1972 Lamborghini Jarama USA Crankcase And Sump (9.18)

Maintenance Parts:

Belts

PN	Item
004608478	Belt Belt	Avail to order Our Price: $113.58
004504532	Belt Belt	Current Stock: 1 Our Price: $55.72
001604645	Belt Belt	Current Stock: 3 Our Price: $24.80
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.81

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $456.30
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $76.00
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.62

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.03

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.70
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.39
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 5 Our Price: $48.08

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.34
001501128	OIL FILTER SEAL OIL FILTER SEAL		Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.06
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.59
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
001605819	Relay Relay	Current Stock: 1 Our Price: $44.63
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.95
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.18

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.39
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.27

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.61

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.75
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.16
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	Wheel install tool Screws into hub for easy installation.		Current Stock: 95 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 9.18 - Crankcase And Sump

1972 Lamborghini Jarama USA Crankcase And Sump (9.18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201101	NLA (No Longer Available)	28 req	*See Description
2	008411101	Snap Ring 11.5x21x1.2	28 req	Avail to order Our Price: $9.04
3	008301212	Head Fastening Stud M11x100	28 req	Current Stock: 1 Our Price: $14.29
4	001101816	Cylinder Head Gasket	1 req	Avail to order Our Price: $466.67
5	001801880	Cylinder Liner	12 req	Avail to order Our Price: $1,238.12
6	008932202	Plug 22mb	1 req	Avail to order Our Price: $92.28
7	008602002	Ring 21 mm Or	1 req	Current Stock: 8 Our Price: $25.40
8	008932401	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
9	001101815	Cylinder Head Gasket Right Side	1 req	Avail to order Our Price: $466.67
10	N01100637	HEX.NUT	7 req	Current Stock: 18 Our Price: $2.00
11	WHT001197A	WASHER	7 req	Current Stock: 2 Our Price: $2.00
12	008300608	NLA (No Longer Available)	3 req	*See Description
13	001829009	GROMMET	1 req	Current Stock: 2 Our Price: $71.67
14	001802454	This item is no longer available	1 req
15	001800294	CRANKCASE REAR COVERSEAL	1 req	Avail to order Our Price: $27.71
16	008850803	This item is no longer available	2 req
17	001800546	Crankcase	1 req	Avail to order Our Price: $23,034.50
18	008850804	Reference Pin 8x14 C40	2 req	Avail to order Our Price: $20.61
19	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
20	008300815	Special Stud M8x33	2 req	Avail to order Our Price: $19.55
21	008300609	Stud M6x25 Uni 5911 8g/Zd	2 req	Avail to order Our Price: $16.43
22	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $2.00
23	008300611	Stud 6x30 Uni 5911/8g/Z	2 req	Avail to order Our Price: $8.17
24	WHT003079	Reference Pin 8h7x6.25x10	2 req	Avail to order Our Price: $35.69
25	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
26	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
27	WHT003165	TAP END STUD	2 req	Current Stock: 3 Our Price: $2.00
28	001804886	This item is no longer available	1 req
29	WHT003057	O-RING	1 req	Current Stock: 11 Our Price: $2.00
30	008300816	Stud M8x1x65 Uni 5919 10k	2 req	Avail to order Our Price: $17.89
31	008301213	Special Stud M12x98	2 req	Avail to order Our Price: $69.23
32	001800311	Oil Sump Seal	1 req	Avail to order Our Price: $85.86
33	008301214	Special Stud M12x94	12 req	Avail to order Our Price: $40.45
34	008300817	Stud M8x1x60 Uni 5919 10k	12 req	Avail to order Our Price: $19.55
35	001800297	This item is no longer available	1 req
36	008401502	Copper Washer 15x28x2	2 req	Avail to order Our Price: $19.35
37	008931403	Bronze Plug	2 req	Avail to order Our Price: $58.44
38	001800206	This item is no longer available	5 req
39	001800285	This item is no longer available	1 req
40	WHT001514	SPRING WASHER	14 req	Current Stock: 9 Our Price: $26.80
41	008200805	M8x1x8 8g/B Nut	14 req	Avail to order Our Price: $2.00
42	07L301155	BUSH	14 req	Avail to order Our Price: $62.05
43	001804497	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
44	008602901	Ring 30 mm Or	1 req	Current Stock: 15 Our Price: $2.00
45	001804650	Espada Oil Sump Bulkhead	1 req	Avail to order Our Price: $345.88
46	WHT003055	Washer 13x24x1.2 Din137/B C72	14 req	Current Stock: 10 Our Price: $2.00
47	001201210	This item is no longer available	14 req
48	001805141	Gearbox/Sump Bracket	1 req	Avail to order Our Price: $75.56
49	N0152785	WASHER	3 req	Current Stock: 71 Our Price: $2.00
50	008100826	Screw M8x16 Uni 5739/8g/Z	3 req	Avail to order Our Price: $2.00
51	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $150.16
52	008300608	NLA (No Longer Available)	16 req	*See Description
53	N01152427	WASHER	18 req	Current Stock: 16 Our Price: $2.00
54	008200605	Simmon Nut for urama	18 req	Current Stock: 50 Our Price: $3.10
55	001804507	Oil Sump	1 req	Avail to order Our Price: $2,840.19
56	086301141A	Magnetic Plug 22x1.5	1 req	Avail to order Our Price: $39.91
57	008260606	This item is no longer available	3 req
58	N01152427	WASHER	3 req	Current Stock: 16 Our Price: $2.00
59	WHT003165	TAP END STUD	3 req	Current Stock: 3 Our Price: $2.00
60	001804885	Oil Dipstick Pipe	1 req	Avail to order Our Price: $35.30
61	008200401	M4 Uni 5587/5s/Z	12 req	Avail to order Our Price: $2.00
62	008410402	Washer D.4.3 Uni 1751 /Zd	12 req	Current Stock: 15 Our Price: $2.00
63	008300401	Special Stud M4x7	12 req	Avail to order Our Price: $2.00
64	001803094	Oil Dipstick Pipe Seal	1 req	Current Stock: 11 Our Price: $8.46
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
