1981-1988 Jalpa 3.5 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	AUXILIARY UNIT BELT AUXILIARY UNIT BELT		Avail to order Our Price: $346.32
004613685	AIR PUMP BELT AIR PUMP BELT		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $99.00
003135292	BRAKE PADS FRONT - JALPA - EARLY DIABLO - PER ROTOR FRONT BRAKE PADS		Avail to order Our Price: $524.67

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.44
007029005	BONNET LIFTER BONNET LIFTER		Current Stock: 4 Our Price: $114.79

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.51
002111112	FLYWHEEL FLYWHEEL	Avail to order Our Price: $1,270.26
002111111	CLUTCH PRESSURE PLATE CLUTCH PRESSURE PLATE	Current Stock: 1 Our Price: $2,742.24
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.19
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.44
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,431.28
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $350.78

Fuel-Air

PN	Item
006220011	FUEL FILTER FUEL FILTER	Avail to order Our Price: $314.68
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.24
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.85
006617106	12V 60/55W BULB 12V 60/55W BULB	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526492	ENGINE GASKET KIT JALPA ENGINE GASKET KIT	Avail to order Our Price: $1,403.08
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.55
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.80

Ignition

PN	Item	Diagram
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $667.35
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99

Misc

PN	Item
006121168	NLA (NO LONGER AVAILABLE) WIPER BLADE TYPE B	Avail to order Our Price: $40.41
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.12
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.05
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 94 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 47.78 - Doors

