1972 Lamborghini Jarama USA Steering (23.10400.4)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $456.30
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.70
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.34
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.95
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.27

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 23.10400.4 - Steering

1972 Lamborghini Jarama USA Steering (23.10400.4)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004308911	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	004304570	NLA (No Longer Available)	1 req	*See Description
3	004301424	Joint	1 req	Avail to order Our Price: $5,246.68
4	008201011	M10 Uni 5589-65/8g Nut	2 req	Avail to order Our Price: $21.39
5	008411005	Washer D.10.5 Uni 1751/F	2 req	Avail to order Our Price: $2.00
6	004309163	Zf Steering Box Assembly	1 req	Avail to order Our Price: $1,982.92
7	008301005	Special Stud M10x20.4	1 req	Avail to order Our Price: $9.53
8	008401007	Washer 21.5x10.4x2 Uni 6592/5s	1 req	Avail to order Our Price: $2.00
9	008201008	Nut	1 req	Current Stock: 2 Our Price: $2.00
10	004305625	Tierod	2 req	Avail to order Our Price: $918.51
11	008401306	Washer D.13x24x3 8g	6 req	Avail to order Our Price: $2.72
12	004302537	Rh Central Steering Tierod	1 req	Avail to order Our Price: $694.09
13	004301214	Steering Tierod Coupling Pin	1 req	Avail to order Our Price: $152.39
14	004302538	Lh Central Steering Tierod	1 req	Avail to order Our Price: $694.09
15	004308474	Steering Box Lever	1 req	Avail to order Our Price: $439.82
16	008820501	Split Pin 4.7x40 Uni 1336b	1 req	Avail to order Our Price: $2.92
17	004304565	Steering Transmission Lever	1 req	Avail to order Our Price: $367.47
18	004304424	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
19	008200806	M8 Uni 5588/8g/Z Nut	4 req	Current Stock: 25 Our Price: $2.00
20	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
21	008300824	Stud M8x22 Uni 5911 10k Z	4 req	Avail to order Our Price: $2.00
22	008932401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
23	004303722	Transmission Lever Pin Bushing	2 req	Avail to order Our Price: $45.12
24	008602601	Ring	2 req	Avail to order Our Price: $3.99
25	004304564	SEE PN: 4303723 AND 8900801	1 req	Avail to order Our Price: $21.87
26	008900602	Elastic Pin 6x35	1 req	Avail to order Our Price: $2.00
27	008301010	Stud M10x30 Uni 59098gz	2 req	Avail to order Our Price: $11.96
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
