1981-1988 Lamborghini Jalpa 3.5 USA Pedals (25.42)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 25.42 - Pedals

1981-1988 Lamborghini Jalpa 3.5 USA Pedals (25.42)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004219032	NLA (No Longer Available)	1 req	*See Description
2	004206783	NLA	1 req	*See Description
3	004113503	RH/LH Upper Spare Wheel Bracke	1 req	Avail to order Our Price: $104.96
4	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $26.80
5	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
6	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
7	004220467	Clutch /Brake Pedal Bracket	1 req	Avail to order Our Price: $435.35
8	008100827	Screw M8x25 Uni 5739/8g/Zg	6 req	Current Stock: 14 Our Price: $2.00
9	N90179103	WASHER	6 req	Current Stock: 5 Our Price: $2.00
10	N0111849	HEX.HEAD CLAMPING NUT	6 req	Current Stock: 5 Our Price: $2.39
11	004208705	Accelerator Pedal	1 req	Avail to order Our Price: $465.17
12	004203128	Accelerator Pedal Cover Countach	1 req	Avail to order Our Price: $93.34
13	004208709	Accelerator Wire Lever	1 req	Avail to order Our Price: $39.22
14	001300803	Lever Ball Joint	1 req	Current Stock: 5 Our Price: $38.47
15	002104216	Clutch Lever Return Spring	1 req	Avail to order Our Price: $48.83
16	003307535	Handbrake Wire Cover	1 req	Current Stock: 1 Our Price: $34.44
17	004220939	NLA Clutch Cylinder	1 req	*See Description
18	004208710	Brake Pedal Return Spring	1 req	Avail to order Our Price: $34.97
19	004206788	This item is no longer available	1 req
20	008922501	Rear Exhaust Mount	2 req	Avail to order Our Price: $8.13
21	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
22	004201212	Brake Pedal Cover	2 req	Avail to order Our Price: $61.09
23	002111422	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
24	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
25	008700802	Allen Screw M8x50 Uni 5931 10k	2 req	Current Stock: 30 Our Price: $2.00
26	004220464	Shim	1 req	Avail to order Our Price: $76.19
27	008200806	M8 Uni 5588/8g/Z Nut	1 req	Current Stock: 25 Our Price: $2.00
28	004208714	Brake & Clutch Cylinder Pin	2 req	Avail to order Our Price: $428.06
29	004208713	Clutch Pedal Fork	2 req	Avail to order Our Price: $46.74
30	004207085	Brake Cylinder Pin Stopper	2 req	Avail to order Our Price: $85.47
31	004208711	Clutch Pedal Return Spring	2 req	Avail to order Our Price: $83.95
32	008900403	Elastic Pin 4x30 Din1481	2 req	Avail to order Our Price: $2.91
33	008801401	Bushing 14x18x57.5 mm	1 req	Avail to order Our Price: $21.69
34	004208703	Brake Pedal	1 req	Avail to order Our Price: $420.44
35	008801204	Bushing 7x16x18 mm	2 req	Current Stock: 1 Our Price: $10.89
36	N90612002	PAN HEAD BOLT	3 req	Current Stock: 37 Our Price: $2.00
37	004209247	Accelerator Pedal Bracket	1 req	Avail to order Our Price: $79.92
38	008410603	Washer D.6.4 Uni 1751/Zd	1 req	Avail to order Our Price: $2.00
39	008100618	Screw M6x20 Uni 5739/8g/Zd	1 req	Current Stock: 44 Our Price: $2.00
40	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
41	008100632	Screw M6x30 Uni 5739-65a 5	1 req	Avail to order Our Price: $2.91
42	004210467	Rest Pedal	1 req	Avail to order Our Price: $202.03
43	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $2.00
44	N01118312	HEX.HEAD CLAMPING NUT	2 req	Avail to order Our Price: $2.17
45	008801402	Bushing 14x16x15 mm	2 req	Avail to order Our Price: $20.13
46	008401411	Washer 14x35x1-1.5-2	1 req	Avail to order Our Price: $11.59
47	008800803	Bushing 8x12x8 mm	2 req	Avail to order Our Price: $7.08
48	004210768	Clutch Pedal	1 req	Avail to order Our Price: $420.44
49	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
50	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
51	008300825	Stud M8x22 Uni 5911 10k Z	2 req	Avail to order Our Price: $15.26
52	004210769	Brake Clutch Pedal Pin	1 req	Avail to order Our Price: $207.24
53	004211182	Servo Clutch Pedal Spring	1 req	Avail to order Our Price: $34.97
55	008200811	M8 Uni 5589/8g/ZdNut	2 req	Avail to order Our Price: $6.79
56	N01152427	WASHER	2 req	Current Stock: 16 Our Price: $2.00
64	004210776	Clutch Spring Tierod	1 req	Avail to order Our Price: $63.66
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
