1981-1988 Lamborghini Jalpa 3.5 USA Fuel System (4.13)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 4.13 - Fuel System

1981-1988 Lamborghini Jalpa 3.5 USA Fuel System (4.13)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008100618	Screw M6x20 Uni 5739/8g/Zd	7 req	Current Stock: 44 Our Price: $2.00
2	008410603	Washer D.6.4 Uni 1751/Zd	7 req	Avail to order Our Price: $2.00
3	001310963	Carburettor Drive Shaft Lever	4 req	Avail to order Our Price: $59.64
4	001310961	Filter Carburettor Return Spri	1 req	Current Stock: 1 Our Price: $89.63
5	001310955	Lh Carburettor Control Shaft	1 req	Avail to order Our Price: $14.09
6	001311534	Intake Manifold Union	1 req	Avail to order Our Price: $31.61
7	N91116801	WASHER	2 req	Current Stock: 1 Our Price: $8.93
8	001311533	Intake Manifold Nipple Bolt	1 req	Avail to order Our Price: $22.07
9	001310960	Fuel Filter Seal	8 req	Current Stock: 2 Our Price: $7.09
10	008410503	Washer Din 137a 5.3x10 Zgd.	16 req	Avail to order Our Price: $2.00
11	N10689901	HEX.NUT	16 req	Current Stock: 5 Our Price: $2.00
12	001300804	Head Unit	5 req	Avail to order Our Price: $13.72
13	N10689901	HEX.NUT	5 req	Current Stock: 5 Our Price: $2.00
14	001310956	Carburettor Tierod	4 req	Avail to order Our Price: $18.42
15	008200504	M5 Lh. Special Nut	5 req	Avail to order Our Price: $18.56
16	400721214E	BALL JOINT HEAD (LEFT HAND THREAD)	5 req	Avail to order Our Price: $68.19
17	001310948	Carburettor Rod Pulley	1 req	Avail to order Our Price: $97.21
18	001310950	Carburettor Pulley Shim	1 req	Avail to order Our Price: $4.25
19	001310944	Intake Manifold Union Pipe	2 req	Avail to order Our Price: $6.04
20	WHT001514	SPRING WASHER	16 req	Current Stock: 9 Our Price: $26.80
21	008200806	M8 Uni 5588/8g/Z Nut	16 req	Current Stock: 25 Our Price: $2.00
22	001319569	Carburettor Connection Pipe As	1 req	Avail to order Our Price: $1,856.19
23	001319565	Rh/Lh Carburettor Assembly Tie	1 req	Avail to order Our Price: $102.43
24	006220772	Tank Fuel Recirculation Pipe	1 req	Avail to order Our Price: $32.06
25	001319554	Rear Carburettors	2 req	Avail to order Our Price: $526.29
26	001310958	Manifold/CarburettorShim	4 req	Avail to order Our Price: $45.77
27	001319921	Seal Between Manifolds & Carbu	8 req	Current Stock: 1 Our Price: $14.35
28	001319919	This item is no longer available	3 req
29	N01020717	HEXAGON HEAD BOLT	1 req	Current Stock: 4 Our Price: $2.00
30	001310949	Carburettor Wire Adjustment Cy	1 req	Avail to order Our Price: $43.39
31	004220814	Accelerator Bowden Wire	1 req	Avail to order Our Price: $7.96
32	001311580	Carburettor Drive Shaft Lever	2 req	Current Stock: 1 Our Price: $386.15
33	001310964	Carburettor Rh ShaftSpring	1 req	Avail to order Our Price: $12.38
34	008300820	Stud M8x25 Uni 5911 8g Zd	16 req	Avail to order Our Price: $2.45
35	001319918	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
36	001319553	Front Carburettors	2 req	Avail to order Our Price: $526.29
37	001312155	Seal	4 req	Avail to order Our Price: $4.18
38	001312131	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
39	004221664	This item is no longer available	4 req
40	001111782	Sensor Fitting Connection	4 req	Avail to order Our Price: $75.74
41	008300820	Stud M8x25 Uni 5911 8g Zd	16 req	Avail to order Our Price: $2.45
42	WHT001514	SPRING WASHER	16 req	Current Stock: 9 Our Price: $26.80
43	008200811	M8 Uni 5589/8g/ZdNut	16 req	Avail to order Our Price: $6.79
44	N0211963	HEX.HEAD CLAMPING	2 req	Avail to order Our Price: $2.00
45	008410503	Washer Din 137a 5.3x10 Zgd.	2 req	Avail to order Our Price: $2.00
46	008100826	Screw M8x16 Uni 5739/8g/Z	2 req	Avail to order Our Price: $2.00
47	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
48	004211724	Starter Guard	1 req	Avail to order Our Price: $102.13
49	004221088	This item is no longer available	1 req
50	004221425	This item is no longer available	1 req
50	004220430	This item is no longer available	1 req
51	003319356	Lever Button	1 req	Avail to order Our Price: $41.23
52	004212259	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
53	008700413	Lock Screw 4.2x12.7din798	1 req	Avail to order Our Price: $6.79
54	001311140	Fuel Pipe Clamp	1 req	Avail to order Our Price: $12.01
55	008100809	Screw M8x22 Uni 5739/8g/Zd	1 req	Current Stock: 8 Our Price: $2.00
56	004211718	Starter Wire	1 req	Avail to order Our Price: $68.82
57	004220428	Starter Wire Sheath Bushing	1 req	Avail to order Our Price: $38.32
58	004212260	Starter Wire Pin	1 req	Avail to order Our Price: $19.68
59	N01152427	WASHER	1 req	Current Stock: 16 Our Price: $2.00
60	008820201	Split Pin 1.8x15 Uni 1336a	1 req	Current Stock: 19 Our Price: $7.60
61	004220429	Starter Wire Sheath	1 req	Avail to order Our Price: $25.72
62	008604401	Ring 44 mm Or	8 req	Current Stock: 4 Our Price: $2.00
63	008830903	Clamp	12 req	Avail to order Our Price: $14.02
64	001319213	Carburettor Control Shaft	1 req	Avail to order Our Price: $13.80
65	001613782	Three-Way Union	1 req	Avail to order Our Price: $4.03
66	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
67	008700637	Screw M6x30 Uni5923 12k/Zd	1 req	Avail to order Our Price: $6.87
68	N01020717	HEXAGON HEAD BOLT	2 req	Current Stock: 4 Our Price: $2.00
69	008410502	Washer D.5.3 Uni 1751/Zd	2 req	Current Stock: 33 Our Price: $2.00
70	008100618	Screw M6x20 Uni 5739/8g/Zd	1 req	Current Stock: 44 Our Price: $2.00
71	008410603	Washer D.6.4 Uni 1751/Zd	1 req	Avail to order Our Price: $2.00
72	001313153	Carburettor Lever	1 req	Avail to order Our Price: $148.80
73	001312152	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
74	001312982	Electromagnet	1 req	Avail to order Our Price: $169.97
75	001321663	Horn On Carburettors	4 req	Avail to order Our Price: $338.44
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
