1972 Lamborghini Jarama USA Front Suspension (25.51)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
004608478	Belt Belt	Avail to order Our Price: $113.58

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $456.30
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.70
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.34
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.95
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.27

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 25.51 - Front Suspension

1972 Lamborghini Jarama USA Front Suspension (25.51)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	005104562	This item is no longer available	1 req
1	008101610	Screw 16x1.5x72 Ch2410k	8 req	Current Stock: 1 Our Price: $56.81
2	008401705	Washer 44x17.5x1.5	1 req	Current Stock: 2 Our Price: $2.00
3	008921702	Silbloc Riv.89801584	8 req	Avail to order Our Price: $27.53
4	005105498	Front Arm	2 req	Avail to order Our Price: $243.78
5	008201603	Nut	8 req	Avail to order Our Price: $3.97
6	008200804	Nut	8 req	Current Stock: 7 Our Price: $2.00
7	008400803	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	8 req	*See Description
8	005100969	This item is no longer available	2 req
9	008100830	Screw M8x20 Uni 5739/8g/Z	8 req	Current Stock: 19 Our Price: $2.00
10	008101609	NLA (No Longer Available)	4 req	*See Description
11	008401612	Washer 16.5x35x4	8 req	Avail to order Our Price: $11.96
12	008921601	Silbloc Riv X220 52470	4 req	Avail to order Our Price: $85.18
13	005105678	This item is no longer available	2 req
14	005205680	Rear Shock Absorber Bulkhead	2 req	Avail to order Our Price: $116.23
15	008401611	Washer 17x29x3 5s Uni 16592	4 req	Avail to order Our Price: $16.43
16	008201603	Nut	4 req	Avail to order Our Price: $3.97
17	005103990	This item is no longer available	2 req
18	005104538	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
19	005104627	Front Shock AbsorberSpring	2 req	Avail to order Our Price: $500.89
20	005104560	Lh Lower Arm	1 req	Avail to order Our Price: $343.65
21	008403502	Washer 32x44x1.5	4 req	Avail to order Our Price: $30.83
22	008403501	Ertalon Washer 30x45	4 req	Avail to order Our Price: $30.83
23	008401707	Washer 17.5x44x1.5	4 req	Avail to order Our Price: $17.89
24	008401708	Washer 17.5x26x3 Aq42	8 req	Current Stock: 1 Our Price: $2.92
25	008820301	Split Pin 3.7x35 Uni 1336b	2 req	Avail to order Our Price: $2.92
26	008401614	Allen Screw Washer Rpr 16	2 req	Avail to order Our Price: $23.92
27	005100555	Lower Ball Joint	2 req	Avail to order Our Price: $790.17
28	008201212	Nut	2 req	Current Stock: 1 Our Price: $2.04
29	008401304	Washer 13x24x3 Uni 1734	2 req	Avail to order Our Price: $2.92
30	008101217	NLA (No Longer Available)	2 req	*See Description
31	008101016	Special Screw	2 req	Avail to order Our Price: $27.71
32	008401006	Washer 22x10.5x2.5 Uni 1734/5s	2 req	Current Stock: 1 Our Price: $2.00
33	008201010	M10Self Locking Nut	2 req	Avail to order Our Price: $2.00
34	008201007	M10x1Self-LockingNut	4 req	Avail to order Our Price: $8.85
35	008701003	Screw 10x1x21 8g	4 req	Avail to order Our Price: $109.40
36	008921801	Roll Bar Mount 18	2 req	Current Stock: 2 Our Price: $42.27
37	005101056	Torsion Bar U-Bolt	2 req	Avail to order Our Price: $125.63
38	008921802	U BOLT	2 req	Avail to order Our Price: $40.52
39	005104541	This item is no longer available	1 req
40	005101047	Torsion Bar U-Bolt	2 req	Avail to order Our Price: $126.70
41	008201006	M10Self Locking Nut	4 req	Avail to order Our Price: $8.85
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
