1972 Lamborghini Jarama USA Engine And Luggage Comp. Hoods (38.10228.59)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.01
004608478	Belt Belt	Avail to order Our Price: $110.33
004504532	Belt Belt	Current Stock: 1 Our Price: $54.12
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $112.42

Brakes

PN	Item
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $76.40
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003106765	Brake Pads Front - Jarama - Miura Front Brake Pads	Avail to order Our Price: $331.45

Drivetrain

PN	Item
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Avail to order Our Price: $46.75
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $27.59
002104719	Drive Plate Drive Plate	Avail to order Our Price: $848.33
001504611	Oil Filter Oil Filter	Avail to order Our Price: $494.99

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $487.51

Fuses-Bulbs-Relays

PN	Item
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
001605819	Relay Relay	Current Stock: 1 Our Price: $43.32
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $13.10
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $6.92
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.51

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,119.19
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $96.32

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $66.73
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $145.52

Open All

Select Group and TAV

< Previous Next >

TAV: 38.10228.59 - Engine And Luggage Comp. Hoods

1972 Lamborghini Jarama USA Engine And Luggage Comp. Hoods (38.10228.59)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	006759110	Engine Bonnet Lock E/J	1 req	Avail to order Our Price: $92.74
1	006810010	This item is no longer available	1 req
2	006859005	This item is no longer available	2 req
3	008100618	Screw M6x20 Uni 5739/8g/Zd	4 req	Current Stock: 44 Our Price: $0.30
4	006859033	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
5	006859032	Engine Cover Rh Spring	1 req	Avail to order Our Price: $140.44
6	006859036	This item is no longer available	2 req
7	006859011	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
8	008100618	Screw M6x20 Uni 5739/8g/Zd	4 req	Current Stock: 44 Our Price: $0.30
9	WHT002961	WASHER	4 req	Current Stock: 39 Our Price: $0.41
10	006759111	Left Engine Bonnet Lock E/J	1 req	Avail to order Our Price: $92.74
11	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $0.35
12	WHT002961	WASHER	2 req	Current Stock: 39 Our Price: $0.41
13	006859014	This item is no longer available	1 req
14	006859015	This item is no longer available	3 req
15	006859016	This item is no longer available	1 req
16	006859017	This item is no longer available	1 req
17	006859019	This item is no longer available	1 req
18	006859021	This item is no longer available	1 req
19	N10689901	HEX.NUT	2 req	Current Stock: 5 Our Price: $0.08
20	WHT001187	Washer 10x5.3x1 Uni 6952 Cat-A	2 req	Current Stock: 8 Our Price: $0.84
21	006405010	Front Bonnet Handle	1 req	Avail to order Our Price: $110.93
22	008820102	Split Pin 1.3x20 Uni 1336a	2 req	Avail to order Our Price: $2.76
23	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $1.64
24	008201011	M10 Uni 5589-65/8g Nut	2 req	Avail to order Our Price: $20.73
25	008201012	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	6 req	*See Description
26	006859025	This item is no longer available	4 req
27	006859026	This item is no longer available	2 req
28	006859030	This item is no longer available	1 req
29	006810020	Boot Lid	1 req	Avail to order Our Price: $1,878.55
30	006859040	Trunk Lock Hook	1 req	Avail to order Our Price: $23.42
31	WHT002961	WASHER	2 req	Current Stock: 39 Our Price: $0.41
32	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $0.07
33	008100617	Screw M6x18 Uni 57395s	2 req	Avail to order Our Price: $6.56
33	006859042	Bonnet Lock	1 req	Avail to order Our Price: $134.07
34	006859041	This item is no longer available	1 req
36	008100617	Screw M6x18 Uni 57395s	2 req	Avail to order Our Price: $6.56
37	008410604	Washer 6x11 Rds6	2 req	Avail to order Our Price: $2.76
38	WHT002961	WASHER	2 req	Current Stock: 39 Our Price: $0.41
39	006859001	This item is no longer available	1 req
40	006859045	Boot Lid Hinge	2 req	Avail to order Our Price: $170.71
41	WHT002961	WASHER	4 req	Current Stock: 39 Our Price: $0.41
42	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $0.07
43	008100617	Screw M6x18 Uni 57395s	4 req	Avail to order Our Price: $6.56
44	006708050	This item is no longer available	1 req
45	006808010	This item is no longer available	1 req
46	006808011	This item is no longer available	1 req
47	006859046	This item is no longer available	2 req
48	WHT002961	WASHER	4 req	Current Stock: 39 Our Price: $0.41
49	008410604	Washer 6x11 Rds6	4 req	Avail to order Our Price: $2.76
50	008100616	Screw M6x16 Uni 5739/5s/Z	4 req	Avail to order Our Price: $0.16
51	006613014	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
52	006107562	Air Vent Upper Frame	1 req	Avail to order Our Price: $229.60
53	006108019	Radiator Air Vent Frame	1 req	Avail to order Our Price: $152.82
54	006108020	Air Vent Lower Frame	1 req	Avail to order Our Price: $521.82
55	006859035	Spring Lock Plate	2 req	Avail to order Our Price: $66.57
56	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.44
57	008100826	Screw M8x16 Uni 5739/8g/Z	2 req	Avail to order Our Price: $0.45
58	006859034	Spring Fix.Bracket	1 req	Avail to order Our Price: $12.75
59	008410502	Washer D.5.3 Uni 1751/Zd	1 req	Current Stock: 33 Our Price: $0.08
60	008100503	Screw M5x8 Uni 5739/8g	1 req	Avail to order Our Price: $0.14
61	008100809	Screw M8x22 Uni 5739/8g/Zd	2 req	Current Stock: 6 Our Price: $0.26
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
