TAV: 9.0.12 - Clutch

1968-1978 Lamborghini Espada USA Clutch (9.0.12)

Please note: You are not permitted to print or save images of the catalog pages. If you need a page printed, you must purchase a Espada Parts Manual. Sorry, but there are NO exceptions.

Item #	PN	Item	Qty Req *
1	008602003	Ring 21 mm Or	2 req	Avail to order Our Price: $2.00
2	002109617	Clutch Control Fork	1 req	Avail to order Our Price: $424.94
3	008900801	Elastic Pin 8x32	2 req	Avail to order Our Price: $12.06
4	002109618	Clutch Fork Shaft	1 req	Avail to order Our Price: $318.36
5	002109615	Clutch Cylinder Return Spring	1 req	Avail to order Our Price: $12.06
6	002102530	Clutch Shaft ControlLever	1 req	Avail to order Our Price: $196.04
7	008410818	Snap Ring 8x12.7x2 Uni 1751	1 req	Avail to order Our Price: $2.92
8	008100838	Special Screw M8x25	1 req	Avail to order Our Price: $16.09
9	410721493	Brake Pipe Protection Rubber W	2 req	Avail to order Our Price: $58.16
10	003105378	NLA	1 req	*See Description
11	008300825	Stud M8x22 Uni 5911 10k Z	2 req	Avail to order Our Price: $15.24
12	002100254	NLA (No Longer Available)	1 req	*See Description
13	N91116801	WASHER	1 req	Current Stock: 1 Our Price: $8.93
14	002101961	Union Male-Male	1 req	Avail to order Our Price: $32.28
15	WHT001514	SPRING WASHER	2 req	Current Stock: 9 Our Price: $26.80
16	008200806	M8 Uni 5588/8g/Z Nut	2 req	Current Stock: 25 Our Price: $2.00
17	002104088	Clutch Rod	1 req	Avail to order Our Price: $28.39
18	008200811	M8 Uni 5589/8g/ZdNut	1 req	Avail to order Our Price: $6.81
19	002104084	This item is no longer available	1 req
20	003381387	This item is no longer available	1 req
21	WHT001942	WASHER	1 req	Current Stock: 13 Our Price: $3.50
22	008820281	This item is no longer available	1 req
23	008613502	Oil Seal 35x47x7 mm	1 req	Current Stock: 9 Our Price: $10.95
24	008850687	This item is no longer available	2 req
25	002401842	Gearbox Front Cover Seal	1 req	Avail to order Our Price: $27.32
26	002401837	Gearbox Front Cover	1 req	Avail to order Our Price: $463.64
27	N0152785	WASHER	2 req	Current Stock: 71 Our Price: $2.00
28	008100837	Screw 8x1.25x19uni4721 10k	2 req	Avail to order Our Price: $27.71
29	002104716	Sleeve	1 req	Avail to order Our Price: $358.62
30	002184715	This item is no longer available	1 req
31	002184712	This item is no longer available	1 req
32	002184719	This item is no longer available	1 req
33	008850808	Dowel 8x18	1 req	Avail to order Our Price: $25.38
34	008850807	Dowel 8x12.842	3 req	Avail to order Our Price: $20.13
35	001407366	Espada Flywheel	1 req	Avail to order Our Price: $1,753.84
36	008300825	Stud M8x22 Uni 5911 10k Z	8 req	Avail to order Our Price: $15.24
37	008410408	This item is no longer available	8 req
38	N01100845	HEX.NUT	8 req	Current Stock: 17 Our Price: $2.14
39	008190830	This item is no longer available	8 req
40	N0152785	WASHER	6 req	Current Stock: 71 Our Price: $2.00
41	008100838	Special Screw M8x25	8 req	Avail to order Our Price: $16.09
42	008410411	This item is no longer available	4 req
43	008830112	Pipe Clamp	2 req	Avail to order Our Price: $126.12
44	002109618	Clutch Fork Shaft	1 req	Avail to order Our Price: $318.36
* Qty Req is the Quantity used on this part diagram. This does NOT mean this is how many you get, but rather how many you need to buy if you are replacing all the parts.
