1981-1988 Jalpa 3.5 - USA

Group :

Tav :

Maintenance Parts:

Belts

PN	Item	Diagram
004613685	AIR PUMP BELT AIR PUMP BELT		Avail to order Our Price: $79.07
001219534	AUXILIARY UNIT BELT AUXILIARY UNIT BELT		Avail to order Our Price: $346.32

Brakes

PN	Item	Diagram
003135292	BRAKE PADS FRONT - JALPA - EARLY DIABLO - PER ROTOR FRONT BRAKE PADS		Avail to order Our Price: $524.67
003220800	BRAKE PAD REAR - URRACO - JALPA - SOLD EACH REAR BRAKE PAD KITS		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.44
007029005	BONNET LIFTER BONNET LIFTER		Current Stock: 4 Our Price: $114.79

Drivetrain

PN	Item
001505914	OIL FILTER - DIABLO - LM002 - COUNTACH - URRACO - JALPA OIL CARTRIDGE. NOTE: THESE ARE ORDERED DIRECTLY FROM THE FACTORY. BRAND/MODEL/COLOR MAY DIFFER FROM THE PICTURE. WE HAVE NO CONTROL AS TO WHAT IS SENT WHEN THEY ARE ORDERED.	Current Stock: 20 Our Price: $86.51
004219984	MASTER CLUTCH CYLINDER CLUTCH CYLINDER CONTROL ASSEMBLY	Avail to order Our Price: $350.78
002111112	FLYWHEEL FLYWHEEL	Avail to order Our Price: $1,270.26
002111111	CLUTCH PRESSURE PLATE CLUTCH PRESSURE PLATE	Current Stock: 1 Our Price: $2,742.24
002108644	THRUST BEARING THRUST BEARING	Current Stock: 1 Our Price: $1,856.19
002106838	CLUTCH CYLINDER ROD CLUTCH CYLINDER ROD	Avail to order Our Price: $68.44
002109862	CLUTCH PLATE CLUTCH PLATE	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item
001320172KN	PERFORMANCE FILTER FOR COUNTACH/ESPADA/JARAMA/MIURA HIGH FLOW PERFORMANCE FILTER.	Current Stock: 1 Our Price: $130.02
001501128	OIL FILTER SEAL OIL FILTER SEAL	Current Stock: 3 Our Price: $22.01
006220011	FUEL FILTER FUEL FILTER	Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W BULB LAMP BA 15S 21W USED IN VARIOUS LAMPS (DEPENDING ON YOUR YEAR AND MODEL)	Current Stock: 76 Our Price: $9.90
N0177522	BULB HEADLIGHT LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006617093	12V 5W BULB 12V 5W BULB	Avail to order Our Price: $20.24
006309758	CYLINDER BULB 6411/12V 10W CYLINDER BULB 6411/12V 10W	Avail to order Our Price: $11.85
006617106	12V 60/55W BULB 12V 60/55W BULB	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	ENGINE GASKET SET - JALPA - MIURA ENGINE GASKET KIT JALPA AND MIURA SEE ALSO 001526473 GROMMET & OIL SEALS SET	Avail to order Our Price: $1,098.80
001526473	GROMMET AND OIL SEALS SET - JALPA - MIURA GROMMET AND OIL SEALS SET JALPA - MIURA	Avail to order Our Price: $348.55
001526492	ENGINE GASKET KIT JALPA ENGINE GASKET KIT	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $667.35
008811403	SPARK PLUG - COUNTACH-JALPA SPARK PLUG		Current Stock: 16 Our Price: $39.99

Misc

PN	Item
006121168	NLA (NO LONGER AVAILABLE) WIPER BLADE TYPE B	Avail to order Our Price: $40.41
008200605R	OE SPEC ALTERNATIVE FOR 008200605 M6 NCM 70 URAMA SIMMON NUT	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ML CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.72
001801333	OIL & COOLANT TEMPERATURE THERMOMETER OIL & COOLANT TEMPERATURE THERMOMETER NLA FROM FACTORY. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.12
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $647.05
001719309	URRACO THERMOSTAT COOLANT THERMOSTAT	Current Stock: 2 Our Price: $195.00

Tools and Tookits

PN	Item	Diagram
wheeltool	WHEEL INSTALL TOOL SCREWS INTO HUB FOR EASY INSTALLATION.		Current Stock: 94 Our Price: $19.42

