1972 Lamborghini Jarama USA Gearbox (14.10100.24)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $456.30
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.70
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.34
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.95
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.27

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 14.10100.24 - Gearbox

1972 Lamborghini Jarama USA Gearbox (14.10100.24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002402557	Gear Lever Boot Cover	1 req	Avail to order Our Price: $40.84
2	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
3	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
4	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.74
5	002402166	Gearbox Upper Cover	1 req	Avail to order Our Price: $107.35
6	002402167	GEAR LEVER COVER SEAL	1 req	Avail to order Our Price: $508.37
7	N01100637	HEX.NUT	8 req	Current Stock: 18 Our Price: $2.00
8	WHT001197A	WASHER	8 req	Current Stock: 2 Our Price: $2.00
9	WHT003165	TAP END STUD	8 req	Current Stock: 3 Our Price: $2.00
10	002402526	Reverse Gear Cover Seal	1 req	Current Stock: 1 Our Price: $11.34
11	002402524	Reverse Gear Cover	1 req	Avail to order Our Price: $79.15
12	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.74
13	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
14	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
15	N01020717	HEXAGON HEAD BOLT	2 req	Current Stock: 4 Our Price: $2.00
16	008410503	Washer Din 137a 5.3x10 Zgd.	2 req	Avail to order Our Price: $2.00
17	002402535	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	008401216	Fiber Washer 12.5x20x1.5	1 req	Avail to order Our Price: $2.00
19	002401873	This item is no longer available	1 req
20	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
21	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
22	002402355	Rear Gearbox Cover	1 req	Avail to order Our Price: $346.66
23	002401850	Gearbox Rear Cover Seal	1 req	Avail to order Our Price: $15.41
24	008300613	Stud M6x14 Uni 5911 8g/Z	4 req	Avail to order Our Price: $5.74
25	002401851	Plug	3 req	Avail to order Our Price: $76.00
26	002407279	Espada Rear Gearbox Cover	1 req	Avail to order Our Price: $1,303.02
27	008851401	Gearbox Cover Dowel	2 req	Avail to order Our Price: $11.96
28	N01100845	HEX.NUT	9 req	Current Stock: 17 Our Price: $2.14
29	WHT001514	SPRING WASHER	6 req	Current Stock: 9 Our Price: $26.80
30	008300818	Stud M8x30 Uni 5911 8g Zd	5 req	Avail to order Our Price: $5.04
31	002401768	GEARBOX BOX SEAL	1 req	Avail to order Our Price: $25.69
32	002401782	Gearbox & Clutch Box	1 req	Avail to order Our Price: $3,503.65
33	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
34	008300815	Special Stud M8x33	1 req	Avail to order Our Price: $19.55
35	002405139	Gearbox Vibrachoc Mount	1 req	Avail to order Our Price: $95.59
36	008931902	Reverse Shaft Plug	1 req	Avail to order Our Price: $27.71
37	410971250	Engine/Chassis/Exhaust Pipe Ea	1 req	Avail to order Our Price: $72.63
38	WHT003166	TAP END STUD	2 req	Avail to order Our Price: $54.08
39	WHT003051	Washer D.3.2 Uni 1751/F	3 req	Avail to order Our Price: $2.00
40	008330827	This item is no longer available	1 req
41	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $188.37
42	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
43	N01100845	HEX.NUT	9 req	Current Stock: 17 Our Price: $2.14
44	WHT001514	SPRING WASHER	9 req	Current Stock: 9 Our Price: $26.80
45	008300315	This item is no longer available	7 req
46	008350806	This item is no longer available	2 req
47	008201407	Nut	1 req	Avail to order Our Price: $2.72
48	008401417	Washer 15x25x2 Uni 1736/Zd Aq4	1 req	Current Stock: 1 Our Price: $3.40
49	008101412	Screw M.14x90 Uni 5737/10k	1 req	Avail to order Our Price: $25.38
50	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
51	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
52	008100830	Screw M8x20 Uni 5739/8g/Z	4 req	Current Stock: 19 Our Price: $2.00
53	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.43
54	N90179103	WASHER	1 req	Current Stock: 5 Our Price: $2.00
55	008100830	Screw M8x20 Uni 5739/8g/Z	1 req	Current Stock: 19 Our Price: $2.00
56	002404723	Bracket	1 req	Avail to order Our Price: $429.54
57	002405140	Vibrachoc	1 req	Avail to order Our Price: $442.92
58	008401401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
59	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
60	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
61	008100827	Screw M8x25 Uni 5739/8g/Zg	4 req	Current Stock: 14 Our Price: $2.00
62	008100620	Screw M6x12 Uni 5739/5s/Z	1 req	Avail to order Our Price: $6.81
63	WHT001197A	WASHER	1 req	Current Stock: 2 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
