1972 Lamborghini Jarama USA Lights And Direction Indicators (5.10066)

Maintenance Parts:

Belts

PN	Item	Diagram
004608478	Belt Belt		Avail to order Our Price: $110.33
004504532	Belt Belt		Current Stock: 1 Our Price: $54.12
001604645	Belt Belt		Current Stock: 3 Our Price: $24.01
004009744	Power Steering Belt Power Steering Belt		Avail to order Our Price: $112.42

Brakes

PN	Item	Diagram
003106765	Brake Pads Front - Jarama - Miura Front Brake Pads		Avail to order Our Price: $322.90
003207720	E-Brake Pad - Espada - Jarama Handbrake Pad		Avail to order Our Price: $73.99
003206764	Brake Pad Rear - Espada - Miura - Jarama - Sold Each Rear Brake Pad		Avail to order Our Price: $74.43

Drivetrain

PN	Item	Diagram
001501188	Oil Filter - Miura Countach Espada Jarama Oil Filter Cartridge		Avail to order Our Price: $46.75
002104719	Drive Plate Drive Plate		Avail to order Our Price: $848.33
002104088	Clutch Rod Clutch Rod		Avail to order Our Price: $27.59
001504611	Oil Filter Oil Filter		Avail to order Our Price: $494.99

Fuel-Air

PN	Item	Diagram
001320172	Air Filter - Carbureted Air Filter Early Countach, Miura, Jarama, Espada SEE PN 001320172KN for Performance filter option		Avail to order Our Price: $474.94

Fuses-Bulbs-Relays

PN	Item	Diagram
006617095	Bulb for license plate lamp Bulb LAMP SV8,5-8 5W		Current Stock: 42 Our Price: $10.71
006617091	Bulb 21w tail light 21w Bulb		Current Stock: 5 Our Price: $13.10
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)		Current Stock: 77 Our Price: $9.60
N0177522	bulb Headlight LAMP 12V/3W		Current Stock: 10 Our Price: $2.09
001605819	Relay Relay		Current Stock: 1 Our Price: $43.32
006617089	10 W Bulb 10 W Bulb		Avail to order Our Price: $15.51
006617103	3w Bulb 3w Bulb		Avail to order Our Price: $6.92

Gaskets

PN	Item	Diagram
001526482	Engine Gasket Set - Espada - Jarama Engine Gasket Kit Espada - Jarama		Avail to order Our Price: $1,090.33
001526462	Grommet and Oil Seals Set - Espada - Jarama Grommet and Oil Seals Set Espada - Jarama		Avail to order Our Price: $93.84

Misc

PN	Item	Diagram
006715235	Windsc.Wip.Blade Windsc.Wip.Blade		Avail to order Our Price: $66.73
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut		Avail to order Our Price: $1.94
900000382	NLA use PN 400093050D for USA replacement		Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.		Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 5.10066 - Lights And Direction Indicators

1972 Lamborghini Jarama USA Lights And Direction Indicators (5.10066)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jarama Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	006743111	This item is no longer available	2 req
0	006744068	Lowbeam Unit	1 req	Avail to order Our Price: $127.18
0	006744069	Rh Highbeam Unit	1 req	Avail to order Our Price: $127.18
0	006744070	This item is no longer available	1 req
0	006843021	This item is no longer available	1 req
0	006843022	This item is no longer available	1 req
0	006744050	Rh High Beam	1 req	Avail to order Our Price: $459.21
0	006744051	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
0	006744058	Rh Low Beam	1 req	Avail to order Our Price: $511.39
0	006744059	Lh Low Beam	1 req	Avail to order Our Price: $511.39
0	006109320	This item is no longer available	2 req
0	006109170	This item is no longer available	2 req
0	006743108	This item is no longer available	2 req
0	006743106	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
0	006843008	Red Left Lens	1 req	Avail to order Our Price: $63.60
0	006843028	Left Rear Lens	1 req	Avail to order Our Price: $63.60
0	006843025	Rh Rr Light	1 req	Avail to order Our Price: $523.32
0	006843026	Lh Rr Light	1 req	Avail to order Our Price: $523.32
1	008200401	M4 Uni 5587/5s/Z	8 req	Avail to order Our Price: $0.08
2	008410402	Washer D.4.3 Uni 1751 /Zd	8 req	Current Stock: 17 Our Price: $0.05
3	006108293	This item is no longer available	2 req
4	006108281	Rh Side Marker Housing	2 req	Avail to order Our Price: $152.07
5	006743110	Front Side Marcker	2 req	Avail to order Our Price: $115.40
6	006617103	3w Bulb	4 req	Avail to order Our Price: $6.92
7	008700409	Screw Tgs 4x16 Uni 6110	8 req	Avail to order Our Price: $6.56
8	008200505	M5 Special Nut	4 req	Avail to order Our Price: $6.64
9	WHT001514	SPRING WASHER	4 req	Current Stock: 9 Our Price: $25.98
10	006309085	Number Plate Light	2 req	Avail to order Our Price: $133.30
11	006309152	Number Plate Light Shim	2 req	Avail to order Our Price: $29.52
12	006744067	Lowbeam Unit	1 req	Avail to order Our Price: $127.18
13	006617091	Bulb 21w tail light	2 req	Current Stock: 5 Our Price: $13.10
14	006743120	This item is no longer available	2 req
15	006743109	NLA (No Longer Available)	2 req	*See Description
16	006843009	Red Right Lens	1 req	Avail to order Our Price: $63.60
17	006843027	Right Rear Lens	1 req	Avail to order Our Price: $63.60
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