Open All

Select Group and TAV

< Previous Next >

TAV: 1.13 - Fuel System

1981-1988 Lamborghini Jalpa 3.5 USA Fuel System (1.13)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008932003	PLUG 20X1.5M 5S	1 req	Avail to order Our Price: $21.69
2	008402007	ANNEALED COPPER WASHER D.21X27	1 req	Current Stock: 8 Our Price: $0.68
3	001122055	LH HEAD REAR CONNECTION	1 req	Avail to order Our Price: $31.69
4	008700617	SCREW M6X18 UNI 5931/8G/Z	8 req	Current Stock: 1 Our Price: $0.28
5	WHT001197A	WASHER	8 req	Current Stock: 2 Our Price: $0.31
6	001322187	COVER ASSEMBLY	2 req	Avail to order Our Price: $195.32
7	001321907	CARBURETTOR HOUSINGSCOVER GASK	4 req	Current Stock: 1 Our Price: $3.96
8	001322785	This item is no longer available	1 req
9	001321685	RH AND LH CARBURETTOR HOUSING	2 req	Avail to order Our Price: $91.25
10	001321998	PIPE FROM UNION	2 req	Avail to order Our Price: $8.21
11	001321904	LH CARBURETTOR HOUSING COVER S	1 req	Avail to order Our Price: $22.14
12	001310930	UNION FOR FUEL INLETINTO REAR	2 req	Avail to order Our Price: $80.07
13	001321999	PIPE FROM UNION ON REAR RH CAR	2 req	Avail to order Our Price: $15.88
14	001321986	FUEL INLET UNION INTO FRONT CA	2 req	Avail to order Our Price: $83.79
15	008830901	NLA (NO LONGER AVAILABLE)	18 req	*See Description
16	001322000	PIPE FROM UNION ON FRONT RH CA	2 req	Avail to order Our Price: $13.50
17	001321987	UNION	1 req	Avail to order Our Price: $80.37
18	008700617	SCREW M6X18 UNI 5931/8G/Z	13 req	Current Stock: 1 Our Price: $0.28
19	001321683	COVER ON CARBURETTORHOUSING ON	1 req	Avail to order Our Price: $149.84
20	WHT001197A	WASHER	13 req	Current Stock: 2 Our Price: $0.31
21	001321682	COVER ON CARBURETTORHOUSING ON	1 req	Avail to order Our Price: $151.33
22	001321905	RH CARBURETTOR HOUSING COVER S	1 req	Avail to order Our Price: $7.91
23	001322352	This item is no longer available	1 req
24	001322353	This item is no longer available	1 req
25	001322352	This item is no longer available	3 req
26	001612048	LH HEAD/SOLENOID VALVE BAR PIP	1 req	Avail to order Our Price: $36.23
27	004622354	This item is no longer available	1 req
28	001322351	This item is no longer available	2 req
29	001322003	PIPE FROM FUEL RECIRCULATION U	1 req	Avail to order Our Price: $10.51
30	001322056	UNION ON INTAKE MANIFOLD	1 req	Avail to order Our Price: $25.57
31	001311607	FUEL TANK RECIRCULATION UNION	1 req	Avail to order Our Price: $125.69
32	001322002	PIPE FROM FUEL RECIRCULATION U	1 req	Avail to order Our Price: $15.88
33	001321988	UNION	1 req	Avail to order Our Price: $33.63
34	001321912	FAIRLEADS	2 req	Current Stock: 2 Our Price: $77.24
35	008300818	STUD M8X30 UNI 5911 8G ZD	16 req	Avail to order Our Price: $5.06
36	008800803	BUSHING 8X12X8 MM	4 req	Avail to order Our Price: $7.08
37	001321993	UNION ON CARBURETTOR	1 req	Avail to order Our Price: $146.56
38	008401424	WASHER 14.5X21X2	4 req	Avail to order Our Price: $11.93
39	008201415	M14X1.5 H.5 SPECIAL NUT	4 req	Avail to order Our Price: $11.93
40	001322001	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
41	001321629	LH HEAD CARBURETTOR HOUSING	1 req	Avail to order Our Price: $581.46
42	001322200	VALVE	2 req	Avail to order Our Price: $33.93
43	001321913	RUBBER PLUGS	14 req	Current Stock: 2 Our Price: $39.97
