TAV: 4.10100.14 - Crankshaft And Pistons

1972 Lamborghini Jarama USA Crankshaft And Pistons (4.10100.14)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001402908	Upper Segment	12 req	Avail to order Our Price: $144.08
2	001402907	Lower Segment	12 req	Avail to order Our Price: $109.47
3	001402906	Oil Scraper	12 req	Avail to order Our Price: $75.88
4	001408017	Piston D.82 Fino Alla 400	12 req	Avail to order Our Price: $527.07
5	001400398	Pin 19x66x11	12 req	Avail to order Our Price: $190.14
6	008572101	O-Ring I 20 Uni 3654	24 req	Avail to order Our Price: $0.09
7	001403519	This item is no longer available	12 req
8	001413206	Bushing	12 req	Avail to order Our Price: $117.14
9	001400359	This item is no longer available	24 req
10	001404419	This item is no longer available	24 req
11	008820201	Split Pin 1.8x15 Uni 1336a	24 req	Current Stock: 19 Our Price: $7.08
12	001419898	Bushing	24 req	Avail to order Our Price: $70.69
13	001403520	This item is no longer available	12 req
14	001400802	This item is no longer available	12 req
15	07M109381	Snap Ring I 35 Uni 3654	1 req	Current Stock: 35 Our Price: $1.72
16	410109264	Bearing	1 req	Avail to order Our Price: $24.62
17	001407338	Espada Crankshaft	1 req	Avail to order Our Price: $31,645.53
18	008860801	Tab 8x7x20 Unim 92	1 req	Avail to order Our Price: $11.09
19	001401245	SEE PN 07M105531A AND 07M105532	1 req	Avail to order Our Price: $32.49
20	001407354	Front Crankshaft Gear	1 req	Avail to order Our Price: $252.33
21	001401245	SEE PN 07M105531A AND 07M105532	1 req	Avail to order Our Price: $32.49
22	001400248	Bushing	1 req	Avail to order Our Price: $50.18
23	001400244	Bushing	1 req	Avail to order Our Price: $50.18
24	001400236	Bushing	5 req	Current Stock: 1 Our Price: $181.56
25	001400236	Bushing	5 req	Current Stock: 1 Our Price: $181.56
26	001400243	Bushing	1 req	Avail to order Our Price: $47.61
27	001400239	Bushing	1 req	Avail to order Our Price: $50.18
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
