1972 Lamborghini Jarama USA Crankshaft And Pistons (4.14)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 4.14 - Crankshaft And Pistons

1972 Lamborghini Jarama USA Crankshaft And Pistons (4.14)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001402908	Upper Segment	12 req	Avail to order Our Price: $152.35
2	001402907	Lower Segment	12 req	Avail to order Our Price: $115.79
3	001402906	Oil Scraper	12 req	Avail to order Our Price: $80.27
4	001402904	PISTON COMPLETE	12 req	Avail to order Our Price: $884.35
5	001400398	Pin 19x66x11	12 req	Avail to order Our Price: $204.26
6	008572101	O-Ring I 20 Uni 3654	24 req	Avail to order Our Price: $2.00
7	001403519	This item is no longer available	12 req
8	001413206	Bushing	12 req	Avail to order Our Price: $123.81
9	001400359	This item is no longer available	24 req
10	001404419	This item is no longer available	24 req
11	008820201	Split Pin 1.8x15 Uni 1336a	24 req	Current Stock: 19 Our Price: $7.60
12	001419898	Bushing	24 req	Avail to order Our Price: $76.04
13	001403520	This item is no longer available	12 req
14	001400802	This item is no longer available	12 req
15	07M109381	Snap Ring I 35 Uni 3654	1 req	Current Stock: 35 Our Price: $2.00
16	410109264	Bearing	1 req	Current Stock: 10 Our Price: $30.31
17	001401116	Crankshaft	1 req	Avail to order Our Price: $10,693.98
18	008860803	Tab 8x7x25 con Sm	1 req	Avail to order Our Price: $12.93
19	001404486	Crankshaft Gear Shim	1 req	Avail to order Our Price: $108.51
20	001401117	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
21	001401245	SEE PN 07M105531A AND 07M105532	2 req	Avail to order Our Price: $33.70
22	001400248	Bushing	1 req	Avail to order Our Price: $53.90
23	001400244	Bushing	1 req	Avail to order Our Price: $53.90
24	001400236	Bushing	5 req	Current Stock: 1 Our Price: $194.57
25	001400236	Bushing	5 req	Current Stock: 1 Our Price: $194.57
26	001400243	Bushing	1 req	Avail to order Our Price: $51.14
27	001400239	Bushing	1 req	Avail to order Our Price: $53.90
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