1981-1988 Lamborghini Jalpa 3.5 USA Doors (47.78)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	007821004	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
0	007821002	LH DOOR WINDOW	1 req	Avail to order Our Price: $1,647.46
0	007821023	WINDOW CHANNEL BUTT	1 req	Avail to order Our Price: $104.05
0	006921241	This item is no longer available	1 req
0	007821058	LH STRIKER 9954001	1 req	Avail to order Our Price: $109.25
0	006921186	LEFT DOOR HANDLE LEVER	1 req	Avail to order Our Price: $139.85
0	007821029	DOOR PANEL CENTRAL FRAME	1 req	Avail to order Our Price: $218.49
0	007821033	PANEL	1 req	Avail to order Our Price: $405.53
0	007821079	LH DOOR ARMREST	1 req	Avail to order Our Price: $772.29
0	007821025	LEFT FRONT SIDE PANEL FRAME	1 req	Avail to order Our Price: $202.76
0	007821056	LOCK DOOR	1 req	Avail to order Our Price: $405.53
1	007121011	FLYWHEEL EXT. SEAL	2 req	Avail to order Our Price: $20.13
2	006921300	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
3	006921266	MM 41 REAR BUTT. WINDOW SEAL L	2 req	Avail to order Our Price: $34.97
4	007821019	WINDOW LOWER.CM CHANNEL MOULD.	2 req	Avail to order Our Price: $121.67
5	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	6 req	Current Stock: 8 Our Price: $0.89
6	007821054	FIXED BUTT. WINDOW FRAME INTER	2 req	Avail to order Our Price: $115.70
7	007821001	RH DOOR WINDOW	1 req	Avail to order Our Price: $1,647.46
8	007821003	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
9	007821009	INERNAL HANDLE CONNECTION ROD	4 req	Avail to order Our Price: $162.52
10	008700432	SCREW 4X25 UNI 6109/5S	14 req	Avail to order Our Price: $6.93
11	WHT003040	WASHER	14 req	Current Stock: 2 Our Price: $8.12
12	006558588	DOOR SAFETY LOCK	2 req	Avail to order Our Price: $16.43
13	006921180	RIM.SI SEAL	2 req	Avail to order Our Price: $7.01
14	007821055	RIGHT DOOR LOCK	1 req	Avail to order Our Price: $405.53
15	007821020	WINDOW LOWER.CM CHANNEL MOULD.	2 req	Avail to order Our Price: $121.67
16	007821022	REAR SIDE WINDOW CHANNEL BUTT	1 req	Avail to order Our Price: $109.25
17	007821057	RH STRIKER 9954001	1 req	Avail to order Our Price: $109.25
18	006921200	This item is no longer available	1 req
19	008700631	SCREW M6X14 DIN 966 4S/Z	6 req	Avail to order Our Price: $2.91
20	007821011	FRONT RIGHT BUTT. WINDOW	1 req	Avail to order Our Price: $985.50
21	007821012	FRONT LEFT BUTT. WINDOW	1 req	Avail to order Our Price: $985.50
22	006721234	DOOR LIGHT PIN SWITCH (DOES NOT INCLUDE RUBBER GASKET ORDER PN 006921236)	2 req	Current Stock: 6 2 Used Available Our Price: $43.47
23	006921216	NLA (NO LONGER AVAILABLE)	2 req	*See Description
24	007821077	BUTT. WINDOW FIX.BRACKET	2 req	Avail to order Our Price: $35.11
25	007821082	This item is no longer available	2 req
26	007121008	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
27	008200405	4X0.7X3 UNI 5589 5S NUT	28 req	Avail to order Our Price: $2.91
28	007821049	NLA (NO LONGER AVAILABLE)	2 req	*See Description
29	006921164	DOOR LEVER RETAININGSPRING	2 req	Avail to order Our Price: $34.97
30	006921185	RIGHT DOOR HANDLE LEVER	1 req	Avail to order Our Price: $139.85
31	006921614	DOOR HAND.FIX.BRACKET	2 req	Avail to order Our Price: $69.93
32	006921196	DOOR SAF.LOCK TIE ROD	2 req	Avail to order Our Price: $69.93
33	006921240	This item is no longer available	1 req
34	410837261	COM.SERR.HEAD 78926 /C DOOR PIECE	4 req	Avail to order Our Price: $3.65
35	006921214	DOOR FAIRLEAD PIPE	2 req	Avail to order Our Price: $36.16
36	006921956	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
37	006921954	DOOR CABLE SEAL HOUSING	2 req	Avail to order Our Price: $14.02
38	006921958	DOOR FARILEAD SEAL	2 req	Avail to order Our Price: $3.51
39	007821006	RH POWER WINDOW	1 req	Avail to order Our Price: $2,027.64
40	007821005	LH POWER WINDOW	1 req	Avail to order Our Price: $2,027.64
40	007821008	NLA (NO LONGER AVAILABLE)	2 req	*See Description
41	007821007	OPENING HANDLE	2 req	Avail to order Our Price: $811.06
42	007821048	WINDOW UPPER LIMIT SWITCH CABL	2 req	Avail to order Our Price: $42.12
43	007821061	STROKE CABLE SHEATH	2 req	Avail to order Our Price: $24.38
44	006935118	This item is no longer available	4 req
45	007821040	This item is no longer available	2 req
46	007821009	INERNAL HANDLE CONNECTION ROD	2 req	Avail to order Our Price: $162.52
47	007821075	NLA (NO LONGER AVAILABLE)	2 req	*See Description
48	007821074	DOOR WARNING LAMP	2 req	Current Stock: 1 Our Price: $69.86
49	008700631	SCREW M6X14 DIN 966 4S/Z	6 req	Avail to order Our Price: $2.91
50	WHT002961	WASHER	22 req	Current Stock: 38 Our Price: $0.43
51	008100622	SCREW M6X12 UNI 5739/8G	14 req	Avail to order Our Price: $6.79
52	008700305	LOCK SCREW 3.5X16DIN7982/C	8 req	Avail to order Our Price: $2.91
53	008100621	SCREW M6X20 UNI 5739/5S/Z	8 req	Avail to order Our Price: $0.14
54	008700203	LOCK SCREW 2.9X31.7DIN798	2 req	Avail to order Our Price: $2.91
55	N01100637	HEX.NUT	8 req	Current Stock: 18 Our Price: $0.36
56	N10689901	HEX.NUT	6 req	Current Stock: 5 Our Price: $0.08
57	008700818	SCREW TPS M8X30 UNI 5933	4 req	Avail to order Our Price: $2.91
58	008700313	LOCK SCREW 2.9X13DIN7982/N	32 req	Avail to order Our Price: $2.91
59	007821028	DOOR PANEL CENTRAL FRAME	1 req	Avail to order Our Price: $218.49
60	007821032	I PART PANEL FRAME	1 req	Avail to order Our Price: $405.53
61	007821078	RH DOOR ARMREST	1 req	Avail to order Our Price: $772.29
62	007821024	RIGHT FRONT SIDE PANEL FRAME	1 req	Avail to order Our Price: $202.76
63	007821072	This item is no longer available	2 req
64	007821067	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
