TAV: 22.33 - Handbrake

1981-1988 Lamborghini Jalpa 3.5 USA Handbrake (22.33)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	003319349	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
2	N90179103	WASHER	4 req	Current Stock: 5 Our Price: $2.00
3	008100830	Screw M8x20 Uni 5739/8g/Z	4 req	Current Stock: 19 Our Price: $2.00
4	003319720	Lever Rod Fixing Pin	2 req	Avail to order Our Price: $22.44
5	003320148	Handbrake Sheath Wire From Sho	1 req	Avail to order Our Price: $419.14
6	008101246	Bolt D.M12x1.5x30 10k Bon	4 req	Avail to order Our Price: $71.35
7	WHT003055	Washer 13x24x1.2 Din137/B C72	4 req	Current Stock: 10 Our Price: $2.00
8	008401305	Washer 13x22x* C 72	1 req	Avail to order Our Price: $2.00
9	003318969	NLA	4 req	*See Description
10	003313950	Rh Brake Shoe	1 req	Avail to order Our Price: $339.18
11	003319356	Lever Button	1 req	Avail to order Our Price: $41.23
12	008820201	Split Pin 1.8x15 Uni 1336a	1 req	Current Stock: 19 Our Price: $7.60
13	WHT002962	WASHER	1 req	Current Stock: 11 Our Price: $2.00
14	003320156	Shim	1 req	Avail to order Our Price: $48.98
15	N01100637	HEX.NUT	1 req	Current Stock: 18 Our Price: $2.00
16	003320619	Front & Rear Tierod Adjustment	1 req	Avail to order Our Price: $12.23
17	008200607	D 6x1 Sin. 8g Nut	1 req	Avail to order Our Price: $14.92
18	003319198	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
19	003313951	LH BRAKE SHOE	1 req	Avail to order Our Price: $391.55
20	004207085	Brake Cylinder Pin Stopper	1 req	Avail to order Our Price: $85.47
21	003313888	Handbrake Equaliser Pulley	1 req	Avail to order Our Price: $164.75
22	003320310	Handbrake InspectionFlap	1 req	Avail to order Our Price: $22.22
23	008410603	Washer D.6.4 Uni 1751/Zd	6 req	Avail to order Our Price: $2.00
24	008100621	Screw M6x20 Uni 5739/5s/Z	6 req	Avail to order Our Price: $2.00
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
