1981-1988 Lamborghini Jalpa 3.5 USA Engine Chassis (24.41)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.37
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.10

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.64
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $98.99

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.48
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.94

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 20 Our Price: $86.47
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.83
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.25
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.21
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.46
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item
006220011	Fuel Filter Fuel Filter	Avail to order Our Price: $314.70
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.14
006311154	RELAY RELAY	Avail to order Our Price: $56.11
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.28
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.86
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.30

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.81
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.60
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.11

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $667.34

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.45
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.16
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.04
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00

Open All

Select Group and TAV

< Previous Next >

TAV: 24.41 - Engine Chassis

1981-1988 Lamborghini Jalpa 3.5 USA Engine Chassis (24.41)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	004110760	Rh Rear Crossmember Mount	1 req	Avail to order Our Price: $909.49
2	004106741	Rear Frame Grommet	10 req	Avail to order Our Price: $73.09
3	004108879	This item is no longer available	5 req
4	008411401	Corrugated Washer D.14.2 Uni 3	5 req	Avail to order Our Price: $2.92
5	008101407	Screw M14x55 Uni 5738/8g/Z	5 req	Avail to order Our Price: $6.22
6	008101408	Special Screw M14x80	4 req	Avail to order Our Price: $62.62
7	008921409	Rear Frame Grommet Support	8 req	Avail to order Our Price: $182.05
8	004108895	Engine Mount	2 req	Avail to order Our Price: $329.98
9	008401413	Flat Washer 14.3 Uni1750/Z	4 req	Current Stock: 11 Our Price: $2.00
10	008201406	Nut	4 req	Current Stock: 8 Our Price: $2.00
11	004108898	Gearbox Mount Flange	1 req	Avail to order Our Price: $101.42
12	008100830	Screw M8x20 Uni 5739/8g/Z	4 req	Current Stock: 19 Our Price: $2.00
13	004108897	Gearbox Mount	1 req	Avail to order Our Price: $69.92
14	008200804	Nut	8 req	Current Stock: 7 Our Price: $2.00
15	004110759	Lh Rear Crossmember Mount	1 req	Avail to order Our Price: $175.23
16	N90179103	WASHER	18 req	Current Stock: 5 Our Price: $2.00
17	008100856	Special Screw	6 req	Avail to order Our Price: $9.14
18	004119402	Engine Mount Frame	1 req	Avail to order Our Price: $8,207.45
18	004121410	This item is no longer available	1 req
19	004108899	Gearbox Mount On Differential	1 req	Avail to order Our Price: $104.92
20	008300822	Stud M8x18 Uni 5911 8g Z	4 req	Avail to order Our Price: $26.31
21	008100840	Screw M8x1.25x18 Uni5739/	4 req	Current Stock: 7 Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
