TAV: 40.61 - Heater

1972 Lamborghini Jarama USA Heater (40.61)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006107277	Windscreen Air Manifold	4 req	Avail to order Our Price: $14.84
2	006107508	This item is no longer available	1 req
3	006106823	This item is no longer available	1 req
4	006106817	This item is no longer available	1 req
5	N01152221	WASHER	12 req	Current Stock: 3 Our Price: $2.00
6	008700407	Screw M4x14 Uni 6108/8g/Z	6 req	Avail to order Our Price: $2.91
7	008200401	M4 Uni 5587/5s/Z	6 req	Avail to order Our Price: $2.00
8	006107109	This item is no longer available	1 req
9	006106846	Heater Manifold Flap	1 req	Avail to order Our Price: $9.62
10	006106903	Manifold Flap Pin	1 req	Avail to order Our Price: $11.11
11	006105649	This item is no longer available	1 req
12	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
13	008820101	Split Pin 1.8x12 Uni 1336a	2 req	Avail to order Our Price: $2.91
14	008700302	Screw 3x5 Uni 6108/5s/Z	2 req	Avail to order Our Price: $2.91
15	N0211963	HEX.HEAD CLAMPING	5 req	Avail to order Our Price: $2.00
16	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	7 req	Current Stock: 8 Our Price: $2.00
17	008700305	Lock Screw 3.5x16din7982/C	2 req	Avail to order Our Price: $2.91
18	004507150	This item is no longer available	1 req
19	004507022	This item is no longer available	1 req
20	008830205	Clamp	6 req	Avail to order Our Price: $7.91
21	006104760	This item is no longer available	1 req
22	006103239	TAP	1 req	Avail to order Our Price: $830.73
23	006104758	This item is no longer available	1 req
24	004506794	Heated Air Manifold Seal	1 req	Avail to order Our Price: $51.74
25	006106793	This item is no longer available	1 req
26	004506763	Evaporator Battery &Motor Brac	1 req	Avail to order Our Price: $59.64
27	006105426	Heater Rh Motor Manifold	1 req	Avail to order Our Price: $48.90
28	006105474	Ignition Fan	1 req	Avail to order Our Price: $30.57
29	006107031	NLA (No Longer Available)	1 req	*See Description
30	006105599	Ignition Fan	1 req	Avail to order Our Price: $31.61
31	006105439	Heater Lh Motor Manifold	1 req	Avail to order Our Price: $48.90
32	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
33	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	8 req	Current Stock: 8 Our Price: $2.00
34	N0211963	HEX.HEAD CLAMPING	8 req	Avail to order Our Price: $2.00
35	008921201	Mount Rocam F.81011/D.2001	4 req	Avail to order Our Price: $26.69
36	008410403	Washer D.4.3 Uni 1751/Z	8 req	Avail to order Our Price: $7.60
37	008200401	M4 Uni 5587/5s/Z	8 req	Avail to order Our Price: $2.00
38	006107167	Heater/Condenser Motor Bracket	2 req	Avail to order Our Price: $4.18
39	006107032	Heater Motor BracketClamp	2 req	Avail to order Our Price: $22.74
40	N01020717	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
41	N10689901	HEX.NUT	4 req	Current Stock: 5 Our Price: $2.00
42	008410502	Washer D.5.3 Uni 1751/Zd	4 req	Current Stock: 33 Our Price: $2.00
43	006106852	This item is no longer available	2 req
44	006106824	This item is no longer available	1 req
45	004506860	Expansion Valve	1 req	Avail to order Our Price: $105.24
46	004506859	This item is no longer available	1 req
47	004507017	This item is no longer available	1 req
48	006104759	This item is no longer available	1 req
49	008611002	NLA	2 req	*See Description
50	004506959	Condenser/Heater Battery Unit	1 req	Avail to order Our Price: $928.84
51	006107034	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
