1981-1988 Lamborghini Jalpa 3.5 USA Front Brakes (19.31)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $327.24
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $74.72

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $496.66
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
002111112	Flywheel Flywheel	Avail to order Our Price: $1,182.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,671.52
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $294.96
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $80.00

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,022.15
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $329.42
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,326.35

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $629.88

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $37.60
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 19.31 - Front Brakes

1981-1988 Lamborghini Jalpa 3.5 USA Front Brakes (19.31)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003211424	This item is no longer available	1 req
2	003211427	This item is no longer available	1 req
3	003204607	Brake Booster Union Pipe	1 req	Avail to order Our Price: $110.94
4	008830205	Clamp	10 req	Avail to order Our Price: $7.37
5	008201014	M10x1x6 Uni 5589/5s/Z Nut	2 req	Current Stock: 1 Our Price: $6.65
6	N01118312	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 4 Our Price: $2.01
7	N01152427	WASHER	1 req	Avail to order Our Price: $2.00
8	003108672	Brake Three-Way Union	2 req	Avail to order Our Price: $61.40
9	003108674	Rh Shoe Pipe/Three-Way	1 req	Avail to order Our Price: $21.95
10	003108673	Pipe	1 req	Avail to order Our Price: $67.34
11	003208683	Hose	2 req	Avail to order Our Price: $94.99
12	001708593	Coolant Pipe Protection Sleeve	1 req	Avail to order Our Price: $25.71
13	003211466	This item is no longer available	1 req
14	003101513	Copper Washer 16.2x24x1	2 req	Avail to order Our Price: $2.00
15	003204975	Vacuum Reservoir Three-Way Uni	1 req	Avail to order Our Price: $55.54
16	003201511	Bolt	1 req	Avail to order Our Price: $49.97
17	003211465	This item is no longer available	1 req
18	003111431	Three-Way Pipe/Lh Front Shoe	1 req	Avail to order Our Price: $19.88
19	003120630	Pipe	1 req	Avail to order Our Price: $67.63
20	003208682	Union	1 req	Current Stock: 1 Our Price: $59.76
21	N01152427	WASHER	1 req	Avail to order Our Price: $2.00
22	N01118312	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 4 Our Price: $2.01
23	003111432	Three-Way Pipe/Rh Front Shoe	1 req	Avail to order Our Price: $19.88
24	003211425	Cylinder Pipe/SafetyDevice	1 req	Avail to order Our Price: $67.34
25	003111430	Cylinder/Safety Device	1 req	Avail to order Our Price: $18.73
26	003121091	This item is no longer available	1 req
27	003208693	Hydraulic Brake Light Switch	1 req	Avail to order Our Price: $114.40
28	N01118312	HEX.HEAD CLAMPING NUT	3 req	Current Stock: 4 Our Price: $2.01
29	003111405	Brake Booster Clamp	1 req	Avail to order Our Price: $20.52
30	N01152427	WASHER	3 req	Avail to order Our Price: $2.00
31	008100604	Screw M6x14 Uni 5739/5s/Z	2 req	Avail to order Our Price: $2.65
32	003110013	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
33	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
34	008200813	5/16x24 Unf Fon Special Nu	2 req	Avail to order Our Price: $2.65
35	003106919	Ventilated Front/Rear Brake Di	2 req	Avail to order Our Price: $1,650.70
36	008100826	Screw M8x16 Uni 5739/8g/Z	4 req	Avail to order Our Price: $2.00
37	003120224	Brake Shoe System Pipe	1 req	Avail to order Our Price: $22.02
38	003108676	Lh Shoe Pipe/Three-Way	1 req	Avail to order Our Price: $21.95
39	003112008	Lh Shoe	1 req	Avail to order Our Price: $1,022.15
40	003112007	Rh Shoe	1 req	Avail to order Our Price: $1,022.15
41	008401305	Washer 13x22x* C 72	1 req	Avail to order Our Price: $2.00
42	008411303	Snap Ring 21x13x2.5 Uni 175 1	4 req	Current Stock: 6 Our Price: $3.00
43	008101223	Special Screw M12x37	4 req	Current Stock: 2 Our Price: $14.09
44	003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor	4 req	Avail to order Our Price: $496.66
45	003120629	Pipe	1 req	Avail to order Our Price: $67.63
46	N01118312	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 4 Our Price: $2.01
47	N01152427	WASHER	1 req	Avail to order Our Price: $2.00
48	003111243	NLA (No Longer Available)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
