1981-1988 Jalpa 3.5 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	AUXILIARY UNIT BELT AUXILIARY UNIT BELT		Avail to order Our Price: $396.26
004613685	AIR PUMP BELT AIR PUMP BELT NO LONGER AVAILABLE TO ORDER FROM FACTORY PLEASE CONTACT US FOR SUITABLE REPLACEMENT OPTIONS		Current Stock: 1 Our Price: $90.51

Brakes

PN	Item	Diagram
003135292	BRAKE PADS FRONT - JALPA - EARLY DIABLO - PER ROTOR FRONT BRAKE PADS		Avail to order Our Price: $599.37
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $94.74

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 6 Our Price: $28.85
007029005	BONNET LIFTER BONNET LIFTER		Current Stock: 4 Our Price: $109.98

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 19 Our Price: $99.09
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Current Stock: 1 Our Price: $402.08
002111112	FLYWHEEL FLYWHEEL	Avail to order Our Price: $1,215.94
002111111	CLUTCH PRESSURE PLATE CLUTCH PRESSURE PLATE	Current Stock: 1 Our Price: $3,137.27
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,779.60
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $65.48
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,369.70

Fuel-Air

PN	Item
006220011	FUEL FILTER FUEL FILTER	Avail to order Our Price: $301.91
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $105.28
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 2 Our Price: $25.14

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.47
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.37
006311154	RELAY RELAY	Avail to order Our Price: $53.65
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $19.44
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.40
006617106	12V 60/55W BULB 12V 60/55W BULB	Avail to order Our Price: $81.83

Gaskets

PN	Item
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,052.53
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA NLA GROMMET AND OIL SEALS SET JALPA - MIURA NO LONGER AVAILABLE TO ORDER FROM FACTORY.	Avail to order Our Price: $399.62
001526492	ENGINE GASKET KIT JALPA ENGINE GASKET KIT	Avail to order Our Price: $1,606.65

Ignition

PN	Item	Diagram
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $764.53

Misc

PN	Item
006121168	NLA (NO LONGER AVAILABLE) WIPER BLADE TYPE B	Avail to order Our Price: $38.65
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.57
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $82.84

Sensors

PN	Item
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $172.55
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $619.08
001719309	COOLANT THERMOSTAT COOLANT THERMOSTAT FITS THE FOLLOWING: COUNTACH 5000 S, LP400 ESPADA JALPA 3.5 URRACO P30	Avail to order Our Price: $395.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 89 Our Price: $15.72

Open All

Select Group and TAV

< Previous Next >

TAV: 33.46 - Air Pollution System

1981-1988 Lamborghini Jalpa 3.5 USA Air Pollution System (33.46)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	001612219	WELDING ASSEMBLY	2 req	Avail to order Our Price: $25.99
2	001711772	This item is no longer available	1 req
3	001613783	SOLENOID VALVE BRACKET	1 req	Avail to order Our Price: $33.28
4	001612049	SOLENOID VALVE/DISTRIBUTOR PIP	1 req	Avail to order Our Price: $4.61
5	001612048	LH HEAD/SOLENOID VALVE BAR PIP	1 req	Avail to order Our Price: $34.62
6	004613690	AIR DELIVERY LH INJECTORS	1 req	Avail to order Our Price: $299.81
7	004612976	GEARBOX OIL DELIVERYUNION PIPE	8 req	Avail to order Our Price: $34.62
8	004607188	DOUBLE TAPERS	8 req	Current Stock: 3 Our Price: $16.51
9	004421511	RH SAMPLER	1 req	Avail to order Our Price: $52.31
10	008700612	SCREW M6X25 UNI 5931/8G/ZD	4 req	Avail to order Our Price: $0.40
11	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.40
12	004613689	PUMP PULLEY BRACKET	1 req	Avail to order Our Price: $634.34
13	004613688	AIR PUMP GEAR	1 req	Avail to order Our Price: $401.60
14	006211596	FUEL PUMP SHIM	2 req	Avail to order Our Price: $5.11
15	008610701	GROMMET 7X13X2 MM	2 req	Avail to order Our Price: $33.03
16	WHT002961	WASHER	2 req	Current Stock: 38 Our Price: $0.50
17	N10430103	HEXALOBULAR SOCKET	2 req	Current Stock: 21 Our Price: $1.70
18	008401701	WASHER	1 req	Avail to order Our Price: $19.70
19	410115207	BEARING	2 req	Avail to order Our Price: $38.15
20	008251702	M17X1X28 SELF-LOCKING RING NUT	1 req	Avail to order Our Price: $4.27
21	004618999	This item is no longer available	1 req
22	008700804	SCREW 8X1.5X25 5931 8G ZG	1 req	Avail to order Our Price: $1.84
23	WHT001514	SPRING WASHER	1 req	Current Stock: 9 Our Price: $28.20
24	004421512	LH SAMPLER	1 req	Avail to order Our Price: $52.31
25	008502507	BEARING	1 req	Current Stock: 4 Our Price: $32.03
26	008582601	O-RING E 26 UNI 7435-75	1 req	Avail to order Our Price: $6.53
27	008575001	O-RING	1 req	Current Stock: 10 Our Price: $1.10
28	008613202	OIL SEAL	1 req	Current Stock: 5 Our Price: $14.10
29	008830206	CLAMP	6 req	Current Stock: 1 Our Price: $22.30
30	004607187	NLA (NO LONGER AVAILABLE)	2 req	*See Description
31	008700501	SCREW M5X10 UNI 5933/12K/F	5 req	Current Stock: 3 Our Price: $3.02
32	004613684	ELECTROMAGNETIC COUPLING PULLE	1 req	Avail to order Our Price: $508.24
33	07M109381	O-RING SEAL RING	1 req	Current Stock: 25 Our Price: $1.91
34	008410603	WASHER D.6.4 UNI 1751/ZD	3 req	Avail to order Our Price: $0.10
35	008100605	SCREW M6X40 UNI 5739-65A 5	3 req	Avail to order Our Price: $0.30
36	008860503	TAB 5X5X25	1 req	Avail to order Our Price: $6.62
37	008100643	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	4 req	*See Description
38	WHT001197A	WASHER	4 req	Current Stock: 22 Our Price: $0.40
39	008101021	SCREW M10X1.5X125 UNI 5737	1 req	Avail to order Our Price: $20.54
40	004606295	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
41	004607438	DIVERTER FLANGE SEAL	1 req	Current Stock: 2 Our Price: $8.68
42	004606277	JOINT SHAFT	1 req	Avail to order Our Price: $480.57
43	004812760	This item is no longer available	1 req
44	004608477	AIR PUMP ADJUSTMENT	1 req	Avail to order Our Price: $93.96
45	004612760	WASHER	2 req	Avail to order Our Price: $128.36
46	008101046	This item is no longer available	1 req
47	004613685	AIR PUMP BELT	1 req	Current Stock: 1 Our Price: $90.51
48	004613687	COOLANT PUMP PULLEY	1 req	Avail to order Our Price: $409.48
49	004613691	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
50	004621317	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
51	004621114	This item is no longer available	1 req
52	004621116	2-WAY DIVERTER VALVE	1 req	Avail to order Our Price: $498.60
53	004624322	SMOG/AIR PUMP	1 req	Avail to order Our Price: $1,973.52
54	004606297	AIR PUMP PIPE SEAL	1 req	Avail to order Our Price: $8.04
55	004621314	DIVERTER/PIPE CONNECTING SLEEV	1 req	Avail to order Our Price: $34.79
56	004621316	DIVERTER UNION METALPIPE	1 req	Avail to order Our Price: $104.30
57	004621315	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
