TAV: 19.10350.33 - Handbrake

1972 Lamborghini Jarama USA Handbrake (19.10350.33)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201213	12 Uni 210 8g Nut	2 req	Avail to order Our Price: $6.26
2	003301867	Handbrake AdjustmentScrew	2 req	Avail to order Our Price: $42.65
3	003309123	This item is no longer available	1 req
4	003309124	This item is no longer available	1 req
5	410609789	Pin	3 req	Avail to order Our Price: $32.91
6	003301305	Fork	2 req	Avail to order Our Price: $108.51
7	N90179103	WASHER	3 req	Current Stock: 5 Our Price: $2.00
8	008820201	Split Pin 1.8x15 Uni 1336a	3 req	Current Stock: 19 Our Price: $7.60
9	008700506	Screw Knip 4.8x16din7971 Black	5 req	Current Stock: 4 Our Price: $2.00
10	003305471	Lower Handbrake Cap Lock Plate	1 req	Avail to order Our Price: $16.33
11	003305468	Handbrake Boot	1 req	Avail to order Our Price: $120.24
12	003308016	This item is no longer available	1 req
13	008410502	Washer D.5.3 Uni 1751/Zd	2 req	Current Stock: 33 Our Price: $2.00
14	N01020717	HEXAGON HEAD BOLT	2 req	Current Stock: 4 Our Price: $2.00
15	003301857	Sheath Terminal	4 req	Avail to order Our Price: $5.08
16	003301312	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
17	003301308	Handbrake Bracket	1 req	Avail to order Our Price: $29.07
18	008100826	Screw M8x16 Uni 5739/8g/Z	4 req	Avail to order Our Price: $2.00
19	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
20	003308698	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
21	003301470	Handbrake Wire Plate	1 req	Avail to order Our Price: $13.94
22	003304857	Rh Handbrake Tierod	1 req	Avail to order Our Price: $26.02
23	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
24	413609206	Handbrake Tierod Adjustment	1 req	Avail to order Our Price: $70.72
25	006617083	NLA (No Longer Available)	1 req	*See Description
26	008200607	D 6x1 Sin. 8g Nut	1 req	Avail to order Our Price: $14.92
27	003308670	Handbrake Assembly Tierod Asse	1 req	Avail to order Our Price: $91.25
28	008580702	Circlip 7 9 Din 6799	2 req	Avail to order Our Price: $21.40
29	003308671	Handbrake Rod Pin	1 req	Avail to order Our Price: $16.63
30	008400701	Washer 734x14x1.5 Uni 1733/5s/	2 req	Avail to order Our Price: $2.91
31	003308700	Handbrake Guard Bulkhead	1 req	Avail to order Our Price: $61.30
32	008700306	Screw Knip B3.5x16din7971	3 req	Avail to order Our Price: $2.91
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