44	001111782	SENSOR FITTING CONNECTION	14 req	Avail to order Our Price: $75.74
45	001322045	HOSE RUBBER CAPS	8 req	Avail to order Our Price: $6.49
46	004621565	6-WAY VACUUM MANIFOLD	1 req	Avail to order Our Price: $93.63
47	001311580	CARBURETTOR DRIVE SHAFT LEVER	2 req	Current Stock: 1 Our Price: $386.15
48	001321911	SHAFT CONTROL LEVER SHIM	1 req	Avail to order Our Price: $7.46
49	001321909	LH HEAD CARBURETTOR SHAFT	1 req	Avail to order Our Price: $29.90
50	001321982	THROTTLE VALVE	2 req	Avail to order Our Price: $27.73
51	008830205	CLAMP	20 req	Avail to order Our Price: $7.91
52	008100701	SCREW 7X1X10 UNI 5739 8G/Z	1 req	Avail to order Our Price: $2.91
53	008400704	COPPER WASHER 7.4X10X1	1 req	Avail to order Our Price: $2.91
54	001321994	UNION	1 req	Avail to order Our Price: $80.37
55	001321659	RH HEAD CARBURETTOR HOUSING	1 req	Avail to order Our Price: $581.46
56	008700506	SCREW KNIP 4.8X16DIN7971 BLACK	2 req	Current Stock: 4 Our Price: $0.14
57	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	2 req	Current Stock: 8 Our Price: $0.89
58	001322785	This item is no longer available	1 req
59	004621570	MANIFOLD RETAINER PLATE	1 req	Avail to order Our Price: $142.23
60	001321910	SHAFT CONTROL LEVER SHIM	2 req	Avail to order Our Price: $7.09
61	001321270	THROTTLE LEVER RETURN SPRING	1 req	Current Stock: 3 Our Price: $9.77
62	001321268	PLATE ON AIR DELIVERY CASING	1 req	Avail to order Our Price: $9.17
63	008100631	SCREW M6X8 UNI 5739 8G	1 req	Avail to order Our Price: $0.14
64	001322053	This item is no longer available	1 req
65	WHT003068	SCREW	4 req	Current Stock: 8 Our Price: $1.52
66	001322054	REAR COVER SEAL	2 req	Current Stock: 17 Our Price: $0.62
67	008830205	CLAMP	4 req	Avail to order Our Price: $7.91
68	001322328	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	2 req	*See Description
69	001322005	NLA	2 req	*See Description
70	001321985	VACUUM CHAMBER BRACKET	1 req	Avail to order Our Price: $57.70
71	001122107	LH CYLINDER HEAD COVER	1 req	Avail to order Our Price: $312.35
72	001320436	This item is no longer available	1 req
73	001322710	AIR MANIFOLD	1 req	Avail to order Our Price: $80.07
74	001322207	This item is no longer available	1 req
75	001321981	THROTTLE VALVE BRACKET SHAFT	2 req	Avail to order Our Price: $77.24
76	008700435	SCREW M4X.07X7.5 UNI6107 Z	4 req	Avail to order Our Price: $0.34
77	001321983	LEVER	2 req	Avail to order Our Price: $83.79
78	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	2 req	Current Stock: 8 Our Price: $0.89
79	N0211963	HEX.HEAD CLAMPING	2 req	Avail to order Our Price: $0.83
80	WHT001187	WASHER 10X5.3X1 UNI 6952 CAT-A	2 req	Current Stock: 8 Our Price: $0.89
81	008820201	SPLIT PIN	2 req	Current Stock: 19 Our Price: $7.60
82	008300624	STUD M6X12 UNI 5914 8G ZD	4 req	Avail to order Our Price: $17.25
83	N01152427	WASHER	4 req	Current Stock: 16 Our Price: $0.31
84	008200605	SIMMON NUT FOR URAMA	4 req	Current Stock: 50 Our Price: $3.05
85	001322351	This item is no longer available	2 req
86	001321984	VACUUM CHAMBER BRACKET	1 req	Avail to order Our Price: $57.70
87	001122106	RH CYLINDER HEAD COVER	1 req	Avail to order Our Price: $426.41
88	008700603	SCREW M6X20 UNI 593312K/Z	12 req	Avail to order Our Price: $2.91
89	008501201	BEARING	6 req	Avail to order Our Price: $31.39
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
