1981-1988 Lamborghini Jalpa 3.5 USA Dashboard And Tunnel (44.78)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 44.78 - Dashboard And Tunnel

1981-1988 Lamborghini Jalpa 3.5 USA Dashboard And Tunnel (44.78)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	410819077	DIFFERENTIAL UNION PIPE	3 req	Avail to order Our Price: $42.96
2	009414507	AC VENT (LARGE FLANGE)	3 req	Avail to order Our Price: $37.35
3	007814003	This item is no longer available	1 req
3	007814058	Gd Raw Dash Board	1 req	Avail to order Our Price: $10,924.36
4	007014041	This item is no longer available	1 req
5	007814027	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
5	007814057	This item is no longer available	1 req
6	007814056	This item is no longer available	1 req
6	007814026	This item is no longer available	1 req
7	007814002	Dashboard Box Floor	1 req	Avail to order Our Price: $121.67
7	007814052	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
8	007814017	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
9	007814084	Speedor Inn. ReinforSheet	1 req	Avail to order Our Price: $273.49
9	007814070	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
10	007814067	This item is no longer available	1 req
10	007814011	Door Lid Pad	1 req	Avail to order Our Price: $608.29
11	007814080	Upper Profile SheetSteel	1 req	Avail to order Our Price: $273.49
12	007814046	Rough Instrument Panel Support	1 req	Avail to order Our Price: $1,625.09
12	007814059	Base Instr.Support	1 req	Avail to order Our Price: $1,625.09
13	007814031	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
14	007814049	Lh Steering Col.Cover.	1 req	Avail to order Our Price: $781.80
14	007814060	Radio Carrier	1 req	Avail to order Our Price: $820.44
15	007814061	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
15	007814051	Rh Steering Col.Cover.	1 req	Avail to order Our Price: $781.80
16	007814032	Instr.Panel	1 req	Avail to order Our Price: $2,994.91
17	007814033	Instr.Panel	1 req	Avail to order Our Price: $1,642.38
17	007814075	Instr.Panel	1 req	Avail to order Our Price: $2,437.64
18	007809003	Air Conditioner Frame	1 req	Avail to order Our Price: $648.55
19	007058001	NLA (No Longer Available)	1 req	*See Description
20	007014038	This item is no longer available	1 req
21	007814020	This item is no longer available	1 req
22	007814021	This item is no longer available	1 req
22	007814072	This item is no longer available	1 req
23	007014040	NLA	1 req	*See Description
24	007809011	Lever Comp.Lock Plate	1 req	Avail to order Our Price: $358.95
25	007809001	Tunnel	1 req	Avail to order Our Price: $8,110.54
26	007809014	This item is no longer available	1 req
27	007809002	Tunnel Box Lid	1 req	Avail to order Our Price: $648.55
28	007809013	Tunnel Box Bottom Plate	1 req	Avail to order Our Price: $42.12
29	007809005	This item is no longer available	1 req
30	008200601	M6 Uni 5588-8g/Z Nut	6 req	Avail to order Our Price: $4.18
31	008700525	Allen Tapping Screw 50 mm	4 req	Avail to order Our Price: $2.09
31	008700524	Allen Lock Screw 26 mm	4 req	Current Stock: 7 Our Price: $2.46
32	WHT001942	WASHER	4 req	Current Stock: 13 Our Price: $3.51
33	008100621	Screw M6x20 Uni 5739/5s/Z	4 req	Avail to order Our Price: $2.00
35	N10689901	HEX.NUT	6 req	Current Stock: 5 Our Price: $2.00
36	WHT002961	WASHER	14 req	Current Stock: 38 Our Price: $2.00
37	008410302	This item is no longer available	4 req
38	008700205	Lock Screw 2.9x16x5.3 Din	17 req	Avail to order Our Price: $2.91
39	008700312	Lock Screw 2.9x9.5din7982	11 req	Avail to order Our Price: $2.91
40	008700204	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
