1981-1988 Lamborghini Jalpa 3.5 USA Steering (29.43)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 29.43 - Steering

1981-1988 Lamborghini Jalpa 3.5 USA Steering (29.43)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004319411	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
2	008201411	M14 Uni 5589 8g/ZNut	2 req	Avail to order Our Price: $19.61
3	004319410	Rack Arm Tierod	1 req	Avail to order Our Price: $378.69
4	008100846	Screw M8x70 Uni 5737-65a 1	3 req	Avail to order Our Price: $8.80
5	N90179103	WASHER	8 req	Current Stock: 5 Our Price: $2.00
6	008201412	M14x1.5 Lh Special Nut	1 req	Avail to order Our Price: $21.40
7	004309272	Shim	1 req	Avail to order Our Price: $14.76
8	008921401	Hyperbloc	2 req	Avail to order Our Price: $84.09
9	004307089	This item is no longer available	1 req
10	008201010	M10Self Locking Nut	1 req	Avail to order Our Price: $2.00
11	008401006	Washer 22x10.5x2.5 Uni 1734/5s	2 req	Current Stock: 1 Our Price: $2.00
12	WHT000768	SPRING WASHER	1 req	Current Stock: 17 Our Price: $2.09
13	008101019	Screw M10x1.5x45 Uni5737/	1 req	Avail to order Our Price: $5.22
14	004308739	Steering Damper	1 req	Avail to order Our Price: $450.26
15	N0152785	WASHER	1 req	Current Stock: 71 Our Price: $2.00
16	N0111849	HEX.HEAD CLAMPING NUT	1 req	Current Stock: 5 Our Price: $2.39
17	004307097	Rack Bracket	1 req	Avail to order Our Price: $64.41
18	008200804	Nut	5 req	Current Stock: 7 Our Price: $2.00
19	N01033520	HEXAGON HEAD BOLT	4 req	Current Stock: 6 Our Price: $2.00
20	004319874	Light & Wiper Stalk Assembly	1 req	Avail to order Our Price: $153.57
20	006120590	Wiper Control	1 req	Avail to order Our Price: $292.23
21	008574501	O-Ring I 42 Uni 3654	1 req	Current Stock: 7 Our Price: $2.01
22	008700601	Screw M6x30 Uni 59318g/Z	4 req	Avail to order Our Price: $6.79
23	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $2.00
24	008401217	Washer12 Allen Screw5s	2 req	Current Stock: 3 Our Price: $6.79
25	008201215	Nut	2 req	Avail to order Our Price: $11.93
26	004319412	LHD Rack	1 req	Avail to order Our Price: $3,078.73
27	004319861	Steering Joint UpperConnection	1 req	Avail to order Our Price: $143.28
28	N01152427	WASHER	8 req	Current Stock: 16 Our Price: $2.00
29	004319655	Steering Joint	1 req	Avail to order Our Price: $169.23
30	004319860	Steering Joint UpperConnection	1 req	Avail to order Our Price: $106.75
31	004309787	Steering Column Joint	1 req	Avail to order Our Price: $468.15
32	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
33	N01024230	HEXAGON HEAD BOLT	4 req	Current Stock: 4 Our Price: $2.00
34	004313277	LIGHT / HORN SWITCH	1 req	Avail to order Our Price: $1,801.41
35	WHT003079	Reference Pin 8h7x6.25x10	2 req	Avail to order Our Price: $35.64
36	004309680	Steering Wheel Plate	1 req	Avail to order Our Price: $12.75
37	008100308	This item is no longer available	2 req
38	004308355	NLA (No Longer Available)	1 req	*See Description
39	008700408	Screw M4x10 Uni 5931/8g/Z	1 req	Avail to order Our Price: $2.00
40	004320420	This item is no longer available	1 req
41	008401417	Washer 15x25x2 Uni 1736/Zd Aq4	1 req	Current Stock: 1 Our Price: $3.43
42	WHT003099	NUT	1 req	Avail to order Our Price: $17.87
43	004309646	Steering Wheel LowerBracket	1 req	Avail to order Our Price: $736.52
44	004309647	Steering Wheel UpperBracket	1 req	Avail to order Our Price: $651.53
45	008581801	O-Ring E 20 Uni 7435-75	4 req	Current Stock: 18 Our Price: $2.00
46	008502007	BEARING	2 req	Current Stock: 4 Our Price: $38.19
47	004301397	Indicator Return Lever Pin	1 req	Avail to order Our Price: $27.73
48	004309661	Upper Steering Column	1 req	Avail to order Our Price: $383.16
49	004309278	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
50	004309277	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
52	004319677	Rack Arm	1 req	Avail to order Our Price: $578.48
53	008100846	Screw M8x70 Uni 5737-65a 1	2 req	Avail to order Our Price: $8.80
54	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
55	008921401	Hyperbloc	2 req	Avail to order Our Price: $84.09
56	004319410	Rack Arm Tierod	2 req	Avail to order Our Price: $378.69
57	004307098	Rack Mounting U Bolt	1 req	Avail to order Our Price: $83.95
58	004309660	Rack Bracket Cover	1 req	Avail to order Our Price: $83.50
59	008100843	Screw M8x90 Uni 5737/8g	2 req	Avail to order Our Price: $2.00
60	008401217	Washer12 Allen Screw5s	2 req	Current Stock: 3 Our Price: $6.79
61	008201215	Nut	2 req	Avail to order Our Price: $11.93
61	004309276	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
62	004307097	Rack Bracket	1 req	Avail to order Our Price: $64.41
63	004319676	RHD Rack	1 req	Avail to order Our Price: $3,153.27
64	004313663	Rack Cushion Bracket	1 req	Avail to order Our Price: $114.35
65	004309926	Rack Rubber Ring	1 req	Avail to order Our Price: $235.56
66	004309659	Rack Bracket	1 req	Avail to order Our Price: $83.50
67	008200806	M8 Uni 5588/8g/Z Nut	8 req	Current Stock: 25 Our Price: $2.00
68	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
69	N01033520	HEXAGON HEAD BOLT	4 req	Current Stock: 6 Our Price: $2.00
70	004319861	Steering Joint UpperConnection	1 req	Avail to order Our Price: $143.28
71	004319860	Steering Joint UpperConnection	1 req	Avail to order Our Price: $106.75
72	004319655	Steering Joint	1 req	Avail to order Our Price: $169.23
73	008400806	Washer 15x8x1.5 Uni 1750 R40/Z	4 req	Current Stock: 5 Our Price: $2.00
74	004320407	This item is no longer available	1 req
75	004309788	Rack Joint	1 req	Avail to order Our Price: $368.26
76	007814024	This item is no longer available	1 req
77	004309666	Rack Rubber Bushing	2 req	Avail to order Our Price: $29.23
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
