1972 Lamborghini Jarama USA Clutch (10.21)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $110.33
004504532	Belt Belt	Current Stock: 1 Our Price: $54.12
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $112.42
001604645	Belt Belt	Current Stock: 3 Our Price: $24.01

Brakes

PN	Item
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $76.40
003106765	Brake Pads Front - Jarama - Miura Front Brake Pads	Avail to order Our Price: $331.45
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95

Drivetrain

PN	Item
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Avail to order Our Price: $46.75
002104719	Drive Plate Drive Plate	Avail to order Our Price: $848.33
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $27.59
001504611	Oil Filter Oil Filter	Avail to order Our Price: $494.99

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $487.51

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.09
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.51
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $6.92
001605819	Relay Relay	Current Stock: 1 Our Price: $43.32

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,119.19
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $96.32

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $66.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $145.52

Open All

Select Group and TAV

< Previous Next >

TAV: 10.21 - Clutch

1972 Lamborghini Jarama USA Clutch (10.21)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008802003	Bushing 20x23x25 mm	2 req	Avail to order Our Price: $26.92
2	002101652	Clutch Control Fork	1 req	Avail to order Our Price: $726.07
3	008900801	Elastic Pin 8x32	2 req	Avail to order Our Price: $3.51
4	002101822	Clutch Fork Drive Shaft	1 req	Avail to order Our Price: $187.11
5	002102532	Clutch Lever Spring	1 req	Avail to order Our Price: $23.64
6	002102530	Clutch Shaft ControlLever	1 req	Avail to order Our Price: $190.84
7	WHT000771	SPRING LOCK WASHER	1 req	Current Stock: 10 Our Price: $1.24
8	008100836	Special Screw M8x25	1 req	Avail to order Our Price: $8.50
9	410721493	Brake Pipe Protection Rubber W	2 req	Avail to order Our Price: $56.42
10	003105378	NLA	1 req	*See Description
11	008300825	Stud M8x22 Uni 5911 10k Z	2 req	Avail to order Our Price: $14.82
12	002100254	NLA (No Longer Available)	1 req	*See Description
13	N91116801	WASHER	1 req	Current Stock: 1 Our Price: $8.71
14	002101961	Union Male-Male	1 req	Avail to order Our Price: $31.39
15	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $25.98
16	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $0.38
17	002104088	Clutch Rod	1 req	Avail to order Our Price: $27.59
18	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.56
19	002104086	Clutch Gear Fork	1 req	Avail to order Our Price: $46.22
20	410609789	Pin	1 req	Avail to order Our Price: $31.94
21	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	1 req	Current Stock: 5 Our Price: $0.57
22	008820201	Split Pin 1.8x15 Uni 1336a	1 req	Current Stock: 19 Our Price: $7.38
23	008613502	Oil Seal 35x47x7 mm	1 req	Current Stock: 9 Our Price: $10.63
24	008950607	This item is no longer available	2 req
25	002401842	Gearbox Front Cover Seal	1 req	Avail to order Our Price: $26.55
26	002401837	Gearbox Front Cover	1 req	Avail to order Our Price: $450.26
27	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $0.44
28	008100837	Screw 8x1.25x19uni4721 10k	2 req	Avail to order Our Price: $26.92
29	002104716	Sleeve	1 req	Avail to order Our Price: $348.13
30	002104715	This item is no longer available	1 req
31	002104712	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
32	002104719	Drive Plate	1 req	Avail to order Our Price: $848.33
33	WHT003078	Reference Pin 8h7x16C40	1 req	Avail to order Our Price: $17.80
34	008850807	Dowel 8x12.842	3 req	Avail to order Our Price: $19.54
35	001404724	This item is no longer available	1 req
36	008300825	Stud M8x22 Uni 5911 10k Z	6 req	Avail to order Our Price: $14.82
37	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $0.44
38	N01100845	HEX.NUT	6 req	Current Stock: 16 Our Price: $2.01
39	008100830	Screw M8x20 Uni 5739/8g/Z	6 req	Current Stock: 19 Our Price: $0.47
40	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $0.44
41	008100838	Special Screw M8x25	8 req	Avail to order Our Price: $15.61
42	410141179	RETAINING PART	4 req	Avail to order Our Price: $66.11
43	008830112	Pipe Clamp	2 req	Avail to order Our Price: $122.41
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
