1981-1988 Jalpa 3.5 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	AUXILIARY UNIT BELT AUXILIARY UNIT BELT		Avail to order Our Price: $376.76
004613685	AIR PUMP BELT AIR PUMP BELT NO LONGER AVAILABLE TO ORDER FROM FACTORY PLEASE CONTACT US FOR SUITABLE REPLACEMENT OPTIONS		Current Stock: 1 Our Price: $86.06

Brakes

PN	Item	Diagram
003135292	BRAKE PADS FRONT - JALPA - EARLY DIABLO - PER ROTOR FRONT BRAKE PADS		Avail to order Our Price: $569.87
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $88.85

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.84
007029005	BONNET LIFTER BONNET LIFTER		Current Stock: 4 Our Price: $103.15

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 17 Our Price: $94.21
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,668.87
002111111	CLUTCH PRESSURE PLATE CLUTCH PRESSURE PLATE	Current Stock: 1 Our Price: $2,982.84
002111112	FLYWHEEL FLYWHEEL	Avail to order Our Price: $1,140.28
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Current Stock: 1 Our Price: $320.63
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $61.41
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 1 Our Price: $1,284.48

Fuel-Air

PN	Item
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $105.28
006220011	FUEL FILTER FUEL FILTER	Avail to order Our Price: $283.12
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $23.90

Fuses-Bulbs-Relays

PN	Item
006311154	RELAY RELAY	Avail to order Our Price: $50.32
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $8.88
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.35
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $10.69
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $18.24
006617106	12V 60/55W BULB 12V 60/55W BULB	Avail to order Our Price: $76.74

Gaskets

PN	Item
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $379.94
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $987.05
001526492	ENGINE GASKET KIT JALPA ENGINE GASKET KIT	Avail to order Our Price: $1,527.56

Ignition

PN	Item	Diagram
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $726.89

Misc

PN	Item
006121168	NLA (NO LONGER AVAILABLE) WIPER BLADE TYPE B	Avail to order Our Price: $36.25
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.57
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
001719309	COOLANT THERMOSTAT COOLANT THERMOSTAT FITS THE FOLLOWING: COUNTACH 5000 S, LP400 ESPADA JALPA 3.5 URRACO P30	Avail to order Our Price: $395.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $164.05
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $580.56

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 88 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 12.21 - Clutch

1981-1988 Lamborghini Jalpa 3.5 USA Clutch (12.21)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008410801	CHECK WASHER	4 req	Current Stock: 16 Our Price: $0.80
2	008100863	SPECIAL SCREW M8X20	8 req	Avail to order Our Price: $3.14
3	002111112	FLYWHEEL	1 req	Avail to order Our Price: $1,140.28
4	002109862	CLUTCH PLATE	1 req	Current Stock: 1 Our Price: $1,284.48
5	002111111	CLUTCH PRESSURE PLATE	1 req	Current Stock: 1 Our Price: $2,982.84
6	002108644	THRUST BEARING	1 req	Current Stock: 1 Our Price: $1,668.87
7	002108643	SLEEVE	1 req	Avail to order Our Price: $335.23
8	008580601	O-RING E 6 UNI 7435-75	1 req	Avail to order Our Price: $2.67
9	N01152427	WASHER	1 req	Current Stock: 11 Our Price: $0.36
10	002108640	NLA	1 req	*See Description
11	002106838	CLUTCH CYLINDER ROD	1 req	Avail to order Our Price: $61.41
12	008583701	O-RING E 37 UNI 7435-75	1 req	Current Stock: 8 Our Price: $0.60
12	008583201	O-RING E 32 UNI 7435-75	1 req	Current Stock: 17 Our Price: $1.10
13	002109407	CLUTCH CYLINDER RETURN SPRING	1 req	Avail to order Our Price: $43.71
14	002120932	NLA (NO LONGER AVAILABLE)	1 req	*See Description
14	002106604	DISCONTINUED - NLA - CONTACT US	1 req	*See Description
15	002106605	CYLINDER SPRING CONTAINER	1 req	Avail to order Our Price: $8.81
16	WHT003078	REFERENCE PIN 8H7X16C40	1 req	Avail to order Our Price: $49.87
17	008580501	CIRCLIP D.6 UNI 3656	3 req	Current Stock: 18 Our Price: $1.00
18	008850609	TEMPERED PIN 6X16 MM	3 req	Avail to order Our Price: $31.40
19	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $0.58
20	N10517304	12-POINT SOCKET	6 req	Current Stock: 5 Our Price: $3.64
21	008581401	CIRCLIP D. MM16 UNI 3656	1 req	Avail to order Our Price: $2.67
22	002108641	CLUTCH LEVER ROD	1 req	Avail to order Our Price: $34.20
23	008201011	M10 UNI 5589-65/8G NUT	1 req	Avail to order Our Price: $19.26
24	002121242	CLUTCH CYLINDER HOSE	1 req	Avail to order Our Price: $372.76
24	002108649	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
