TAV: 41.62 - Fuel System

1981-1988 Lamborghini Jalpa 3.5 USA Fuel System (41.62)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	006205360	Float Dimmer Seal	1 req	Current Stock: 14 Our Price: $114.96
2	008410404	Corrugated Washer D.4.1 Uni370	6 req	Avail to order Our Price: $2.00
3	008200401	M4 Uni 5587/5s/Z	6 req	Avail to order Our Price: $2.00
4	006208724	FUEL SENDING UNIT	1 req	Avail to order Our Price: $850.46
5	008830901	NLA (No Longer Available)	8 req	*See Description
6	006220228	Exhaust Gas Pigtail	2 req	Avail to order Our Price: $42.05
7	008830111	NLA (No Longer Available)	2 req	*See Description
8	006220233	This item is no longer available	2 req
9	008700413	Lock Screw 4.2x12.7din798	2 req	Avail to order Our Price: $6.79
10	006220232	This item is no longer available	1 req
11	006220229	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
12	006220221	Rh Fuel Tank	1 req	Avail to order Our Price: $4,035.33
13	006208728	Lh Tank Breather Pipe	1 req	Avail to order Our Price: $6.04
14	008830903	Clamp	19 req	Avail to order Our Price: $14.02
15	WHT002961	WASHER	3 req	Current Stock: 38 Our Price: $2.00
16	008100506	Screw M5x14 Uni 5739	3 req	Avail to order Our Price: $11.93
17	006211030	This item is no longer available	1 req
18	006220327	Fuel Flap Cup	1 req	Avail to order Our Price: $68.74
19	006220985	FUEL FILLER CAP & KEY COUNTACH-JALPA	1 req	Avail to order Our Price: $61.06
20	006208726	Fuel Tank Pipe Boot	1 req	Avail to order Our Price: $34.52
21	006220772	Tank Fuel Recirculation Pipe	1 req	Avail to order Our Price: $32.06
22	006209751	This item is no longer available	1 req
23	006220275	Rh Tank Cover Bulkhead	1 req	Avail to order Our Price: $199.04
24	006220230	Rh Tank/Pigtail Breather Pipe	1 req	Avail to order Our Price: $49.73
25	006220834	This item is no longer available	4 req
26	008100809	Screw M8x22 Uni 5739/8g/Zd	5 req	Current Stock: 8 Our Price: $2.00
27	WHT001514	SPRING WASHER	5 req	Current Stock: 9 Our Price: $26.80
28	N90179103	WASHER	5 req	Current Stock: 5 Our Price: $2.00
29	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
30	WHT001942	WASHER	4 req	Current Stock: 13 Our Price: $3.51
31	008100827	Screw M8x25 Uni 5739/8g/Zg	4 req	Current Stock: 14 Our Price: $2.00
32	006208729	Rh Tank Breather Pipe	1 req	Avail to order Our Price: $26.10
33	008100630	Screw M6x14 Uni 5739/8g/Z	2 req	Avail to order Our Price: $2.00
34	006210989	Fuel Filter Bracket	1 req	Avail to order Our Price: $62.77
35	008835004	Clamp	2 req	Avail to order Our Price: $10.86
36	006220218	Lh Filling Pipe Connecting Sle	1 req	Avail to order Our Price: $336.21
37	006208736	Engine Filter Pipe Guard	2 req	Avail to order Our Price: $13.35
38	006220772	Tank Fuel Recirculation Pipe	1 req	Avail to order Our Price: $32.06
39	001304420	Fuel Pump Ground Wire	1 req	Avail to order Our Price: $3.35
40	008100613	Screw M6x10 Uni 5739/5s/Z	2 req	Avail to order Our Price: $2.00
41	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
42	006220011	Fuel Filter	1 req	Avail to order Our Price: $314.68
43	006220276	Rh Tank Cover Bulkhead	1 req	Avail to order Our Price: $199.04
44	001303074	NLA	1 req	*See Description
45	008610701	Grommet 7x13x2 mm	2 req	Avail to order Our Price: $34.52
46	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $2.00
47	N01100637	HEX.NUT	2 req	Current Stock: 18 Our Price: $2.00
48	006220231	This item is no longer available	1 req
49	006208730	Tank Union Pipe	1 req	Avail to order Our Price: $341.86
50	006220222	Lh Fuel Tank	1 req	Avail to order Our Price: $4,035.33
51	008833501	Clamp	2 req	Avail to order Our Price: $11.93
52	008401804	Annealed Copper Washer 18.2x30	2 req	Avail to order Our Price: $4.70
53	001303057	Fuel Intake Nipple Bolt	1 req	Avail to order Our Price: $721.61
54	006211602	NLA (No Longer Available)	1 req	*See Description
55	001304214	NLA (No Longer Available)	2 req	*See Description
56	006208727	Fuel Tank/Pump Hose	1 req	Avail to order Our Price: $32.06
57	001301474	Fibre Seal 14x10x2	4 req	Current Stock: 4 Our Price: $4.41
58	001304211	Fuel Pump Union Screw	2 req	Current Stock: 3 Our Price: $14.02
59	006210974	Pump/Fuel Filter Pipe	1 req	Avail to order Our Price: $71.87
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
