1972 Jarama - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item
004608478	BELT BELT	Avail to order Our Price: $100.78
004504532	BELT BELT	Current Stock: 1 Our Price: $49.39
001604645	BELT BELT	Current Stock: 1 Our Price: $21.96
004009744	POWER STEERING BELT POWER STEERING BELT	Avail to order Our Price: $102.76

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $494.83
003207720	E-BRAKE PAD ESPADA JARAMA E-BRAKE PAD ESPADA JARAMA	Avail to order Our Price: $82.36
003206764	BRAKE PAD REAR - ESPADA - MIURA - JARAMA - SOLD EACH REAR BRAKE PAD	Avail to order Our Price: $85.26

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $25.41
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $589.94

Drivetrain

PN	Item
002104719	DRIVE PLATE DRIVE PLATE	Avail to order Our Price: $774.98
002104088	CLUTCH ROD CLUTCH ROD	Avail to order Our Price: $25.19
001501188	OIL FILTER - MIURA COUNTACH ESPADA JARAMA OIL FILTER CARTRIDGE	Current Stock: 5 Our Price: $52.14

Fuel-Air

PN	Item	Diagram
001320172	AIR FILTER - CARBURETED AIR FILTER EARLY COUNTACH, MIURA, JARAMA, ESPADA SEE PN 001320172KN FOR PERFORMANCE FILTER OPTION		Avail to order Our Price: $544.80
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $23.86

Fuses-Bulbs-Relays

PN	Item
006617095	LICENSE PLATE LAMP REPLACEMENT BULB LICENSE PLATE LAMP REPLACEMENT BULB	Current Stock: 42 Our Price: $9.86
006617091	BULB 21W TAIL LIGHT 21W BULB	Current Stock: 4 Our Price: $12.04
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.80
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.43
001605819	RELAY RELAY	Current Stock: 1 Our Price: $39.61
006617089	10 W BULB 10 W BULB	Avail to order Our Price: $14.15
006617103	3W BULB 3W BULB	Avail to order Our Price: $6.35

Gaskets

PN	Item	Diagram
001526482	ENGINE GASKET SET - ESPADA - JARAMA ENGINE GASKET KIT ESPADA - JARAMA		Avail to order Our Price: $1,250.80
001526462	GROMMET AND OIL SEALS SET - ESPADA - JARAMA GROMMET AND OIL SEALS SET ESPADA - JARAMA		Avail to order Our Price: $107.67

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $931.04

Misc

PN	Item
006715235	WINDSC.WIP.BLADE WINDSC.WIP.BLADE	Avail to order Our Price: $60.97
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.53
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $162.79
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT		Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 93 Our Price: $15.26

Open All

Select Group and TAV

< Previous Next >

TAV: 20.41 - Chassis Structure

1972 Lamborghini Jarama USA Chassis Structure (20.41)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004204675	CLUTCH OIL PIPE RETURN WASHER	1 req	Avail to order Our Price: $23.28
2	004204677	This item is no longer available	1 req
3	WHT001197A	WASHER	2 req	Current Stock: 2 Our Price: $0.40
4	N90612002	PAN HEAD BOLT	2 req	Current Stock: 37 Our Price: $1.00
5	008200804	NUT	4 req	Current Stock: 7 Our Price: $1.37
6	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $1.94
7	008300822	STUD M8X18 UNI 5911 8G Z	4 req	Avail to order Our Price: $23.67
8	008401007	WASHER 21.5X10.4X2 UNI 6592/5S	8 req	Avail to order Our Price: $0.14
9	008201008	NUT	8 req	Current Stock: 2 Our Price: $1.06
10	008921407	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
11	002404447	ENGINE MOUNT	2 req	Avail to order Our Price: $621.58
12	008401413	FLAT WASHER 14.3 UNI1750/Z	2 req	Current Stock: 11 Our Price: $1.19
13	008411502	SNAP RING 24X15X3 UNI 1751 C72	2 req	Avail to order Our Price: $2.58
14	008101412	SCREW M.14X90 UNI 5737/10K	2 req	Avail to order Our Price: $22.48
15	001807468	This item is no longer available	1 req
16	008930801	PICKLING HOLE PLUG	37 req	Current Stock: 6 Our Price: $2.58
17	008932001	FRAME HOLE CAP PR 1746	12 req	Current Stock: 16 Our Price: $7.81
18	005205317	NO LONGER AVAILABLE TO ORDER	2 req	Avail to order Our Price: $32.16
19	008100908	SPECIAL SCREW M9X78	8 req	Avail to order Our Price: $13.43
20	008400901	WASHER 9.5X18X2	8 req	Current Stock: 18 Our Price: $0.11
21	008200904	SPECIAL NUT	8 req	Avail to order Our Price: $7.81
22	004104694	REAR SUSPENSION FRONT LOWER CO	2 req	Avail to order Our Price: $394.11
23	004104693	REAR SHOCK ABSORBER ADJUSTMENT	8 req	Avail to order Our Price: $29.82
24	004201213	FOOTREST COVER	1 req	Avail to order Our Price: $31.94
25	006102094	FOOTREST BRACKET	1 req	Avail to order Our Price: $48.68
26	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.43
27	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $0.50
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
