1981-1988 Lamborghini Jalpa 3.5 USA RHD Pedals (28.42)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $327.24
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $74.72

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $496.66
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
002111112	Flywheel Flywheel	Avail to order Our Price: $1,182.26
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,671.52
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $294.96
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $80.00

Gaskets

PN	Item
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $329.42
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,022.15
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,326.35

Ignition

PN	Item	Diagram
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $629.88
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $37.60
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 28.42 - RHD Pedals

1981-1988 Lamborghini Jalpa 3.5 USA RHD Pedals (28.42)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004219984	Master Clutch Cylinder	1 req	Avail to order Our Price: $332.32
2	N0152785	WASHER	8 req	Current Stock: 71 Our Price: $2.00
3	008100812	Screw 8x1.25x16 Uni 5739/8	2 req	Avail to order Our Price: $2.00
4	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
5	004120600	Spare Tyre Bracket	1 req	Avail to order Our Price: $65.41
6	004221532	Brake & Clutch PedalBracket	1 req	Avail to order Our Price: $416.01
7	004206703	This item is no longer available	1 req
8	003219278	DISCONTINUED - NLA - CONTACT US	2 req	*See Description
9	008401018	Pump Fitting Washer	2 req	Avail to order Our Price: $2.00
10	004220949	Master-Vac D8 Brake Booster an	1 req	Avail to order Our Price: $4,083.30
11	003307535	Handbrake Wire Cover	1 req	Current Stock: 1 Our Price: $32.10
12	004211408	Accelerator Bowden Wire	1 req	Avail to order Our Price: $28.24
13	004222888	Accelerator Wire Sheath	1 req	Avail to order Our Price: $107.74
14	004221086	Accelerator Wire Sheath From B	1 req	Avail to order Our Price: $18.87
15	004221087	Sheath Terminal On Bushing & P	1 req	Avail to order Our Price: $18.87
16	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
17	008100610	This item is no longer available	2 req
18	004221183	Bushing	1 req	Avail to order Our Price: $155.67
19	004210310	This item is no longer available	1 req
20	004221087	Sheath Terminal On Bushing & P	1 req	Avail to order Our Price: $18.87
21	004221085	Accelerator Wire Sheath From B	1 req	Avail to order Our Price: $20.42
22	004208714	Brake & Clutch Cylinder Pin	1 req	Avail to order Our Price: $405.44
23	004208713	Clutch Pedal Fork	1 req	Avail to order Our Price: $43.53
24	008200806	M8 Uni 5588/8g/Z Nut	1 req	Current Stock: 25 Our Price: $2.00
25	004207085	Brake Cylinder Pin Stopper	2 req	Avail to order Our Price: $80.80
26	008100826	Screw M8x16 Uni 5739/8g/Z	1 req	Avail to order Our Price: $2.00
27	002121184	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
28	004221529	Pedal Board Bracket Clutch Cyl	1 req	Avail to order Our Price: $109.22
29	008100827	Screw M8x25 Uni 5739/8g/Zg	3 req	Current Stock: 14 Our Price: $2.00
30	004221537	Clutch Control LeverAssembly	1 req	Avail to order Our Price: $208.73
31	008700809	Screw M8x25 Uni 5933/8g/Z	1 req	Avail to order Our Price: $2.00
32	008900403	Elastic Pin 4x30 Din1481	2 req	Avail to order Our Price: $2.65
33	008801802	Bushing 18x20x15 mm	3 req	Avail to order Our Price: $49.75
34	004206788	This item is no longer available	1 req
35	004209702	Clutch Pedal Spring	1 req	Avail to order Our Price: $32.53
36	N90179103	WASHER	10 req	Current Stock: 5 Our Price: $2.00
37	008200804	Nut	10 req	Current Stock: 7 Our Price: $2.00
38	008401816	Washer	1 req	Avail to order Our Price: $2.65
39	004209703	Brake Pedal Spring	1 req	Avail to order Our Price: $32.53
40	004221538	Brake Booster Fork Pin	1 req	Avail to order Our Price: $16.88
41	004221539	Clutch Pedal Servo Fork	1 req	Avail to order Our Price: $22.38
42	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.29
43	002104216	Clutch Lever Return Spring	1 req	Avail to order Our Price: $46.19
44	008100632	Screw M6x30 Uni 5739-65a 5	1 req	Avail to order Our Price: $2.65
45	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
46	004209708	Accelerator Transmission Pin	1 req	Avail to order Our Price: $19.66
47	008581101	O-Ring E 12 Uni 7435-75	1 req	Avail to order Our Price: $6.29
48	004209705	Carburettor Spindle	1 req	Avail to order Our Price: $44.39
49	400721214E	BALL JOINT HEAD (LEFT HAND THREAD)	1 req	Avail to order Our Price: $53.75
50	004210185	Accelerator Pedal Lever	1 req	Avail to order Our Price: $112.37
51	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
52	008100618	Screw M6x20 Uni 5739/8g/Zd	2 req	Current Stock: 44 Our Price: $2.00
53	008801204	Bushing 7x16x18 mm	2 req	Current Stock: 1 Our Price: $10.08
54	001300804	Head Unit	1 req	Avail to order Our Price: $12.73
55	004209706	Accelerator Tierod	1 req	Avail to order Our Price: $41.68
56	004210467	Rest Pedal	1 req	Avail to order Our Price: $187.99
57	004203120	This item is no longer available	2 req
58	N01152427	WASHER	2 req	Avail to order Our Price: $2.00
59	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
60	004221534	Clutch Pedal	1 req	Avail to order Our Price: $393.14
61	004201212	Brake Pedal Cover	2 req	Avail to order Our Price: $57.78
62	008922501	Rear Exhaust Mount	2 req	Avail to order Our Price: $7.51
63	004221533	Brake Pedal	1 req	Avail to order Our Price: $497.50
64	004209707	Accelerator Pedal	1 req	Avail to order Our Price: $413.16
65	008801204	Bushing 7x16x18 mm	2 req	Current Stock: 1 Our Price: $10.08
66	004209704	Accelerator Pedal Bracket	1 req	Avail to order Our Price: $74.34
67	WHT002961	WASHER	1 req	Current Stock: 39 Our Price: $2.00
68	008100607	Screw M6x18 Uni 5739/5s/Z	1 req	Avail to order Our Price: $6.29
69	N90612002	PAN HEAD BOLT	3 req	Current Stock: 37 Our Price: $2.00
70	WHT001197A	WASHER	3 req	Current Stock: 2 Our Price: $2.00
71	008801807	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
