Maintenance Parts:

Belts

PN Item Diagram
004613685 Air Pump Belt
Air Pump Belt
view diagram Current Stock: 2
Our Price: $60.44
Air Pump Belt
001219534 Auxiliary Unit Belt
Auxiliary Unit Belt
view diagram Avail to order
Our Price: $263.49
Auxiliary Unit Belt

Brakes

PN Item Diagram
003135292 Brake Pads Front - Jalpa - Early Diablo - Per Rotor
Front Brake Pads
view diagram Avail to order
Our Price: $400.43
Brake Pads Front - Jalpa - Early Diablo - Per Rotor
003220800 Brake Pad Rear - Urraco - Jalpa - Sold Each
Rear Brake Pad Kits
view diagram Avail to order
Our Price: $83.45

Drivetrain

PN Item Diagram
001505914 Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa
Oil Cartridge. Note: these are ordered directly from the factory. Brand/Model/Color may differ from the picture. We have no control as to what is sent when they are ordered.
view diagram Current Stock: 11
Our Price: $65.82
Oil Filter - Diablo - LM002 - Countach - Urraco - Jalpa
002108644 Thrust Bearing
Thrust Bearing
view diagram Current Stock: 1
Our Price: $741.26
Thrust Bearing
002109862 Clutch Plate
Clutch Plate
view diagram Current Stock: 2
Our Price: $1,212.12
Clutch Plate
002111111 Clutch Pressure Plate
Clutch Pressure Plate
view diagram Current Stock: 1
Our Price: $2,417.66
Clutch Pressure  Plate
002111112 Flywheel
Flywheel
view diagram Avail to order
Our Price: $1,072.26
002106838 Clutch Cylinder Rod
Clutch Cylinder Rod
view diagram Avail to order
Our Price: $57.81
004219984 Master Clutch Cylinder
Clutch Cylinder Control Assembly
view diagram Avail to order
Our Price: $265.38
Master Clutch Cylinder

Fuel-Air

PN Item Diagram
006220011 Fuel Filter
Fuel Filter
view diagram Avail to order
Our Price: $243.98
001320172KN Performance filter for Countach/Espada/Jarama/Miura
High Flow performance filter.
Current Stock: 3
Our Price: $125.90
Performance filter for Countach/Espada/Jarama/Miura

Fuses-Bulbs-Relays

PN Item Diagram
006309758 Cylinder Bulb 6411/12v 10w
Cylinder Bulb 6411/12v 10w
view diagram Avail to order
Our Price: $10.02
006311154 Relay
Relay
view diagram Avail to order
Our Price: $36.46
Relay
006617093 12v 5w Bulb
12v 5w Bulb
view diagram Avail to order
Our Price: $15.67
006617094 Check Parts Manual for location
Bulb LAMP BA 15S 21W Used in various lamps (depending on your year and model)
view diagram Current Stock: 77
Our Price: $7.65
Check Parts Manual for location
006617106 12v 60/55w Bulb
12v 60/55w Bulb
view diagram Avail to order
Our Price: $66.16
N0177522 bulb
Headlight LAMP 12V/3W
view diagram Current Stock: 10
Our Price: $2.00
bulb

Gaskets

PN Item Diagram
001526473 Grommet and Oil Seals Set - Jalpa - Miura
Grommet and Oil Seals Set Jalpa - Miura
Avail to order
Our Price: $265.38
Grommet and Oil Seals Set - Jalpa - Miura
001526492 Engine Gasket Kit Jalpa
Engine Gasket Kit
Avail to order
Our Price: $1,067.17
001526493 Engine Gasket Set - Jalpa - Miura
Engine Gasket Kit Jalpa and Miura See also 001526473 grommet & oil seals set
Avail to order
Our Price: $925.87
Engine Gasket Set - Jalpa - Miura

Ignition

PN Item Diagram
001622092 Spark Plug Wires - Jalpa
Wires From Distributor To Spar
view diagram Avail to order
Our Price: $507.14
Spark Plug Wires - Jalpa
008811403 Spark Plug - Countach-Jalpa
Spark Plug
view diagram Avail to order
Our Price: $56.04

Misc

PN Item Diagram
006121168 Wiper Blade Type B
Wiper Blade Type B
view diagram Avail to order
Our Price: $34.08
008200605R OE spec alternative for 008200605
M6 Ncm 70 Urama Simmon Nut
Avail to order
Our Price: $3.00
OE spec alternative for 008200605
900000381 NLA (No Longer Available)
Comes with Eyelet connects, Clamp connectors and Cigar Lighter Adapter.
Avail to order
Our Price: $158.74
NLA (No Longer Available)
900000382 NLA
use PN 400093050D for USA replacement
Avail to order
Our Price: $158.74
NLA

Sensors

PN Item Diagram
001801333 NLA (No longer Available to order)
Oil & Coolant Temperature Thermometer
view diagram Avail to order
Our Price: $114.27
NLA (No longer Available to order)
002408637 Reverse Switch
Switch
view diagram Avail to order
Our Price: $115.62
Reverse Switch
Open All

Select Group and TAV

TAV: 21.32 - Rear Brakes

1981-1988 Lamborghini Jalpa 3.5 USA Rear Brakes (21.32)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Jalpa Parts Manual. Sorry, but there are NO exceptions.

