1981-1988 Lamborghini Jalpa 3.5 USA Chassis (23.41)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 23.41 - Chassis

1981-1988 Lamborghini Jalpa 3.5 USA Chassis (23.41)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004113488	Lh Coolant Radiator & Conditio	1 req	Avail to order Our Price: $210.22
2	N0152785	WASHER	8 req	Current Stock: 71 Our Price: $2.00
3	008100826	Screw M8x16 Uni 5739/8g/Z	10 req	Avail to order Our Price: $2.00
4	N0111849	HEX.HEAD CLAMPING NUT	2 req	Current Stock: 5 Our Price: $2.39
5	N90179103	WASHER	2 req	Current Stock: 5 Our Price: $2.00
6	004120244	Radiator Front Crossmember	1 req	Avail to order Our Price: $205.75
7	004113493	Rh Coolant Radiator & Conditio	1 req	Avail to order Our Price: $210.22
8	004120669	Rh Shock Absorber Shim on Chas	1 req	Avail to order Our Price: $167.73
9	N01100845	HEX.NUT	8 req	Current Stock: 17 Our Price: $2.09
10	008401006	Washer 22x10.5x2.5 Uni 1734/5s	1 req	Current Stock: 1 Our Price: $2.00
11	008201010	M10Self Locking Nut	1 req	Avail to order Our Price: $2.00
12	N90179103	WASHER	3 req	Current Stock: 5 Our Price: $2.00
13	008700815	Screw	3 req	Current Stock: 18 Our Price: $2.00
14	004111845	Reaction Strut Mounting	1 req	Avail to order Our Price: $69.93
15	008100840	Screw M8x1.25x18 Uni5739/	4 req	Current Stock: 7 Our Price: $2.00
16	WHT001942	WASHER	4 req	Current Stock: 13 Our Price: $3.51
17	006113501	Engine Bulkhead	1 req	Avail to order Our Price: $463.73
18	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
19	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
20	004513465	Abacus Compressor Bracket	1 req	Avail to order Our Price: $335.17
21	008101008	Screw M10x30uni 5739/8g/Zd	2 req	Current Stock: 3 Our Price: $17.20
22	008101048	Screw M10x1.5x35 Uni5737/	1 req	Avail to order Our Price: $4.25
23	004513467	Adjustment U-Bolt	1 req	Avail to order Our Price: $68.21
24	008201008	Nut	4 req	Current Stock: 2 Our Price: $2.00
25	008401007	Washer 21.5x10.4x2 Uni 6592/5s	2 req	Avail to order Our Price: $2.00
26	N90630504	HEX. BOLT WITH	2 req	Current Stock: 10 Our Price: $3.43
27	004519673	Rotary Compressor Small Bracke	2 req	Avail to order Our Price: $174.44
28	004111842	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
29	008201807	18x1 Right Nut	1 req	Avail to order Our Price: $27.73
30	008201603	Nut	1 req	Avail to order Our Price: $3.95
31	008401611	Washer 17x29x3 5s Uni 16592	1 req	Avail to order Our Price: $16.40
32	008921607	NLA (No Longer Available)	1 req	*See Description
33	004111843	Reaction Strut Bushing	1 req	Avail to order Our Price: $101.38
34	008101609	NLA (No Longer Available)	1 req	*See Description
35	008100508	Screw M5x10 Uni 5739/5s/Z	10 req	Avail to order Our Price: $6.79
36	008410502	Washer D.5.3 Uni 1751/Zd	10 req	Current Stock: 33 Our Price: $2.00
37	008111456	This item is no longer available	1 req
38	0B9501144	SILENTBLOC	1 req	Avail to order Our Price: $262.02
39	008401413	Flat Washer 14.3 Uni1750/Z	1 req	Current Stock: 11 Our Price: $2.00
40	008201406	Nut	1 req	Current Stock: 8 Our Price: $2.00
41	004111951	Gearbox Strut Mounting	1 req	Avail to order Our Price: $104.96
42	004120668	Lh Shock Absorber Shim on Chas	1 req	Avail to order Our Price: $167.73
43	004120291	This item is no longer available	1 req
44	008100620	Screw M6x12 Uni 5739/5s/Z	34 req	Avail to order Our Price: $6.79
45	WHT002961	WASHER	34 req	Current Stock: 38 Our Price: $2.00
46	004120246	Tunnel Front Lower Panel	1 req	Avail to order Our Price: $1,067.49
47	004120236	Lh Tank Cover Door	1 req	Avail to order Our Price: $142.23
48	004120235	Rh Tank Cover Door	1 req	Avail to order Our Price: $142.23
49	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
50	008200804	Nut	4 req	Current Stock: 7 Our Price: $2.00
51	008101409	Special Screw M14x75	1 req	Avail to order Our Price: $33.40
52	008201013	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
53	006111456	Rh Head Bulkhead	1 req	Avail to order Our Price: $48.83
54	WHT000768	SPRING WASHER	2 req	Current Stock: 17 Our Price: $2.09
55	004120292	Tunnel Rear Lower Panel	1 req	Avail to order Our Price: $719.38
56	004613682	This item is no longer available	1 req
57	008101802	Special Screw M18x1.5x23	1 req	Avail to order Our Price: $11.91
58	008401804	Annealed Copper Washer 18.2x30	2 req	Avail to order Our Price: $4.70
59	004613683	This item is no longer available	1 req
60	006121513	This item is no longer available	1 req
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
