1972 Lamborghini Jarama USA Oil Pump And System (5.15)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 5.15 - Oil Pump And System

1972 Lamborghini Jarama USA Oil Pump And System (5.15)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001508565	NLA (No Longer Available)	1 req	*See Description
2	001501481	Oil Pressure Actuator Flange	1 req	Avail to order Our Price: $972.05
3	001504625	Pump Oil Delivery Pipe	1 req	Avail to order Our Price: $499.41
4	008200605	Simmon Nut for urama	4 req	Current Stock: 50 Our Price: $3.06
5	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
6	008300614	Stud M6x18 Uni 5911 8g/Zd	4 req	Avail to order Our Price: $8.70
7	008602304	O-RING	1 req	Avail to order Our Price: $10.11
8	001506588	This item is no longer available	1 req
9	008860502	Tab 5x5x18	1 req	Current Stock: 9 Our Price: $2.00
10	008860604	This item is no longer available	1 req
11	008300615	Stud 6x22 Uni 5911/8g/Z	2 req	Avail to order Our Price: $23.56
12	001504903	Oil Pump Cover	1 req	Avail to order Our Price: $223.64
13	008522203	Bearing	1 req	Avail to order Our Price: $46.44
14	001504500	Drive Gear	1 req	Avail to order Our Price: $143.88
15	001504487	Idle Gear Pin	1 req	Avail to order Our Price: $81.46
16	001504499	Idle Gear	1 req	Avail to order Our Price: $3,210.43
17	001500898	Pump Seal	1 req	Avail to order Our Price: $32.88
18	001506542	This item is no longer available	1 req
19	WHT001197A	WASHER	9 req	Current Stock: 2 Our Price: $2.00
20	008100615	Screw M6x50 Uni 5737/8g	1 req	Avail to order Our Price: $6.79
21	008402003	Washer	1 req	Avail to order Our Price: $15.59
22	008502001	Bearing	1 req	Current Stock: 2 Our Price: $43.33
23	008613002	Oil Seal 30x40x7 mm	1 req	Avail to order Our Price: $4.10
24	004504287	Oil Pump Flange Seal	1 req	Avail to order Our Price: $10.14
25	001506541	Bushing	1 req	Avail to order Our Price: $73.13
26	001506587	Alternator & Compressor Drive	1 req	Avail to order Our Price: $199.04
27	006401801	This item is no longer available	1 req
28	008251801	M18x1.5x28 Self-Locking Ring N	1 req	Avail to order Our Price: $42.05
29	N01100637	HEX.NUT	6 req	Current Stock: 18 Our Price: $2.00
30	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
31	WHT003165	TAP END STUD	4 req	Current Stock: 3 Our Price: $2.00
32	WHT003079	Reference Pin 8h7x6.25x10	4 req	Avail to order Our Price: $35.64
33	008700608	Screw 6x40 Uni 5931/8g/Z	6 req	Avail to order Our Price: $2.00
34	008700609	Screw 6x45 Uni 5931/8g/Zd	2 req	Avail to order Our Price: $2.00
35	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
36	008100616	Screw M6x16 Uni 5739/5s/Z	6 req	Avail to order Our Price: $2.00
37	001504614	Oil Delivery Pipe Assembly	1 req	Avail to order Our Price: $144.02
38	008402401	Copper Washer D.24.5x35x1	1 req	Avail to order Our Price: $17.15
39	008602003	Ring 21 mm Or	1 req	Avail to order Our Price: $2.00
40	001504611	Oil Filter Case	1 req	Avail to order Our Price: $509.90
41	001503755	Oil Pressure Valve Plug	1 req	Avail to order Our Price: $27.81
42	008401804	Annealed Copper Washer 18.2x30	1 req	Avail to order Our Price: $4.70
43	001500917	This item is no longer available	1 req
44	001500914	Oil Pressure Valve Piston	1 req	Avail to order Our Price: $92.14
45	001504634	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
46	001500925	Cartridge Filter Spring	1 req	Current Stock: 3 Our Price: $29.52
47	001501188	Oil Filter - Miura Countach Espada Jarama	1 req	Current Stock: 6 Our Price: $48.16
48	001501128	Oil Filter Seal	1 req	Current Stock: 1 Our Price: $22.01
49	001501189	Over Pressure Valve Seat	1 req	Avail to order Our Price: $459.27
50	008911101	Valve Ball	1 req	Avail to order Our Price: $6.87
51	001501190	Oil Safety Valve Spring	1 req	Current Stock: 3 Our Price: $10.74
52	001507552	Oil Delivery Flange Seal	1 req	Avail to order Our Price: $3.80
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