Item # PN Item Qty Req *
0 003206923 NLA (NO LONGER AVAILABLE)
1 req *See Description
1 003211423 This item is no longer available 1 req
2 003211467 This item is no longer available 1 req
3 003201511 Bolt
2 req Avail to order
Our Price: $45.36
4 003204607 Brake Booster Union Pipe
2 req Avail to order
Our Price: $100.70
5 003101513 Copper Washer 16.2x24x1
4 req Current Stock: 2
Our Price: $2.00
Copper Washer  16.2x24x1
6 003204974 NLA (No longer Available to order)
1 req *See Description
7 003211470 Vacuum Fastening Plate
1 req Avail to order
Our Price: $8.30
8 003208361 Brake Booster Three-Way Union
1 req Avail to order
Our Price: $8.39
9 008612505 Grommet 25x30x4 mm
1 req Avail to order
Our Price: $5.73
10 008830205 Clamp
7 req Current Stock: 3
Our Price: $6.67
Clamp
11 N0211963 HEX.HEAD CLAMPING
3 req Current Stock: 14
Our Price: $2.00
HEX.HEAD CLAMPING
12 003220004 Pressure Regulator Ratio 0.7
1 req Avail to order
Our Price: $80.84
13 008200804 Nut
1 req Current Stock: 7
Our Price: $2.00
Nut
14 N01152427 WASHER
1 req Current Stock: 17
Our Price: $2.00
WASHER
15 003211466 This item is no longer available 1 req
16 003211428 Lh Shoe Pressure Regulating Pi
1 req Avail to order
Our Price: $16.88
17 003209326 NLA (No Longer Available)
1 req *See Description
18 003211468 This item is no longer available 1 req
19 003208687 Shoe Pipe/Three-Way
2 req Avail to order
Our Price: $189.74
20 008100631 Screw M6x8 Uni 5739 8g
4 req Avail to order
Our Price: $2.00
21 008410603 Washer D.6.4 Uni 1751/Zd
4 req Current Stock: 24
Our Price: $2.00
Washer D.6.4 Uni 1751/Zd
22 003208690 Three-Way Union Bracket
2 req Avail to order
Our Price: $50.63
23 008101224 Special Screw
4 req Avail to order
Our Price: $16.88
24 008411303 Snap Ring 21x13x2.5 Uni 175 1
4 req Current Stock: 14
Our Price: $2.38
Snap Ring 21x13x2.5 Uni 175 1
25 008401305 Washer 13x22x* C 72
1 req Avail to order
Our Price: $2.00
26 008201014 M10x1x6 Uni 5589/5s/Z Nut
2 req Current Stock: 1
Our Price: $6.01
M10x1x6  Uni 5589/5s/Z  Nut
27 003208683 Hose
2 req Avail to order
Our Price: $76.40
Hose
28 003211469 This item is no longer available 1 req
29 008100629 Screw M6x22 Uni 5739/8g
2 req Avail to order
Our Price: $2.00
30 WHT001197A WASHER
2 req Current Stock: 11
Our Price: $2.00
WASHER
31 003208682 Union
2 req Current Stock: 1
Our Price: $54.17
Union
32 003208686 POSSIBLE NLA OR NEW PART NUMBER - CONTACT SALES DEPT
2 req *See Description
33 003220800 Brake Pad Rear - Urraco - Jalpa - Sold Each
4 req Avail to order
Our Price: $83.45
34 003206922 NLA (No Longer Available)
1 req *See Description
35 003106919 Ventilated Front/Rear Brake Di
2 req Avail to order
Our Price: $1,331.60
36 008100826 Screw M8x16 Uni 5739/8g/Z
4 req Avail to order
Our Price: $2.00
Screw M8x16 Uni 5739/8g/Z
37 003211424 This item is no longer available 1 req
38 N90179103 WASHER
1 req Current Stock: 18
Our Price: $2.00
WASHER
39 N0111849 HEX.HEAD CLAMPING NUT
1 req Current Stock: 8
Our Price: $2.00
40 003221686 Pipe From Three-Way To Brake R
1 req Avail to order
Our Price: $58.09
41 003221667 Brake Regulator
1 req Avail to order
Our Price: $155.71
41 003211515 Recirculation Pressure Regulat
1 req Avail to order
Our Price: $291.84
42 003221668 Brake Regulator Bracket
1 req Avail to order
Our Price: $4.62
43 N0152785 WASHER
1 req Current Stock: 125
Our Price: $2.00
WASHER
44 008100839 Screw M8x10 Uni 5739/8g Z
1 req Current Stock: 17
Our Price: $2.00
Screw M8x10 Uni 5739/8g Z

* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
