1981-1988 Lamborghini Jalpa 3.5 USA Crankcase (11.18)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $346.32
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $79.07

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $524.67
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $99.00

Common repairs and upgrades

PN	Item	Diagram
007029005	Bonnet Lifter Bonnet Lifter		Current Stock: 4 Our Price: $114.79
410860382	STEERING WHEEL COVER STEERING WHEEL COVER WITH CREST LOGO		Current Stock: 2 Our Price: $22.58

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Current Stock: 21 Our Price: $86.65
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $350.78
002111112	Flywheel Flywheel	Avail to order Our Price: $1,270.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,742.24
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,856.19
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $68.44
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,431.28

Fuel-Air

PN	Item	Diagram
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $130.02
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $314.68

Fuses-Bulbs-Relays

PN	Item
006617094	LAMP BA 15S 21W Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 76 Our Price: $9.90
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.17
006311154	RELAY RELAY	Avail to order Our Price: $56.14
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.85
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $20.24
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $85.26

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,098.80
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $348.55
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,403.08

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Current Stock: 16 Our Price: $39.99
001622092	DISTRIBUTOR PLUG WIRES - JALPA DISTRIBUTOR PLUG WIRES - JALPA		Avail to order Our Price: $668.46

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $40.35
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.94
0R0000149	CLEANER FLUID 250ml CLEANER FLUID	Current Stock: 1 Our Price: $70.78

Sensors

PN	Item
002408637	REVERSE SWITCH REVERSE SWITCH	Avail to order Our Price: $136.52
001719309	URRACO THERMOSTAT Coolant Thermostat	Current Stock: 2 Our Price: $195.00
001801333	OIL & COOLANT TEMPERATURE THERMOMETER Oil & Coolant Temperature Thermometer NLA from factory. CONTACT US FOR CURRENT AVAILABILITY	Avail to order Our Price: $150.37
006019052	OIL TEMPERATURE GAUGE OIL TEMPERATURE GAUGE	Avail to order Our Price: $646.12

