1981-1988 Lamborghini Jalpa 3.5 USA Front Suspension (37.51)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $327.24
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $74.72

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $496.66
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
002111112	Flywheel Flywheel	Avail to order Our Price: $1,182.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,671.52
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $294.96
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $80.00

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,022.15
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $329.42
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,326.35

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $629.88

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $37.60
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 37.51 - Front Suspension

1981-1988 Lamborghini Jalpa 3.5 USA Front Suspension (37.51)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
0	008407502	Washer 75x82.5x0.05	1 req	Avail to order Our Price: $18.73
0	008407501	Washer 75x82.5x0.5	2 req	Avail to order Our Price: $6.37
0	008504502	NLA (No Longer Available)	2 req	*See Description
0	008204501	M45x1.5 Uni 4535-64 Nut	2 req	Avail to order Our Price: $135.38
0	005121688	Rh Front Hub Holder	1 req	Avail to order Our Price: $267.34
0	005121689	Lh Front Hub Holder	1 req	Avail to order Our Price: $267.34
0	005120977	Rh Front Brake Disc Guard	1 req	Avail to order Our Price: $26.67
0	005120978	Lh Front Brake Disc Guard	1 req	Avail to order Our Price: $58.62
0	N01152427	WASHER	2 req	Avail to order Our Price: $2.00
0	N01118312	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 4 Our Price: $2.01
0	005108046	Odometer Gear	1 req	Avail to order Our Price: $2,961.12
0	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
0	008100624	Screw M6x25 Uni 5737/8g	1 req	Avail to order Our Price: $2.00
0	005106976	Lh Front Hub Carrier	1 req	Avail to order Our Price: $619.01
9	005106975	Rh Front Hub Carrier	1 req	Avail to order Our Price: $619.01
18	008610801	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	WHT001197A	WASHER	3 req	Current Stock: 2 Our Price: $2.00
19	008100622	Screw M6x12 Uni 5739/8g	3 req	Avail to order Our Price: $6.29
19	005113543	Odometer Wire	1 req	Avail to order Our Price: $392.41
19	005109581	Odometer Wire RHD	1 req	Current Stock: 1 Our Price: $360.26
40	005108654	Odometer Gear	1 req	Avail to order Our Price: $15.94
41	005106968	Front Wheel Hub	2 req	Avail to order Our Price: $1,333.80
42	005112242	Wheel Outer Cover	2 req	Avail to order Our Price: $243.27
43	008578201	O-Ring I 82 Uni 3654	2 req	Current Stock: 12 Our Price: $3.44
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
