1981-1988 Lamborghini Jalpa 3.5 USA Oil Pump And System (7.15)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 7.15 - Oil Pump And System

1981-1988 Lamborghini Jalpa 3.5 USA Oil Pump And System (7.15)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	007853002	Radiator Air Duct	1 req	Avail to order Our Price: $243.77
2	008100625	Screw M6x16 Uni 5739/8g/Z	10 req	Avail to order Our Price: $140.00
3	N01152427	WASHER	10 req	Current Stock: 16 Our Price: $2.00
4	N01118312	HEX.HEAD CLAMPING NUT	10 req	Avail to order Our Price: $2.17
5	001520345	Oil Radiator	1 req	Avail to order Our Price: $642.09
6	001520326	Camshaft Joint Coupling	1 req	Avail to order Our Price: $46.07
7	001520335	Cross Coupling	1 req	Avail to order Our Price: $33.18
8	001520340	Inner Rotor Shaft	1 req	Avail to order Our Price: $45.93
9	001520311	Low Pressure Pump Casing Brack	1 req	Avail to order Our Price: $148.50
10	008300604	Stud M6x13 Uni 5914/8g/Zd	10 req	Avail to order Our Price: $22.52
11	001520632	Link Pipe From Pump	1 req	Avail to order Our Price: $118.68
12	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
13	008200601	M6 Uni 5588-8g/Z Nut	10 req	Avail to order Our Price: $4.18
14	008830206	Clamp	6 req	Current Stock: 1 Our Price: $23.26
15	001520827	OIL PUMP	1 req	Avail to order Our Price: $360.43
16	001520633	Link Pipe From Sump	1 req	Avail to order Our Price: $67.54
17	008300646	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
18	001520320	Oil Pump Outer Rotor	1 req	Avail to order Our Price: $463.68
19	001520325	Oil Pump Inner Rotor	1 req	Avail to order Our Price: $463.68
20	001520319	Low Pressure Pump Casing Cover	1 req	Avail to order Our Price: $45.33
21	001520299	Oil Radiator Bracket	2 req	Avail to order Our Price: $52.48
22	001520634	Radiator Union Assembly	2 req	Avail to order Our Price: $530.62
23	001507628	Oil Pressure Valve Plug	1 req	Avail to order Our Price: $22.07
24	001820625	Oil Sump Priming Assembly	1 req	Avail to order Our Price: $64.86
25	001508565	NLA (No Longer Available)	1 req	*See Description
26	001806009	Oil Pressure Transmission Redu	1 req	Avail to order Our Price: $31.17
27	008100830	Screw M8x20 Uni 5739/8g/Z	2 req	Current Stock: 19 Our Price: $2.00
28	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
29	001512706	Oil Filter Bracket	1 req	Avail to order Our Price: $183.38
30	008602301	Ring 24 mm Or	3 req	Current Stock: 2 Our Price: $2.01
31	001505918	Oil Filter Sleeve	1 req	Avail to order Our Price: $49.43
32	001820626	Lower Crankcase & Primer Seal	2 req	Avail to order Our Price: $15.59
33	001500927	Oil Pressure Valve Spring	1 req	Avail to order Our Price: $15.81
34	001810982	Oil Pressure Valve Piston	1 req	Avail to order Our Price: $48.83
35	001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa	1 req	Current Stock: 21 Our Price: $86.65
36	WHT002944	TAP END STUD	2 req	Avail to order Our Price: $17.87
37	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
38	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
39	N01022217	HEXAGON HEAD BOLT	2 req	Avail to order Our Price: $7.67
40	WHT001197A	WASHER	2 req	Current Stock: 2 Our Price: $2.00
41	001820624	Oil Return Pipe FromRadiator	1 req	Avail to order Our Price: $29.68
42	008603101	Ring 32 mm Or	1 req	Current Stock: 1 Our Price: $3.95
43	001811008	Oil Inlet Pipe	1 req	Avail to order Our Price: $72.83
44	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
45	008100618	Screw M6x20 Uni 5739/8g/Zd	2 req	Current Stock: 44 Our Price: $2.00
46	001810981	NLA (No Longer Available)	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
