TAV: 17.24 - Gearbox (Castings)

1981-1988 Lamborghini Jalpa 3.5 USA Gearbox (Castings) (17.24)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	002305118	Differential Breather Pipe	1 req	Avail to order Our Price: $15.09
2	001108412	Oil Breather Flame Trap	1 req	Avail to order Our Price: $15.09
3	004108896	Engine-Gearbox MountAdapter	3 req	Avail to order Our Price: $65.12
4	002420960	Gearbox & Differential	1 req	Avail to order Our Price: $1,479.62
4	002411167	This item is no longer available	1 req
5	002302182	Differential Oil Breather Pipe	1 req	Avail to order Our Price: $240.37
6	008575001	O-Ring I 47 Uni 3654	1 req	Current Stock: 11 Our Price: $2.00
7	008613004	Oil Seal 30x42x7 mm	1 req	Current Stock: 2 Our Price: $16.66
7	008613001	Oil Seal 30x47x6 mm	1 req	Avail to order Our Price: $16.66
8	008523511	Bearing	1 req	Avail to order Our Price: $78.20
9	008300604	Stud M6x13 Uni 5914/8g/Zd	3 req	Avail to order Our Price: $20.95
10	008410603	Washer D.6.4 Uni 1751/Zd	3 req	Avail to order Our Price: $2.00
11	N01100637	HEX.NUT	3 req	Current Stock: 18 Our Price: $2.00
12	002420112	Bracket	1 req	Avail to order Our Price: $353.11
12	002406364	Thrust Sleeve Bracket	1 req	Avail to order Our Price: $333.10
13	002407496	Gasket	1 req	Current Stock: 4 Our Price: $22.88
14	002407495	Gearbox Front Cover	1 req	Avail to order Our Price: $24.02
15	008410605	Corrugated Washer D 6	4 req	Avail to order Our Price: $2.65
16	008700603	Screw M6x20 Uni 593312k/Z	4 req	Avail to order Our Price: $2.65
17	002406672	Gear Selector Lever Bracket	1 req	Avail to order Our Price: $38.97
18	WHT001197A	WASHER	11 req	Current Stock: 2 Our Price: $2.00
19	008100603	Screw M6x25 Uni 5739-8g Zg	11 req	Avail to order Our Price: $2.00
20	008604202	Ring 43 mm Or	1 req	Current Stock: 3 Our Price: $2.00
21	01S409965	PLUG	1 req	Current Stock: 5 Our Price: $175.80
22	008611706	Lip Seal	1 req	Avail to order Our Price: $9.34
23	002406854	This item is no longer available	1 req
24	008605001	Or Ring	1 req	Current Stock: 106 Our Price: $2.00
25	008100822	Screw M8x60 Uni 57378g/Zd	10 req	Avail to order Our Price: $6.37
26	008401414	Copper Washer 14x24x0,04513888	1 req	Current Stock: 27 Our Price: $2.46
27	008931201	Plug D.12x1.25x9 Oil5s	1 req	Avail to order Our Price: $39.10
28	WHT003362	Copper Washer D.12x22x1.5	1 req	Avail to order Our Price: $2.00
29	002408619	Differential Cover Seal	1 req	Avail to order Our Price: $37.44
30	002408620	Differential Cover	1 req	Avail to order Our Price: $159.40
31	002406535	Rear Gearbox	1 req	Avail to order Our Price: $345.25
32	008200806	M8 Uni 5588/8g/Z Nut	12 req	Current Stock: 25 Our Price: $2.00
33	008410605	Corrugated Washer D 6	12 req	Avail to order Our Price: $2.65
34	008851101	Bushing 8.5x11x14 Mm	2 req	Avail to order Our Price: $39.10
35	008200605	NLA (No Longer Available)	9 req	*See Description
36	WHT003041	Soft Copper Washer 6.4x12x1.5	9 req	Current Stock: 14 Our Price: $2.00
37	N01100637	HEX.NUT	9 req	Current Stock: 18 Our Price: $2.00
38	WHT001197A	WASHER	12 req	Current Stock: 2 Our Price: $2.00
39	008300620	Special Stud M6x46	9 req	Avail to order Our Price: $2.00
40	002407515	Gearbox Rear Cover Seal	1 req	Avail to order Our Price: $22.09
41	002406502	Flange	1 req	Avail to order Our Price: $92.64
42	008850610	Reference Pin 6h6x19.5 C40	1 req	Avail to order Our Price: $8.15
43	008850502	Dowel 5x11 mm	2 req	Avail to order Our Price: $6.37
44	008300610	SEE PN WHT003165	5 req	Avail to order Our Price: $26.67
45	086301141A	Magnetic Plug 22x1.5	2 req	Avail to order Our Price: $37.39
46	002408636	Gearbox Oil Filter Union	1 req	Avail to order Our Price: $28.31
47	008401408	Annealed Copper Washer 21x14x1	2 req	Current Stock: 41 Our Price: $2.00
48	WHT001197A	WASHER	11 req	Current Stock: 2 Our Price: $2.00
49	008100603	Screw M6x25 Uni 5739-8g Zg	11 req	Avail to order Our Price: $2.00
50	008930901	Taper Gas Plug 1/8	1 req	Avail to order Our Price: $11.09
51	008100603	Screw M6x25 Uni 5739-8g Zg	3 req	Avail to order Our Price: $2.00
52	002408621	Cover & Oil Pump	1 req	Avail to order Our Price: $273.77
53	008700606	Screw Ei M6x1x10 12kd	1 req	Current Stock: 37 Our Price: $2.00
54	008100839	Screw M8x10 Uni 5739/8g Z	1 req	Current Stock: 17 Our Price: $2.00
55	008400802	Copper Washer 8.4x16x1.5	1 req	Avail to order Our Price: $2.00
56	002407480	Gearbox Lower Cover Seal	1 req	Current Stock: 7 Our Price: $3.58
57	002407479	Gearbox Lower Cover	1 req	Avail to order Our Price: $39.96
58	WHT001197A	WASHER	5 req	Current Stock: 2 Our Price: $2.00
59	N01100637	HEX.NUT	5 req	Current Stock: 18 Our Price: $2.00
60	002408627	Gearbox Oil Inlet Union Pipe	2 req	Avail to order Our Price: $16.59
61	002408634	NLA (No Longer Available)	1 req	*See Description
62	008300808	Stud M8x35 Uni 5911 8g Z	2 req	Avail to order Our Price: $5.86
63	002407502	Clutch Hole Guard Cover	1 req	Avail to order Our Price: $13.02
64	N0111849	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 5 Our Price: $2.23
65	008300822	Stud M8x18 Uni 5911 8g Z	4 req	Avail to order Our Price: $24.62
66	008605601	Or Ring	1 req	Avail to order Our Price: $51.96
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
