1972 Lamborghini Jarama USA Handbrake (19.33)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 6 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 19.33 - Handbrake

1972 Lamborghini Jarama USA Handbrake (19.33)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008201213	12 Uni 210 8g Nut	2 req	Avail to order Our Price: $6.26
2	003301867	Handbrake AdjustmentScrew	2 req	Avail to order Our Price: $42.65
3	003307343	Handbrake Wire Assembly	2 req	Avail to order Our Price: $57.70
4	410609789	Pin	3 req	Avail to order Our Price: $32.91
5	003301305	Fork	2 req	Avail to order Our Price: $108.51
6	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	3 req	Current Stock: 5 Our Price: $2.00
7	008820201	Split Pin 1.8x15 Uni 1336a	3 req	Current Stock: 19 Our Price: $7.60
8	008700506	Screw Knip 4.8x16din7971 Black	5 req	Current Stock: 4 Our Price: $2.00
9	003305471	Lower Handbrake Cap Lock Plate	1 req	Avail to order Our Price: $16.33
10	N10689901	HEX.NUT	1 req	Current Stock: 5 Our Price: $2.00
11	003305640	Handbrake Wire Retaining Brack	1 req	Avail to order Our Price: $16.40
12	003305468	Handbrake Boot	1 req	Avail to order Our Price: $120.24
13	008700306	Screw Knip B3.5x16din7971	7 req	Avail to order Our Price: $2.91
14	003308016	This item is no longer available	1 req
15	008410502	Washer D.5.3 Uni 1751/Zd	2 req	Current Stock: 33 Our Price: $2.00
16	N01020717	HEXAGON HEAD BOLT	2 req	Current Stock: 4 Our Price: $2.00
17	003301857	Sheath Terminal	4 req	Avail to order Our Price: $5.08
18	003301740	This item is no longer available	1 req
19	003301312	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
20	003301308	Handbrake Bracket	1 req	Avail to order Our Price: $29.07
21	003304857	Rh Handbrake Tierod	1 req	Avail to order Our Price: $26.02
22	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
23	413609206	Handbrake Tierod Adjustment	1 req	Avail to order Our Price: $70.72
24	008100826	Screw M8x16 Uni 5739/8g/Z	4 req	Avail to order Our Price: $2.00
25	N0152785	WASHER	4 req	Current Stock: 71 Our Price: $2.00
26	003304799	This item is no longer available	1 req
27	008200607	D 6x1 Sin. 8g Nut	1 req	Avail to order Our Price: $14.92
28	008201159	This item is no longer available	1 req
29	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
30	002304856	This item is no longer available	1 req
31	008580801	O-Ring E 8 Uni 7535-75	1 req	Current Stock: 3 Our Price: $2.00
32	003305675	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
