1981-1988 Lamborghini Jalpa 3.5 USA Distribution (3.12)

Maintenance Parts:

Belts

PN	Item	Diagram
001219534	Auxiliary Unit Belt Auxiliary Unit Belt		Avail to order Our Price: $327.24
004613685	Air Pump Belt Air Pump Belt		Avail to order Our Price: $74.72

Brakes

PN	Item	Diagram
003135292	Brake Pads Front - Jalpa - Early Diablo - Per Rotor Front Brake Pads		Avail to order Our Price: $496.66
003220800	Brake Pad Rear - Urraco - Jalpa - Sold Each Rear Brake Pad Kits		Avail to order Our Price: $92.07

Drivetrain

PN	Item
001505914	Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.	Avail to order Our Price: $81.81
004219984	Master Clutch Cylinder Clutch Cylinder Control Assembly	Avail to order Our Price: $332.32
002111112	Flywheel Flywheel	Avail to order Our Price: $1,182.26
002111111	Clutch Pressure Plate Clutch Pressure Plate	Current Stock: 1 Our Price: $2,671.52
002108644	Thrust Bearing Thrust Bearing	Current Stock: 1 Our Price: $1,729.80
002106838	Clutch Cylinder Rod Clutch Cylinder Rod	Avail to order Our Price: $63.77
002109862	Clutch Plate Clutch Plate	Current Stock: 2 Our Price: $1,332.37

Fuel-Air

PN	Item	Diagram
006220011	Fuel Filter Fuel Filter		Avail to order Our Price: $294.96
001320172KN	Performance filter for Countach/Espada/Jarama/Miura High Flow performance filter.		Current Stock: 1 Our Price: $125.33

Fuses-Bulbs-Relays

PN	Item
006617094	Check Parts Manual for location Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)	Current Stock: 77 Our Price: $9.28
N0177522	bulb Headlight LAMP 12V/3W	Current Stock: 10 Our Price: $2.01
006311154	Relay Relay	Avail to order Our Price: $52.25
006617093	12v 5w Bulb 12v 5w Bulb	Avail to order Our Price: $18.99
006309758	Cylinder Bulb 6411/12v 10w Cylinder Bulb 6411/12v 10w	Avail to order Our Price: $11.01
006617106	12v 60/55w Bulb 12v 60/55w Bulb	Avail to order Our Price: $80.00

Gaskets

PN	Item
001526493	Engine Gasket Set - Jalpa - Miura Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set	Avail to order Our Price: $1,022.15
001526473	Grommet and Oil Seals Set - Jalpa - Miura Grommet and Oil Seals Set Jalpa - Miura	Avail to order Our Price: $329.42
001526492	Engine Gasket Kit Jalpa Engine Gasket Kit	Avail to order Our Price: $1,326.35

Ignition

PN	Item	Diagram
008811403	Spark Plug - Countach-Jalpa Spark Plug		Avail to order Our Price: $61.84
001622092	Spark Plug Wires - Jalpa Wires From Distributor To Spar		Avail to order Our Price: $629.88

Misc

PN	Item
006121168	NLA (No Longer Available) Wiper Blade Type B	Avail to order Our Price: $37.60
008200605R	OE spec alternative for 008200605 M6 Ncm 70 Urama Simmon Nut	Avail to order Our Price: $1.87
900000382	NLA use PN 400093050D for USA replacement	Avail to order Our Price: $190.57
900000381	NLA (No Longer Available) Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.	Avail to order Our Price: $190.57

Sensors

PN	Item	Diagram
002408637	Reverse Switch Switch		Avail to order Our Price: $127.24
001801333	NLA (No longer Available to order) Oil & Coolant Temperature Thermometer		Avail to order Our Price: $141.76

