oil & Coolant Temperature Thermometer
view diagram Avail to order
Our Price: $113.33
NLA (No longer Available to order)
Open All

Select Group and TAV

TAV: 5.10400.15 - Oil Pump And System

1972 Lamborghini Jarama USA Oil Pump And System (5.10400.15)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
1 001507368 Engine Output Shaft
1 req Avail to order
Our Price: $1,095.57
2 008860502 Tab 5x5x18
1 req Current Stock: 9
Our Price: $2.00
Tab 5x5x18
3 008860604 This item is no longer available 1 req
4 008300615 Stud 6x22 Uni 5911/8g/Z
2 req Avail to order
Our Price: $19.63
5 001504903 Oil Pump Cover
1 req Avail to order
Our Price: $180.42
6 008522203 Bearing
1 req Avail to order
Our Price: $38.79
7 001504487 Idle Gear Pin
1 req Avail to order
Our Price: $59.40
8 001504499 Idle Gear
1 req Avail to order
Our Price: $113.80
9 008602304 O-RING
2 req Current Stock: 1
Our Price: $7.56
O-RING
10 008300612 POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT
2 req *See Description
11 N01152427 WASHER
2 req Current Stock: 18
Our Price: $2.00
WASHER
12 008200605 NLA SEE PN 008200605R for OE spec alternative
2 req *See Description NLA SEE PN 008200605R for OE spec alternative
13 WHT001197A WASHER
21 req Avail to order
Our Price: $2.00
WASHER
14 008100615 Screw M6x50 Uni 5737/8g
1 req Avail to order
Our Price: $5.59
15 008410603 Washer D.6.4 Uni 1751/Zd
2 req Current Stock: 24
Our Price: $2.00
Washer D.6.4 Uni 1751/Zd
16 008100625 Screw M6x16 Uni 5739/8g/Z
2 req Avail to order
Our Price: $2.00
17 001508485 Pump/Engine Oil Pipe
1 req Avail to order
Our Price: $344.71
18 N01100637 HEX.NUT
6 req Avail to order
Our Price: $2.00
HEX.NUT
19 008300610 Stud 6x1x16 8g Uni5911 Z.
4 req Avail to order
Our Price: $23.92
20 WHT003079 Reference Pin 8h7x6.25x10
4 req Avail to order
Our Price: $29.79
21 001504500 Drive Gear
1 req Avail to order
Our Price: $116.08
22 001500898 Pump Seal
1 req Current Stock: 1
Our Price: $27.46
Pump Seal
23 001508498 This item is no longer available 1 req
24 008700618 Screw M6x50 Uni 5931/8g/B
1 req Avail to order
Our Price: $2.00
25 008700619 Screw M6x80 Uni 5931/8g/Z
1 req Avail to order
Our Price: $5.69
26 001508565 Oil Pressure Sender/Transmitter - Jaeger
1 req Avail to order
Our Price: $331.93
Oil Pressure Sender/Transmitter - Jaeger
27 008402003 Washer
1 req Avail to order
Our Price: $13.05
28 008502001 Bearing
1 req Avail to order
Our Price: $36.27
Bearing
29 008613002 Oil Seal 30x40x7 mm
1 req Avail to order
Our Price: $3.40
30 004504287 Oil Pump Flange Seal
1 req Avail to order
Our Price: $8.25
Oil Pump Flange Seal
31 001506541 Bushing
1 req Avail to order
Our Price: $59.02
33 001507602 Oil Delivery Pipe Set
1 req Avail to order
Our Price: $41.49
33 008402401 Copper Washer D.24.5x35x1
1 req Avail to order
Our Price: $2.00
Copper Washer D.24.5x35x1
34 001507462 This item is no longer available 1 req
35 001504611 Oil Filter
1 req Avail to order
Our Price: $411.19
36 001503755 Oil Pressure Valve Plug
1 req Avail to order
Our Price: $22.47
Oil Pressure Valve Plug
37 008401804 Annealed Copper Washer 18.2x30
1 req Current Stock: 2
Our Price: $3.87
Annealed Copper Washer 18.2x30
38 001500927 Oil Pressure Valve Spring
1 req Avail to order
Our Price: $13.10
Oil Pressure Valve Spring
39 001500914 Oil Pressure Valve Piston
1 req Avail to order
Our Price: $74.41
Oil Pressure Valve Piston
40 001501128 Oil Filter Seal
1 req Avail to order
Our Price: $16.62
Oil Filter Seal
41 008700608 Screw 6x40 Uni 5931/8g/Z
4 req Avail to order
Our Price: $2.00
42 008700609 Screw 6x45 Uni 5931/8g/Zd
2 req Avail to order
Our Price: $2.00
43 008100616 Screw M6x16 Uni 5739/5s/Z
6 req Avail to order
Our Price: $2.00
44 001507909 Alternator & Compressor Drive
1 req Avail to order
Our Price: $161.31
45 008401801 Tempered Flat Washer18x30x2 C4
1 req Avail to order
Our Price: $22.28
46 008251801 M18x1.5x28 Self-Locking Ring N
1 req Avail to order
Our Price: $35.15
47 001501189 Over Pressure Valve Seat
1 req Avail to order
Our Price: $345.65
48 008911101 Valve Ball
1 req Avail to order
Our Price: $5.69
49 001501190 Oil Safety Valve Spring
1 req Current Stock: 3
Our Price: $8.76
Oil Safety Valve Spring
50 001501188 Oil Filter - Miura Countach Espada Jarama
1 req Current Stock: 1
Our Price: $35.08
Oil Filter - Miura Countach Espada Jarama

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
