1981-1988 Lamborghini Jalpa 3.5 USA Radiator And Coolant System (10.17)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $327.24
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $74.72

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $496.66
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
002111112	Flywheel Flywheel	Avail to order Our Price: $1,182.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,671.52
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $294.96
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $80.00

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,022.15
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $329.42
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,326.35

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $629.88

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $37.60
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 10.17 - Radiator And Coolant System

1981-1988 Lamborghini Jalpa 3.5 USA Radiator And Coolant System (10.17)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
2	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $25.05
3	008400814	Washer 8.25x22x2 Aq35 Zg	2 req	Current Stock: 14 Our Price: $2.00
4	001701495	Supplementary Reservoir Bracket	2 req	Current Stock: 1 Our Price: $55.25
5	001701592	Radiator Shim	2 req	Avail to order Our Price: $19.62
6	WHT001189	RUBBER WASHER MOUNT	2 req	Avail to order Our Price: $3.95
7	001720306	NLA (No Longer Available)	1 req	*See Description
8	001705504	Engine Thermal Contact Seal	1 req	Avail to order Our Price: $28.31
9	001701645	SEE PN: 1724565 AND 1724564	1 req	Avail to order Our Price: $48.00
10	008410403	Washer D.4.3 Uni 1751/Z	3 req	Avail to order Our Price: $7.08
11	008200402	M4 Brass Special Nut	3 req	Current Stock: 2 Our Price: $2.65
12	N01152427	WASHER	8 req	Avail to order Our Price: $2.00
13	N01118312	HEX.HEAD CLAMPING NUT	8 req	Current Stock: 4 Our Price: $2.01
14	001720302	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
14	001721203	Fan	2 req	Avail to order Our Price: $121.66
15	001708588	Coolant Radiator Pump Sleeve	1 req	Avail to order Our Price: $152.04
16	001708587	Radiator Outlet Union Pipe	1 req	Avail to order Our Price: $119.75
17	008833502	Wire Clamp D. 40 mm with screw	8 req	Avail to order Our Price: $14.05
18	001713510	Coolant Outlet FrontPipe	1 req	Avail to order Our Price: $293.07
19	008833801	Front Radiator Coolant Pipe Cl	1 req	Avail to order Our Price: $32.10
20	008410603	Washer D.6.4 Uni 1751/Zd	1 req	Avail to order Our Price: $2.00
21	008100605	Screw M6x40 Uni 5739-65a 5	1 req	Avail to order Our Price: $2.00
22	001713509	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
23	001708589	Coolant Circulation Union Pipe	2 req	Avail to order Our Price: $34.31
24	001708591	Radiator Inlet Intermediate Pi	1 req	Avail to order Our Price: $208.51
24	001709764	Radiator Outlet Pipe	1 req	Avail to order Our Price: $40.04
25	001713614	Coolant Central Adapter Pipe	1 req	Avail to order Our Price: $173.76
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
