1972 Lamborghini Jarama USA Gearbox (15.24)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 15.24 - Gearbox

1972 Lamborghini Jarama USA Gearbox (15.24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008933501	Gearbox Outlet Plug	1 req	Avail to order Our Price: $2.91
2	002402569	Transmission Outlet Sleeve	1 req	Avail to order Our Price: $591.89
3	008614203	OIL SEAL	1 req	Avail to order Our Price: $6.19
4	008576601	O-Ring I 62 Uni 3654	2 req	Avail to order Our Price: $2.00
5	008524203	Bearing	1 req	Avail to order Our Price: $245.26
6	002401711	Primary Shaft	1 req	Avail to order Our Price: $1,505.82
7	008253506	M35x1.5x52 Ring Nut	2 req	Avail to order Our Price: $33.40
8	008413502	Washer Skf Mb7	2 req	Avail to order Our Price: $6.64
9	002404434	Odometer Gear Shim	1 req	Avail to order Our Price: $27.81
10	008503503	Bearing	1 req	Avail to order Our Price: $109.14
11	002401754	Flange	1 req	Avail to order Our Price: $75.59
12	002401734	Washer	1 req	Avail to order Our Price: $466.65
13	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.75
14	008410603	Washer D.6.4 Uni 1751/Zd	4 req	Avail to order Our Price: $2.00
15	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
16	002401737	O-ring	1 req	Avail to order Our Price: $92.14
17	001524002	This item is no longer available	1 req
18	002401730	5th Speed Gear	1 req	Avail to order Our Price: $1,826.36
19	002404350	5th Speed Shim Adjustment Wash	1 req	Avail to order Our Price: $380.19
20	002402017	Synchroniser Inner Ring	6 req	Avail to order Our Price: $628.71
21	002409605	Synchroniser Ring	4 req	Current Stock: 4 Our Price: $509.81
22	002402003	Synchroniser Retaining Rings	6 req	Avail to order Our Price: $387.64
23	002402007	Gear Engaging Sleeve	3 req	Avail to order Our Price: $2,288.92
24	002402004	5th Speed Drive Unit	1 req	Avail to order Our Price: $3,760.36
25	008525001	Bearing	1 req	Avail to order Our Price: $49.57
26	002401729	Reverse Gear	1 req	Avail to order Our Price: $638.11
27	086311228A	Needle Cage	3 req	Avail to order Our Price: $114.64
28	002401731	1st Speed Gear	1 req	Avail to order Our Price: $1,114.73
29	002402006	This item is no longer available	1 req
30	002401742	O-ring	2 req	Avail to order Our Price: $282.41
31	002409605	Synchroniser Ring	1 req	Current Stock: 4 Our Price: $509.81
32	002401728	2nd Speed Gear	1 req	Avail to order Our Price: $3,287.45
33	002401727	3rd Speed Gear	1 req	Avail to order Our Price: $2,288.92
34	002409605	Synchroniser Ring	1 req	Current Stock: 4 Our Price: $509.81
35	008502002	Scn 6304-2rs Exbln20	2 req	Avail to order Our Price: $70.90
36	002401732	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
37	002401770	Reverse Guide Gear	1 req	Avail to order Our Price: $372.73
38	002401772	Reverse Guide PulleyShim	1 req	Avail to order Our Price: $13.94
39	008700806	Screw M8x14 Uni 592512k	1 req	Avail to order Our Price: $2.91
40	002401771	Reverse Shaft	1 req	Avail to order Our Price: $69.25
41	002402005	3rd Speed Drive Unit	1 req	Avail to order Our Price: $3,760.36
42	008523005	Bearing	1 req	Avail to order Our Price: $26.69
43	002401726	Gearbox/Clutch Shaft	1 req	Avail to order Our Price: $872.18
44	008503504	Bearing	1 req	Avail to order Our Price: $76.79
45	002401747	Clutch Shaft Shim Adjustment W	1 req	Avail to order Our Price: $72.39
46	008503202	This item is no longer available	1 req
47	008503002	Bearing	1 req	Avail to order Our Price: $31.98
48	002401710	Secondary Shaft	1 req	Avail to order Our Price: $459.21
49	002401709	NLA (No Longer Available)	1 req	*See Description
50	008503003	Bearing	1 req	Avail to order Our Price: $26.02
51	008413001	Washer Skf Mb6	1 req	Current Stock: 10 Our Price: $2.61
52	008253002	30x1.5x45 Self-Locking Ring Nu	1 req	Avail to order Our Price: $50.55
53	002401828	2nd-3rd Speed Washer	1 req	Avail to order Our Price: $82.45
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