Open All

Select Group and TAV

< Previous Next >

TAV: 11.18 - Crankcase

1981-1988 Lamborghini Jalpa 3.5 USA Crankcase (11.18)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008300822	Stud M8x18 Uni 5911 8g Z	3 req	Avail to order Our Price: $26.35
2	001807864	Oil Flow Limiter Ring	1 req	Avail to order Our Price: $7.83
3	001810798	Central Crankcase Cover	1 req	Avail to order Our Price: $23,034.51
4	008100849	Screw M8x18 8g	1 req	Avail to order Our Price: $8.80
5	008300839	Stud M8x28 Uni 5911 8g Z	2 req	Avail to order Our Price: $8.18
6	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
7	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
8	008606205	NLA (No Longer Avialable)	2 req	*See Description
9	001806762	Coolant Pump Shaft Journal	1 req	Avail to order Our Price: $364.53
10	001111782	Sensor Fitting Connection	1 req	Avail to order Our Price: $75.74
11	008411005	Washer D.10.5 Uni 1751/F	2 req	Avail to order Our Price: $2.00
12	N10155210	HEX.NUT	2 req	Current Stock: 38 Our Price: $2.17
13	008301027	Stud M10x30 Uni 59118g Z D	2 req	Avail to order Our Price: $8.80
14	008200805	M8x1x8 8g/B Nut	10 req	Avail to order Our Price: $2.00
15	WHT001514	SPRING WASHER	10 req	Current Stock: 9 Our Price: $26.80
16	008300810	Stud M8x1x80 Uni 5916 10k	10 req	Avail to order Our Price: $15.14
17	008201201	M12x1.25 Uni 5587 8g Nut	8 req	Avail to order Our Price: $6.87
18	WHT003055	Washer 13x24x1.2 Din137/B C72	10 req	Current Stock: 10 Our Price: $2.00
19	008301208	Special Stud E M12x18	10 req	Avail to order Our Price: $17.89
20	008851101	Bushing 8.5x11x14 Mm	2 req	Avail to order Our Price: $41.40
21	008602002	Ring 21 mm Or	1 req	Current Stock: 8 Our Price: $25.35
22	008932202	Plug 22mb	1 req	Avail to order Our Price: $92.29
23	008300615	Stud 6x22 Uni 5911/8g/Z	6 req	Avail to order Our Price: $23.56
24	WHT001197A	WASHER	6 req	Current Stock: 2 Our Price: $2.00
25	N01100637	HEX.NUT	6 req	Current Stock: 18 Our Price: $2.00
26	008600901	POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT	1 req	*See Description
27	001820913	Oil Dipstick	1 req	Avail to order Our Price: $180.41
28	001810803	Oil Dipstick Pipe	1 req	Avail to order Our Price: $58.37
29	001812090	CRANKCASE CENTRAL COVER GASKET	1 req	Avail to order Our Price: $53.51
30	WHT003078	Reference Pin 8h7x16C40	4 req	Avail to order Our Price: $46.98
31	008300831	Stud M8x20 Uni 5911 8g Zd	6 req	Avail to order Our Price: $16.40
32	WHT001514	SPRING WASHER	6 req	Current Stock: 9 Our Price: $26.80
33	008200806	M8 Uni 5588/8g/Z Nut	6 req	Current Stock: 25 Our Price: $2.00
34	001819529	NLA (No Longer Available)	1 req	*See Description
34	001819536	This item is no longer available	1 req
35	001701906	Tap Washer	2 req	Avail to order Our Price: $2.00
36	001701905	Radiator Tap	2 req	Avail to order Our Price: $115.94
37	001819464	Cylinder Liner	8 req	Avail to order Our Price: $353.35
38	001819537	Crankcase Lower Journal	1 req	Avail to order Our Price: $6,239.45
38	001819520	This item is no longer available	1 req
39	001805998	Oil Sump Seal	1 req	Avail to order Our Price: $164.25
40	001807429	Oil Breather Pipe Seal	1 req	Current Stock: 1 Our Price: $5.97
41	001819555	This item is no longer available	2 req
42	N10155210	HEX.NUT	2 req	Current Stock: 38 Our Price: $2.17
43	008411005	Washer D.10.5 Uni 1751/F	2 req	Avail to order Our Price: $2.00
44	008301014	Stud M10x105 Uni 5911 8gz	2 req	Avail to order Our Price: $15.14
45	N10155210	HEX.NUT	1 req	Current Stock: 38 Our Price: $2.17
46	008411005	Washer D.10.5 Uni 1751/F	2 req	Avail to order Our Price: $2.00
47	008301002	Stud M10x75 Uni 59118gz	2 req	Avail to order Our Price: $38.55
48	008301229	Special Stud M11x135	20 req	Avail to order Our Price: $27.73
49	008200805	M8x1x8 8g/B Nut	4 req	Avail to order Our Price: $2.00
50	WHT001514	SPRING WASHER	4 req	Current Stock: 9 Our Price: $26.80
51	008300806	Stud M8x70 Uni 5911 9g Z	2 req	Avail to order Our Price: $6.49
52	008932202	Plug 22mb	2 req	Avail to order Our Price: $92.29
53	008602002	Ring 21 mm Or	1 req	Current Stock: 8 Our Price: $25.35
54	001108163	Oil Dipstick Pipe Seal	1 req	Current Stock: 5 Our Price: $7.58
55	008410603	Washer D.6.4 Uni 1751/Zd	2 req	Avail to order Our Price: $2.00
56	008100617	Screw M6x18 Uni 57395s	2 req	Avail to order Our Price: $6.79
57	WHT003057	O-RING	4 req	Current Stock: 11 Our Price: $2.00
58	008300836	Stud 8x1.25x30 8g	2 req	Avail to order Our Price: $4.18
59	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
60	N01100845	HEX.NUT	2 req	Current Stock: 17 Our Price: $2.09
61	001819557	Head Centring Dowel	2 req	Avail to order Our Price: $66.73
62	001112287	Head Fixing Washer	20 req	Avail to order Our Price: $21.55
63	008201101	NLA (No Longer Available)	20 req	*See Description
64	008300628	Stud M6x90 Uni 5914 8g Zd	4 req	Avail to order Our Price: $4.41
65	N01100637	HEX.NUT	4 req	Current Stock: 18 Our Price: $2.00
66	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
67	N01020717	HEXAGON HEAD BOLT	8 req	Current Stock: 4 Our Price: $2.00
68	008410502	Washer D.5.3 Uni 1751/Zd	8 req	Current Stock: 33 Our Price: $2.00
69	001819957	Oil Turbulence Bulkhead	1 req	Avail to order Our Price: $375.72
70	001810980	Urraco Oil Sump	1 req	Avail to order Our Price: $614.26
71	086301141A	Magnetic Plug 22x1.5	2 req	Avail to order Our Price: $39.91
72	001801333	OIL & COOLANT TEMPERATURE THERMOMETER	1 req	Avail to order Our Price: $150.37
73	008401610	Annealed Copper Washer 16x22x0	1 req	Current Stock: 25 Our Price: $11.23
74	WHT002944	TAP END STUD	2 req	Avail to order Our Price: $17.87
75	008100603	Screw M6x25 Uni 5739-8g Zg	13 req	Avail to order Our Price: $2.00
76	WHT001197A	WASHER	17 req	Current Stock: 2 Our Price: $2.00
77	001819743	Lh Hole Cover	1 req	Avail to order Our Price: $37.13
78	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
79	008100617	Screw M6x18 Uni 57395s	4 req	Avail to order Our Price: $6.79
80	008101226	Screw M12x1.5x30 Ch19 10k	2 req	Avail to order Our Price: $26.61
81	008411303	Snap Ring 21x13x2.5 Uni 175 1	2 req	Current Stock: 6 Our Price: $3.29
82	004108896	Engine-Gearbox MountAdapter	2 req	Avail to order Our Price: $69.93
83	WHT003041	Soft Copper Washer 6.4x12x1.5	1 req	Current Stock: 14 Our Price: $2.00
84	008100650	This item is no longer available	1 req
85	WHT003078	Reference Pin 8h7x16C40	1 req	Avail to order Our Price: $46.98
86	WHT003085	Cylinder Liner Rubber Washer m	8 req	Avail to order Our Price: $4.69
87	008100816	Screw M8x110 Uni 5737 8g	1 req	Avail to order Our Price: $6.87
88	001820183	Crankcase Coolant Seal Cord	2 req	Avail to order Our Price: $12.38
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
