1972 Lamborghini Jarama USA Coolant System (8.17)

Maintenance Parts:

Belts

PN	Item
001604645	Belt Belt	Current Stock: 3 Our Price: $24.72
004009744	Power Steering Belt Power Steering Belt	Avail to order Our Price: $115.85
004504532	Belt Belt	Current Stock: 1 Our Price: $55.61
004608478	Belt Belt	Avail to order Our Price: $113.62

Brakes

PN	Item
003106765	FRONT BRAKE PADS JARAMA AND MIURA FRONT BRAKE PADS JARAMA AND MIURA	Avail to order Our Price: $457.05
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad	Avail to order Our Price: $75.95
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad	Avail to order Our Price: $78.63

Common repairs and upgrades

PN	Item	Diagram
001702817	THERMOSTAT VALVE THERMOSTAT VALVE		Avail to order Our Price: $544.89
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
002104719	Drive Plate Drive Plate	Avail to order Our Price: $873.67
002104088	Clutch Rod Clutch Rod	Avail to order Our Price: $28.40
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge	Current Stock: 3 Our Price: $48.16

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $502.37

Fuses-Bulbs-Relays

PN	Item
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W	Current Stock: 42 Our Price: $11.09
006617091	Bulb 21w tail light 21w Bulb	Current Stock: 4 Our Price: $13.56
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
001605819	Relay Relay	Current Stock: 1 Our Price: $44.66
006617089	10 W Bulb 10 W Bulb	Avail to order Our Price: $15.96
006617103	3w Bulb 3w Bulb	Avail to order Our Price: $7.14

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,153.38
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $99.29

Ignition

PN	Item	Diagram
001627934	DISTIBUTOR CAP DISTRIBUTOR CAP		Avail to order Our Price: $1,049.60

Misc

PN	Item
006715235	Windsc.Wip.Blade Windsc.Wip.Blade	Avail to order Our Price: $68.74
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item	Diagram
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY		Avail to order Our Price: $150.37
001719309	URRACO THERMOSTAT Coolant Thermostat		Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 8.17 - Coolant System

1972 Lamborghini Jarama USA Coolant System (8.17)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003101941	Banjo Bolt Fitting	1 req	Avail to order Our Price: $4.68
2	008401610	Annealed Copper Washer 16x22x0	2 req	Current Stock: 25 Our Price: $11.23
3	001703240	Heating Coolant Delivery Conne	1 req	Avail to order Our Price: $40.86
4	001701646	COOLANT WARNING LIGHT THERMAL	1 req	Avail to order Our Price: $104.76
5	008401610	Annealed Copper Washer 16x22x0	2 req	Current Stock: 25 Our Price: $11.23
6	001702498	This item is no longer available	1 req
7	001702817	THERMOSTAT VALVE	1 req	Avail to order Our Price: $544.89
8	008835004	Clamp	2 req	Avail to order Our Price: $10.86
9	001704585	Radiator Inlet Sleeve	1 req	Avail to order Our Price: $46.07
10	001704483	This item is no longer available	1 req
11	008100617	Screw M6x18 Uni 57395s	6 req	Avail to order Our Price: $6.79
12	N01152427	WASHER	6 req	Current Stock: 16 Our Price: $2.00
13	N01118312	HEX.HEAD CLAMPING NUT	6 req	Avail to order Our Price: $2.17
14	008100831	Screw M8x30 Uni 5737/8g/Z	4 req	Avail to order Our Price: $2.00
15	WHT001942	WASHER	8 req	Current Stock: 13 Our Price: $3.51
16	WHT001189	RUBBER WASHER MOUNT	4 req	Current Stock: 6 Our Price: $6.78
17	001705796	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	001701592	Radiator Shim	4 req	Current Stock: 8 Our Price: $20.77
19	001701495	Supplementary Reservoir Bracket	4 req	Current Stock: 9 Our Price: $58.51
20	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
21	008602303	Ring 24 mm Or	2 req	Current Stock: 18 Our Price: $2.00
22	008200608	Nut	4 req	Avail to order Our Price: $6.87
23	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
24	008300608	NLA (No Longer Available)	4 req	*See Description
25	008200402	M4 Brass Special Nut	3 req	Current Stock: 2 Our Price: $2.91
26	008410402	Washer D.4.3 Uni 1751 /Zd	3 req	Current Stock: 15 Our Price: $2.00
27	001701645	SEE PN: 1724565 AND 1724564	1 req	Avail to order Our Price: $49.79
28	001705504	Engine Thermal Contact Seal	1 req	Avail to order Our Price: $30.42
29	001704590	Espada Radiator Plug	1 req	Avail to order Our Price: $104.82
30	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $150.37
31	001704296	Coolant Cap	1 req	Avail to order Our Price: $155.33
32	008830204	Clamp	3 req	Avail to order Our Price: $10.06
33	001704587	Auxiliary Reservoir Radiator P	1 req	Avail to order Our Price: $25.88
34	008610601	Grommet 6x10x1.5 mm	3 req	Avail to order Our Price: $5.57
35	WHT002961	WASHER	3 req	Current Stock: 38 Our Price: $2.00
36	N01118312	HEX.HEAD CLAMPING NUT	3 req	Avail to order Our Price: $2.17
37	001704579	This item is no longer available	1 req
38	001708139	This item is no longer available	1 req
39	001701906	Tap Washer	1 req	Avail to order Our Price: $2.00
40	001701905	Radiator Tap	1 req	Avail to order Our Price: $115.94
41	001705153	Fan Plug	6 req	Avail to order Our Price: $3.80
42	001704947	NLA (No Longer Available)	2 req	*See Description
43	410801988	Grommet mm 12x20x1.5mm	1 req	Avail to order Our Price: $58.74
44	008830108	Clamp Din 7 2571	1 req	Avail to order Our Price: $6.87
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