Open All

Select Group and TAV

< Previous Next >

TAV: 3.12 - Distribution

1981-1988 Lamborghini Jalpa 3.5 USA Distribution (3.12)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008101201	Screw M12x1.25 Uni 5740 10	1 req	Avail to order Our Price: $25.81
2	008411201	Retaining Shim Washer	1 req	Avail to order Our Price: $6.37
3	001219533	Pump Belt Guard	1 req	Avail to order Our Price: $306.98
4	001613440	Alternator Drive Pulley	1 req	Avail to order Our Price: $54.26
5	001219534	Auxiliary Unit Belt	1 req	Avail to order Our Price: $327.24
6	001219200	NLA (No Longer Available)	2 req	*See Description
7	WHT001197A	WASHER	4 req	Current Stock: 2 Our Price: $2.00
8	008700601	Screw M6x30 Uni 59318g/Z	4 req	Avail to order Our Price: $6.29
9	008932002	Taper Plug 1/2 Gas 5s	4 req	Avail to order Our Price: $28.95
10	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $25.05
11	008700804	Screw 8x1.5x25 5931 8g Zg	2 req	Avail to order Our Price: $2.00
12	001219516	Timing Guard	1 req	Avail to order Our Price: $10,285.82
13	008700613	Screw M6x14 Uni 5933/8g/Zb	10 req	Avail to order Our Price: $2.00
14	008700627	Screw M6x22 Uni 59315s/Z	3 req	Current Stock: 2 Our Price: $2.00
15	WHT002961	WASHER	3 req	Current Stock: 39 Our Price: $2.00
16	008610902	Grommet 14x20x1.5 mm	3 req	Avail to order Our Price: $8.58
17	008850611	Dowel D.6x11 mm	1 req	Avail to order Our Price: $24.74
18	001213439	Pulley	1 req	Avail to order Our Price: $150.83
19	008251701	M17x1x28 Ring Nut - NLA CHECK STOCK	1 req	*See Description
20	001213441	Coolant Pump Pulley	1 req	Avail to order Our Price: $316.65
21	001210889	Auxiliary Unit GuidePin	1 req	Avail to order Our Price: $74.77
22	001213438	Auxiliary Unit Guide	1 req	Avail to order Our Price: $308.79
23	008502501	Bearing D.25x52x20.6	1 req	Avail to order Our Price: $59.26
24	008575201	O-Ring I 52 Uni 3654	1 req	Current Stock: 22 Our Price: $2.00
25	008202501	25x1.5 Sin Special Nut	1 req	Avail to order Our Price: $16.66
26	008300609	Stud M6x25 Uni 5911 8g/Zd	13 req	Avail to order Our Price: $15.23
27	001210852	Chain Gear Pin	2 req	Avail to order Our Price: $35.03
28	008502507	Bearing	4 req	Avail to order Our Price: $31.10
29	001210847	Timing Chain Pinion	2 req	Avail to order Our Price: $364.55
30	001210851	Gear	1 req	Avail to order Our Price: $817.72
31	001210850	Gear	1 req	Avail to order Our Price: $1,090.77
32	WHT001197A	WASHER	12 req	Current Stock: 2 Our Price: $2.00
33	008100622	Screw M6x12 Uni 5739/8g	10 req	Avail to order Our Price: $6.29
34	WHT003078	Reference Pin 8h7x16C40	2 req	Avail to order Our Price: $17.16
35	001210839	Timing System Cover Seal	1 req	Avail to order Our Price: $33.96
36	WHT001197A	WASHER	13 req	Current Stock: 2 Our Price: $2.00
37	N01100637	HEX.NUT	13 req	Current Stock: 18 Our Price: $2.00
38	001219518	Upper Cover Seal	2 req	Avail to order Our Price: $22.81
39	001219949	Timing Case Cover	1 req	Avail to order Our Price: $116.94
40	001210887	Chain Tightener Pin	2 req	Avail to order Our Price: $85.92
41	001210876	Chain Tightener Gear	2 req	Avail to order Our Price: $196.57
42	008522007	Bearing	4 req	Avail to order Our Price: $11.09
43	008581801	O-Ring E 20 Uni 7435-75	2 req	Current Stock: 18 Our Price: $2.00
44	001219508	Timing Chain Tightener	2 req	Avail to order Our Price: $720.51
45	001210886	Tightener Lock Plate	2 req	Avail to order Our Price: $27.74
46	008600902	Ring 9 mm Or	2 req	Avail to order Our Price: $2.00
47	008602301	Ring 24 mm Or	1 req	Current Stock: 2 Our Price: $1.86
48	008601802	Ring 19 mm Or	1 req	Current Stock: 19 Our Price: $2.00
49	001210884	Tightener Mounting Bolt	2 req	Avail to order Our Price: $27.24
50	008603101	Ring 32 mm Or	4 req	Current Stock: 1 Our Price: $3.66
51	001210883	Oil Pump Gear Pin	1 req	Avail to order Our Price: $24.17
52	001219179	Oil Pump Idle Gear	1 req	Avail to order Our Price: $252.33
53	001219180	Oil Pump Driving Gear	1 req	Avail to order Our Price: $89.64
54	008100640	Special Screw	2 req	Avail to order Our Price: $14.09
55	008300822	Stud M8x18 Uni 5911 8g Z	4 req	Avail to order Our Price: $24.62
56	001210877	Chain Tightener Bracket Seal	2 req	Current Stock: 2 Our Price: $3.72
57	WHT001514	SPRING WASHER	4 req	Current Stock: 9 Our Price: $25.05
58	N01118312	HEX.HEAD CLAMPING NUT	4 req	Current Stock: 4 Our Price: $2.01
59	001219507	Chain Tightener Bracket	2 req	Avail to order Our Price: $161.55
60	008522003	Needle Bearing	2 req	Avail to order Our Price: $11.09
61	008575001	O-Ring I 47 Uni 3654	4 req	Current Stock: 11 Our Price: $2.00
62	001210848	Gear	1 req	Avail to order Our Price: $1,090.77
63	001210896	Chain Tightener Spring	2 req	Avail to order Our Price: $32.10
64	WHT003079	Reference Pin 8h7x6.25x10	2 req	Avail to order Our Price: $33.17
65	001210885	Oil Pump Cover	1 req	Avail to order Our Price: $189.43
66	WHT001197A	WASHER	8 req	Current Stock: 2 Our Price: $2.00
67	008100621	Screw M6x20 Uni 5739/5s/Z	8 req	Avail to order Our Price: $2.00
68	001210838	Timing Case Cover	1 req	Avail to order Our Price: $1,579.69
69	001210880	Belt Tightener Spring Shim	2 req	Avail to order Our Price: $9.08
70	008700821	Grub Screw 8x1.25x108 8g	2 req	Avail to order Our Price: $22.09
71	008400802	Copper Washer 8.4x16x1.5	4 req	Avail to order Our Price: $2.00
72	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
73	008200804	Nut	2 req	Current Stock: 7 Our Price: $2.00
74	001219543	Soundproof Screw Rubber Pad	2 req	Avail to order Our Price: $20.59
75	008601500	Ring 15 mm Or	2 req	Avail to order Our Price: $2.00
76	001219542	Clamping Soundproof Screw	2 req	Avail to order Our Price: $56.76
77	001210849	Gear	1 req	Avail to order Our Price: $909.22
78	001210853	Specer	2 req	Avail to order Our Price: $9.16
79	001219517	Timing Case Upper Cover	1 req	Avail to order Our Price: $105.22
80	001211009	Cover Grommet Shim	1 req	Avail to order Our Price: $9.37
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
